Mode Alerts
VG-2 Audio/Visual Alerts
NOTE: You must turn this feature on before it will
Because POP
™
Mode travels on regular radar bandwidth,
detect VG-2.
there is no particular alert for POP
™
Mode transmissions.
POP
™
Mode alerts will be displayed as a regular radar alert.
When a VG-2 signal is detected, the detector 'hides' its own
radiated signal and becomes undetectable by the VG-2.
Every 30 seconds, the detector checks for a VG-2 signal.
LASER/RADAR ALERTS
If a VG-2 signal is still present, the unit continues to
hide and repeats the VG-2 alert. If no signal is detected,
Speed Radar Audio/Visual Alerts
two beeps are provided, indicating an 'all clear' condition.
When X, K or Ka is detected, the band ID and signal
During a VG-2 Alert X, K, and Ka band signals cannot
strength is displayed. The audio alert is continuous
be received (Reference page 21 for VG-2 information).
and has a geiger counter-like pattern. The faster the
beep, the closer or stronger the radar source.
Alert Priority
Laser Audio/Visual Alerts
When two or more signals are received at the same
When a laser signal is detected the audio alert is continuous
time, the alert priority is:
for a minimum of 3 seconds.
1. Laser
• The Displays Shows:
2. VG-2
The more "|||" the closer the laser source.
3. Speed Radar
4. Safety Radar
Example:
Pulse Protection
®
If X band is alerting, then suddenly a VG-2 signal
Pulse (or instant-on) radar is more difficult to detect
is detected, the VG-2 warning will override the
than conventional radar because it remains 'off' until
X band alert.
activated to measure the speed of a targeted vehicle.
When a pulse type transmission is detected, your Whistler
detector sounds an urgent 3-second audio warning
and the display shows:
After the 3-second pulse alert, the standard alert pattern
continues for as long as the signal is present.
It is important to respond promptly to a pulse alert,
since warning time may be minimal.
14
SPEED MONITORING
SPEED MONITORING
N N O O T T E E : : H H a a v v i i n n g g a a r r a a d d a a r r d d e e t t e e c c t t o o r r c c a a p p a a b b l l e e o o f f d d e e t t e e c c t t i i n n g g t t h h e e
Laser Tips
V V G G - - 2 2 m m a a y y a a l l e e r r t t y y o o u u t t o o t t h h e e p p r r e e s s e e n n c c e e o o f f a a s s p p e e e e d d t t r r a a p p . .
If you are the targeted vehicle, a laser gun can often
T T h h e e n n e e w w e e s s t t t t o o o o l l P P o o l l i i c c e e h h a a v v e e t t o o d d e e t t e e c c t t r r a a d d a a r r d d e e t t e e c c t t o o r r s s i i s s
determine your speed within a few seconds after you
c c a a l l l l e e d d S S p p e e c c t t r r e e . . A A s s o o f f t t h h i i s s p p r r i i n n t t i i n n g g . . S S p p e e c c t t r r e e c c a a n n d d e e t t e e c c t t a a l l l l
receive an alert. In this situation there is generally no
u u n n d d e e t t e e c c t t a a b b l l e e ( ( V V G G - - 2 2 ) ) l l a a s s e e r r / / r r a a d d a a r r d d e e t t e e c c t t o o r r s s o o n n t t h h e e m m a a r r k k e e t t . .
time to safely adjust your speed. However, if you are
traveling near or behind the targeted vehicle and
It is the responsibility of the individual radar detector
receive an alert, response time should be sufficient.
owner to now and understand the laws in your area
Any laser alert, regardless of duration, requires
regarding the legality of the use of radar detectors.
immediate action!
