- Page 1 XDrum Drum Stool Semi ArtNo. : 00006432 Assembly instructions Version: 05.2021...
-
Page 2: Detailed Safety Instructions
Semi © 2021 These operating instructions are protected by copyright. Reproduction of these operating instructions, even in part, is only permitted with the permission of Musikhaus Kirstein GmbH. The same applies to the reproduction or copying of images, even in modified form. - Page 3 Semi Thank you for choosing this product. To ensure that you are fully satisfied with this drum stool, please read carefully and understand these assembly instructions before using our product. Keep these assembly instructions in a safe place. The assembly instructions must be passed on to all subsequent users.
- Page 4 Semi Assembly of your XDrum drum stool: (Fig.1) Unfold the tripod and secure it for a firm stand with the lower wing screw. (Fig. 1) (Fig. 2) Insert the rod, which you will later use for height adjustment, into the three-legged...
- Page 5 Semi (Fig. 3) Finally, you can attach the seat to the top of the bar and fix it with a wing screw. The seat position is now height-adjustable from 50 cm to 62 cm. (Fig. 3)
- Page 6 Semi WEEE Declaration (Waste of Electrical and Electronic Equipment) Your product has been designed and manufactured using high quality materials and components that are recyclable and reusable. The symbol means that your product must be disposed of separately from household waste at the end of its life.
- Page 7 Classic Cantabile AP-30 Active Monitor ArtNo. : 00011178 Operating instructions Version: 02.2021...
- Page 8 AP-30 © 2021 These operating instructions are protected by copyright. Reproduction of these operating instructions, even in part, is only permitted with the permission of Musikhaus Kirstein GmbH. The same applies to the reproduction or copying of images, even in modified form. Content Detailed safety instructions: .................
- Page 9 AP-30 Thank you for purchasing this Classic Cantabile Active Monitor. To ensure that you are completely satisfied with the item, please read carefully and understand this owner's manual before using our product. Keep these operating instructions in a safe place. The operating instructions must be passed on to all subsequent users.
-
Page 10: Specifications
AP-30 Detailed safety instructions: • Read these instructions. • Keep these instructions in a safe place. • Heed all warnings. Follow all instructions. • Do not use this appliance near water. • Clean the unit only with a dry cloth. •... - Page 11 AP-30 Use of the Active Monitor Installation place Do not expose your device to the following conditions to avoid deformation, discolouration or more serious damage: Direct sunlight Too high temperatures (near a heat source or in a car exposed to direct sunlight).
- Page 12 AP-30 Controls: Front 1. "Power" button - Switch the unit on or off 2. "Treble" knob - Allows you to adjust the treble in the mix 3. "Middle" knob - Regulate the mids in the mix 4. "Bass" knob - This can be used to raise or lower the bass in the mix 5.
-
Page 13: Connecting The Power Cable
AP-30 Connections: Connecting the power cable Make sure that the amplifier is switched off while connecting or disconnecting the unit from the power source. Connect the power cable to the power input socket on the back of the box. Plug the power cable into the socket. -
Page 14: Aux In Socket
AP-30 AUX IN socket Connect your external audio device (e.g. MP3 player, mobile phone, etc.) to the AUX IN socket to play your favourite songs parallel to the drum kit sound. The volume of the external audio device can be changed using the AUX volume control. -
Page 16: Table Of Contents
© 2020 These operating instructions are protected by copyright. Reproduction of these operating instructions, even in part, is only permitted with the permission of Musikhaus Kirstein GmbH. The same applies to the reproduction or copying of images, even in modified form. Content Safety precautions and precautionary measures .......... - Page 17 XDrum DD-460 Thank you for choosing this product. To ensure that you are completely satisfied with this product, please read these operating instructions carefully before using our product. Keep these operating instructions in a safe place. The operating instructions must be passed on to all subsequent users.
-
Page 18: Safety Precautions And Precautionary Measures
XDrum DD-460 Safety precautions and precautionary measures Always place the appliance securely on a level surface to avoid injury from the appliance falling over. Do not place any devices that can heat up (e.g. lighting equipment or fog machines) on the unit. -
Page 19: Important Information
XDrum DD-460 Important information Power supply Do not plug the appliance into the same sockets as other electrical appliances controlled by an inverter (e.g. freezer, washing machine, microwave or air conditioner) or containing a motor. Depending on how the electrical appliance is used, disturbances in the power supply may cause malfunctions and/or produce audible noises. -
Page 20: Structure And Functions
XDrum DD-460 Structure and functions 1. Drum module 2. Hi-Hat Cymbal 3. Crash Cymbal 4. Tom 1 Pad 5. Tom 2 Pad 6. Ride Cymbal 7. Tom 3 Pad 8. Snare Pad 9. Foot machine 10. Hi-Hat Controller... -
Page 21: Installation Instructions
XDrum DD-460 Installation instructions Workflow: • Open the packaging with a knife and remove all components. Compare the components with the parts list above. • Assemble the components as described in the pictures below and then screw them tight. - Page 22 XDrum DD-460 • Mounting the cymbal pads on the cymbal arms...
- Page 23 XDrum DD-460 • Attach the tom to the frame g. • You can now place the pedals on the floor and connect the cymbal pads and toms to the module via cable.
-
Page 24: Module
XDrum DD-460 Module Top and bottom 1) Volume control: For adjusting the volume 2) On/Off button: Switch the unit on or off 3) DRUM button: Press this button and then use the [+] / [-] buttons to select the different drum kits. -
Page 25: Basic Settings And Operation
XDrum DD-460 Back cover 1) DC IN socket: Connect the supplied power supply unit here to supply the e- drum with power. 2) USB socket: Use this socket to connect your e-drum to a PC/laptop/etc. via USB cable, so that you can use midi functions. - Page 26 XDrum DD-460 4.2) CLICK mode Press the CLICK button to switch to CLICK mode The light of the CLICK button lights up Use the [+] / [-] keys to select the tempo The possible tempo range is between 20 - 300...
- Page 27 XDrum DD-460 4.4) Recording mode (REC button) Press the REC button to switch to recording mode. The REC button light comes on, the metronome starts automatically and you are ready to record. Hit a pad to start recording Press the REC button to stop recording...
-
Page 28: Advanced Settings
XDrum DD-460 Advanced settings 5.1 Setting the volume and trigger parameters Press the DRUM button to enter drum kit mode Press the MULTI button for more than 2 seconds to enter the PAD volume adjustment setup. Now the light of the DRUM button flashes Hit the pad that you want to adjust the volume of. - Page 29 XDrum DD-460 5.2 Setting the metronome The tempo as well as the beat and note values can be changed. Press the CLICK button to access the metronome settings Press and hold the MULTI button for more than 2 seconds for the...
- Page 30 XDrum DD-460 MIDI code default values Pads Key value Bass Drum Snare head Snare Rim Shot Tom1 Fur Tom2 Fur Tom3 Fur Crash surface Crash edge Ride surface Ride edge Pads Key value Hi-Hat surface (open) Hi-Hat rim (open) Hi-Hat surface (closed)
-
Page 31: Weee Declaration
XDrum DD-460 WEEE Declaration (Waste of Electrical and Electronic Equipment) Your product has been designed and manufactured using high quality materials and components that are recyclable and reusable. The symbol means that your product must be disposed of separately from household waste at the end of its life. Dispose of this appliance at your local collection point or recycling centre.
