Whistler 1700 Series User Manual

1753/1763
LASER-RADAR
DETECTOR
The Whistler Group, Inc.
Corporate Headquarters
13016 N. Walton Blvd. • Bentonville, AR 72712
Tel (479) 273-6012 • Fax (479) 273-2927
Customer Return Center
1201 N. Dixieland Rd. • Rogers, AR 72756
Consumer Relations Tel (800) 531-0004
P/N 203332©2003 The Whistler Group, Inc.
WHISTLER FEATURES
- 3 -
If you have questions concerning the
operation of this Whistler product
please call:
Customer Service
1-800-531-0004
Monday - Friday
8:00 am - 5:00 pm CT
or visit our website
whistlergroup
www. .com
Please keep the receipt in a safe place.
You may register your product online at
whistlergroup
www. .com
For warranty verification purposes,
a copy of your dated store receipt
must still accompany any unit sent in
for warranty work. If the unit is
returned without a dated store receipt an
out of warranty service charge applies.
Note: Your warranty period begins at the
time of purchase. The warranty is
validated only by the dated store
receipt! Now is the time to record the
serial number of the unit in the space
provided in the warranty section of
the manual.
WHISTLER FEATURES
Whistler's ergonomic and user-friendly design provides
a new level of operating convenience. Special features
include:
1. Bracket Release Button – Provides quick and
easy release of the mounting bracket.
2. Speaker – Provides distinct audio warnings for X,
K, Ka band radar, safety radar, laser and VG-2.
3. Mounting Bracket Location - Slot holds mount-
ing bracket firmly.
4. Radar Antenna - Compact, high-efficiency anten-
na receives radar signals.
5. Laser Antenna (Front) - High gain optical lens
provides increased sensitivity and field o.
6. Laser Antenna (Rear) - An integrated optical
waveguide provides superior detection of laser
signals transmitted from behind.
7. CITY/CITY 1/CITY 2 Button - Switches out of
highway mode to reduce the annoyance of false
alerts typically encountered in urban driving areas.
8. Quiet Button - Pressing QUIET before a signal is
detected engages Auto Quiet Mode which
automatically reduces the audio level after the
initial warning to a low audio level setting.
Pressing QUIET during a radar/laser encounter
silences audio alerts, while allowing visual alerts
to keep you informed.
9. Power/Dim/Dark/Button – Turns unit on/off and
engages Dim/Dark modes (press and hold for
2 seconds).
10. Volume Up/Down Buttons – Adjust volume up or
down. Pressing both buttons enters compass
calibration mode (1763 only).
- 4 -
INTRODUCTION
Dear Whistler Owner,
For many of us, a vehicle is more than just trans-
portation. It can be a mobile office, communications
or entertainment center, or simply an expression of
our personality. Whistler products are designed to
make the time you spend in your vehicle more
productive, more fulfilling, safer, or just simply more
fun. Our mission is to provide products that improve
your driving experience.
Our new units offer not only bold new styling but
also many features not found on other detectors at any
price. We start with a proven detection circuitry with
All Band ™ and added top-of-the-line features such as:
• Whistler's exclusive Safe Driving System
Incorporates the Safety Warning System (SWS),
keeping you informed of road hazards as well as
our unique Stay Alert system, it tests your alert-
ness on long solo trips.
• High Visibility Text Display - Shows laser-
radar information, VG-2 alerts, SWS messages
and detector settings.
• Real Voice ® - (1753 only) allows you to keep
your eyes on the road.
• Digital Compass - (1763 only) provides
cardinal points and direction in 5 degree
increments.
Even though these units are packed full of
features, they're still very easy to use. To fully utilize
your unit to its potential, we recommend reading this
entire manual or visit our FAQ page on our web site
www.whistlergroup.com.
Note: On 1763 model the compass must be
calibrated before use! See Compass Calibration
set-up section.
Enjoy your new Whistler and please drive safely.
Sincerely,
The Whistler Group, Inc.
WHISTLER FEATURES
11. High Visibility Text Display – Provides distinct
visual confirmation of signals detected such as
VG-2 Laser, X-Band, K-Band, Ka-Band, Highway
Mode, City Mode, Signal Strength, and Compass.
Note: Not all units have all features described.
INSTALLATION
Mounting Guidelines
• Mount the unit as low and level as possible near
the center of the windshield. Unit must be level for
compass to function properly.
• Do not mount your unit behind wipers, ornaments,
mirrored sunscreens, etc. These obstructions have
metal surfaces which can affect radar and laser signals
and reduce critical warning time. (Regular tinted
glass does not affect reception.)
• Some windshields have an Instaclear
type coating, which affect radar signals. Consult your
dealer or the owner's manual supplied with your vehi-
cle to determine if your windshield has this coating.
• Avoid placing unit in direct contact with windshield.
• To reduce the possibility of theft, conceal your unit
when not in use.
- 5 -
TABLE OF CONTENTS
Topic
Model Features Summary
• Features Listing of 1753 / 1763
Installation
• Mounting Guidelines
• Windshield Mounting
• Power Connection and Fuse Replacement
Operation
• Compass Calibration Set-Up Operation
• Power On And Self-Test
• Memory / Beep Confirmation
• Audio Level Adjustment
• Integrated Real Voice ®
• Compass Mode
• Auto Quiet / Quiet Mode
• City Mode
• Dim/Dark Mode
• Engaging / Disengaging VG-2 Detection
• Stay Alert
• Option Select Mode
• Teach / Tutorial Mode
• Vehicle Battery Saver Mode
Radar, Laser and VG-2 Alerts
• Radar Alerts
• Pulse Protection ®
• Laser Audio / Visual Alerts
• Safety Warning System ™
• VG-2 Audio / Visual Alerts
• Alert Priority
• Reset Features
• Care and Maintenance
Troubleshooting Guide
Are Detectors Legal?
Speed Monitoring Technologies
• Radar Facts
• Laser Facts
• Other Speed Detection Systems
• Radar Detector Detectors
Warranty Information
Specifications
Accessories
™ or Electriclear ™
Page
3
4 - 5
6 - 7
5
6
7
8 - 16
8
9
9
9
10
10
10 - 11
11 - 12
12
13
13
14
16
16
17
17
17
17
18
19
19
20
20
21
22
23
23
24
25
25
26 - 28
29
30