Other Speed Detection Systems
Several techniques other than radar or laser are used
WARRANTY INFORMATION
to measure vehicle speeds. When these methods are
Consumer Warranty
being used, no detector can provide a warning. These
techniques include:
This Whistler Laser-Radar detector is warranted to the
original purchaser for a period of one year from the date
• P P a a c c i i n n g g - A patrol car drives behind you and matches
of original purchase against all defects in materials and
your driving speed.
workmanship. This limited warranty is void if the unit is
• V V a a s s c c a a r r / / A A i i r r c c r r a a f f t t - The time it takes a vehicle to travel
abused, modified, installed improperly, if the housing
a known distance is measured.
and/or serial numbers have been removed. There are no
express warranties covering this product other than
Radar Detector Detectors: VG-2, Spectre
those set forth in this warranty. All express or implied
warranties for this product are limited to the above time.
The Interceptor VG-2. or simply VG-2, is one type of
Whistler is not liable for damages arising from the use,
microwave receiver used by Police to detect signals
radiated by the local oscillator of a radar detector.
misuse, or operation of this product.
Because it purpose is to identify persons driving with
radar detectors, these devices are known as a "radar
detector detector" (RDD).
An RDD is the primary tool used by the police to identify
radar detectors equipped vehicles. If caught in a state or
country where detectors are illegal, (see page 18). drivers
risk losing their radar detector and receiving a fine. In
addition, instant-on radar is almost always used in
combination with a RDD, leaving unsuspecting motorists
vulnerable to receive two tickets - one potential for
speeding, the other for possession of a detector.
21
RESET FEATURES
Reset Features
All user features can be reset to factory settings.
•Unplug Power Cord from unit.
•Press and hold Power and Quiet.
•Plug Power Cord into unit.
•Wait for 2 beeps.
•Release Power and Quiet buttons.
Unit is now reset to the following features
and settings.
Default factory settings are:
1. Audio to level (4).
2. Display reads Highway.
3. Dim/Dark Mode to full illumination of display.
4. Auto Quiet Mode OFF.
5. VG-2 Detection Mode OFF.
6. Safety Radar OFF.
7. Vehicle Battery Saver ON.
8. Full Power Up sequence.
9. Default TONE 3.
10. POP ON.
11. Voice On (1778 only).
12. DAD set to ALL (1776 only)
15
16
WARRANTY INFORMATION
Service Under Warranty
During the warranty period, defective units will be
repaired without charge to the purchaser when returned
with a dated store receipt to the address below. Units
returned without a dated store receipt will be han-
dled as described in section "Service Out Of
Warranty." Due to the specialized equipment necessary
for testing a Laser-Radar receiver, there are no
authorized service stations for Whistler brand detectors
other than Whistler.
When returning a unit for service under warranty,
please follow these instructions:
1. Ship the unit in the original carton or in a suitable
sturdy equivalent, fully insured, with return
receipt requested to:
Whistler Repair Dept.
1201 North Dixieland Rd
Rogers, AR. 72756
Please allow 3 weeks turnaround time.
IMPORTANT: Whistler will not assume responsibility
for loss or damage incurred in shipping. Therefore,
please ship your unit insured with return receipt
requested. CODs will not be accepted!
2. Include with your unit the following information,
clearly printed:
• Your name and street address (for shipping via
UPS), a daytime telephone number and an
email address, if applicable.
• A detailed description of the problem (e.g., "Unit
performs self-test but does not respond to radar").
• A copy of your dated store receipt or bill of sale.
23
22
TROUBLESHOOTING
CARE AND MAINTENANCE
Your Whistler detector is expertly engineered and
Care And Maintenance
designed to exacting quality standards to provide
During the summer months, avoid prolonged exposure
you with reliable, trouble-free operation. If your unit
to direct sunlight by removing your unit from the dash
has been correctly installed following the guidelines
when your vehicle is parked for an extended period of
in this manual, but is not operating optimally, please
time. Do not spray water, cleaners, or polishes directly
refer to the troubleshooting guide below.
onto the unit. The spray may penetrate through the
openings and damage the unit. Also, do not use any
PROBLEM: No display or audio.
abrasive cleaners on the unit's exterior.
