Basic Operations

Moving Images

PictureFrame displays images in a linear fashion by default. The images can be moved up or down
the display list.
To move an image up by one (1):
1. Select the album from the drop down list.
2. Select the image within the Images for Album: window.
3. Go to Images > Move Up.
To move an image down by one (1):
1. Select the album from the drop down list.
2. Select the image within the Images for Album: window.
3. Go to Images > Move Down.

Changing Image Durations

The duration each image displays can be set either individually or all images within an album can
be set to the default time.
To set individual durations:
1. Select the album from the drop down list.
2. Select the image within the album.
3. Go to Images > Image Properties to open the Image Properties Dialog.
4. Set the time, in seconds or minutes, within the Time Duration field.
Click OK.
To reset all images to the default duration:
1. Select the album from the drop down list.
2. Select the image within the album.
3. Go to Images > Reset All Image Durations to open the Reset Image Dialog.
4. Click Yes.

Getting Image Properties

Image properties can be altered and changed individually. To change the file location, image file or
file duration the image properties must be edited:
1. Select the album containing the desired image from the drop down list.
2. Select the image within the Album Management window.
3. Go to Images > Image Properties to open the Image Properties Dialog.
4. Select and change any or all fields, i.e. Location, Image File or Duration.
5. Click OK.
The Duration field is in seconds or minutes (range = 5 to 1800 seconds).
8 PictureFrame