• Check fuse in Whistler plug; replace if necessary with a 2
amp 3AG type.
• Check fuse for lighter socket; replace if necessary.
ARE DETECTORS LEGAL?
• Make sure lighter socket is clean.
PROBLEM: Unit alarms when vehicle hits bumps.
• Check for loose lighter socket; tighten and clean.
In Most States YES!
• Check connections at both ends of power cord. Substitute
Laser-Radar detectors are legal in every state (with
another cord to determine if cord is defective. Return
the exception of Virginia and Washington, D.C., which
defective cord to the factory.
have local regulations restricting the use of radar
PROBLEM: Unit alarms when using vehicle electrical
receivers in any vehicle) when used in automobiles or
accessories (brakes, power mirrors, power
light trucks (under 10,000 lbs.).
windows, turn signals, horn, etc.).
Concerning trucks over 10,000 lbs., the Federal
• Vehicle's electrical system, including battery and alternator, may
Highway Administration (FHWA) issued a regulation,
have electrical noise. Install a filter capacitor (470mfd. 25 volt
or larger capacitance value) on the back of the lighter socket.
effective January, 1994 which prohibits radar and laser
detector use in these types of vehicles nationally. Prior
PROBLEM: Unit gives laser alert when accelerating.
to the FHWA regulation, laws existed in the state of
• Possible bad or low quality distributor cap. Replace with
high quality cap.
New York restricting the use of radar detectors in trucks
over 18,000 lbs. and in Illinois in trucks over 26,000 lbs.
PROBLEM: Audio alerts are not loud enough.
• Cancel Auto Quiet Mode or City Mode.
• Check audio level setting (see page 7 & 8).
If difficulties occur which cannot be solved by information
in this Troubleshooting Guide, please call Whistler
Customer Service at 1-800-531-0004 or visit our FAQ
page at www.whistlergroup.com/faq-detectors.asp,
before returning your unit for service.
17
WARRANTY INFORMATION
WARRANTY INFORMATION
3. Be certain your unit is returned with its serial number.
IMPORTANT: When returning your unit for service,
For reference, please write your unit's serial number
be certain to include a daytime telephone number
in the following space: s/n_______________.
and email address (if applicable).
Units without serial numbers are not covered under warranty.
Customer Service
IMPORTANT: To validate that your unit is within
If you have questions concerning the operation of your
the warranty period, make sure you keep a copy
Whistler detector, or require service during or after
of your dated store receipt. You may register
the warranty period, please call Customer Service at:
your warranty online at www.whistlergroup.com,
1-800-531-0004
however, for warranty verification purposes, a
Representatives are available to answer your questions
copy of your dated store receipt must accompany
Monday - Friday from 8:00 a.m. to 5:00 p.m. (CT) or
any unit sent in for warranty work.
visit the FAQ's at www.whistlergroup.com.
Service Out of Warranty
Units will be repaired at 'out of warranty' service
SPECIFICATIONS
rates when:
• The units original warranty has expired.
• A dated store receipt is not supplied.
Dimensions: 4.65" L x 2.95" W x 1.45" H
• The unit has been returned without its serial number.
Weight: 1776 - 6.02 oz., 1778 - 6.3 oz.
• The unit has been abused, modified, installed
improperly, or had its housing removed.
Laser Wavelength: 905 ± 50 nanometers (nm)
Radar Frequencies:
The minimum out of warranty service fee for your
10.500 - 10.550 GHz (X Band)
Whistler detector is $55.00 (U.S.). If you require out
24.050 - 24.250 GHz (K Band )
of warranty service, please return your unit as outlined
in the section "Service Under Warranty" along with a
33.400 - 36.000 GHz (Ka Superwideband)
certified check or money order for $55.00. Payment
Operating Temperature Range: -20˚ C to +80˚ C
may also be made by MasterCard, VISA or American
(-4˚ F to +176˚ F)
Express; personal checks are not accepted.
Power Requirements:
In the event repairs cannot be covered by the
Operational 12 to 15 volts DC, 250mA nominal
minimum $55.00 service fee, you will be contacted
Vehicle Battery Saver, 30mA nominal.
by a Whistler technical service specialist who will
outline options available to you.
One or more U.S. patents may apply:
#5,146,227, #5,379,456, #5,666,120, #5,990,821
If you elect not to have your unit repaired, it will be
returned to you along with your certified check or
POP™ Mode is a trademark of MPH Industries, Inc.
money order.
Specifications are subject to change without notice.
24
FCC INFORMATION
FCC ID : HSXWH11
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device many not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
IMPORTANT
FCC requirements state that changes or modifications
not expressly approved by Whistler could void the
user's authority to operate the equipment.
SPEED MONITORING
Radar Facts
A radar gun operates by transmitting radio waves at
certain frequencies which reflect off objects and are
picked up by the radar gun's receiving section. When
a radar beam reflects off a moving target, a measura-
ble frequency shift occurs. The radar unit converts this
shift into miles per hour to determine your vehicle's
speed. Currently, the FCC (Federal Communications
Commission) permits operation of traffic radar guns
at X Band (10.500 - 10.550 GHz), K Band (24.050 -
24.250 GHz), and Ka Band (33.400 - 36.000 GHz).
Note: A radar detector will not alarm if an officer is
not transmitting on any one of the above radar bands.
POP™ Mode
POP
™
Mode is a feature on some newer radar guns
operating on K and Ka bands. When the gun is in
POP
™
Mode and activated, a brief burst of energy,
less that 1/15 of a second, is transmitted and the
vehicle's speed is quickly acquired. A detector without
POP
™
Mode detection capability cannot respond to
this brief transmission.
18
19
ACCESSORIES
These and other accessories can be ordered directly
from Whistler by calling 1-800-531-0004 or by visiting
our online store at www.whistlergroup.com
*Modular: Interconnecting pieces cord and plug. Shipping and
handling (per order) $7.50 Prices are subject to change without notice.
25
26
SPEED MONITORING
Total Band Protection™
Complete Band Coverage that detects laser, radar,
VG-2 and safety radar bands.
Laser Facts
It's well documented that many radar guns cannot
reliably provide the speed of a targeted vehicle that
is traveling in a group of vehicles. In contrast, a laser
gun can target a specific vehicle out of a line of traffic
and determine its speed. The advantage of laser
over radar in terms of target identification is the result
of the laser gun's narrow beam. A radar gun's trans-
mission can cover more than a four-lane highway at a
distance of 1,000 feet, compared with a laser gun's
transmission which covers about 3 feet at the same
distance. For best protection, keep these points in
mind:
• Because the vehicle's license plate or headlights
are the laser gun's primary targets, mounting the
Whistler detector on the dashboard can improve
laser detection at short range.
• Do not follow closely behind any vehicle you cannot
see through. If you can't see past a vehicle ahead
of you, chances are your detector won't either.
• The receiving range of your laser detector will not
be the same as a radar detector. Laser guns are
most often used at short range.
Whistler Laser-Radar detectors receive all current laser
guns which operate at a laser wavelength of 905 +/- 10mm.
•Pro Laser
™
I II III
•LT1 20-20
•Ultra Lyte
20
OWNER'S MANUAL
1776/78
Total Band Protection
™
LASER-RADAR
DETECTOR
The Whistler Group Corporate Headquarters
13016 N. Walton Blvd. • Bentonville, AR 72712
Tel 479.273.6012 • Fax 479.273.2927
Customer Return Center
1201 N. Dixieland Rd. • Rogers, AR 72756
Customer Service Tel 800.531.0004
www.whistlergroup.com
P/N 203348, © 2005 The Whistler Group, Inc.
Need help?
Do you have a question about the 1776 and is the answer not in the manual?
Questions and answers
