Young JR-MA Instructions Manual

Wind monitor
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

METEOROLOGICAL INSTRUMENTS
INSTRUCTIONS
WIND MONITOR JR-MA
MODEL 04106
R.M. YOUNG COMPANY
2801 AERO PARK DRIVE, TRAVERSE CITY, MICHIGAN 49686, USA
TEL: (231) 946-3980
FAX: (231) 946-4772
WEB: www.youngusa.com
PN: 04106-90
REV: H082124

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JR-MA and is the answer not in the manual?

Questions and answers

Related Manuals for Young JR-MA

Summary of Contents for Young JR-MA

  • Page 1 METEOROLOGICAL INSTRUMENTS INSTRUCTIONS WIND MONITOR JR-MA MODEL 04106 R.M. YOUNG COMPANY 2801 AERO PARK DRIVE, TRAVERSE CITY, MICHIGAN 49686, USA TEL: (231) 946-3980 FAX: (231) 946-4772 WEB: www.youngusa.com PN: 04106-90 REV: H082124...

  • Page 2: Initial Checkout

    To prevent false readings, signal conditioning (0.098 m/s per Hz) electronics should clamp the signal to excitation or reference level when this occurs. Note: YOUNG signal conditioning devices WIND DIRECTION (AZIMUTH) SPECIFICATION SUMMARY clamp the signal to excitation level. Avoid a short circuit between...

  • Page 3: Installation

    CALIBRATION INSTALLATION The Wind Monitor is fully calibrated before shipment and should Proper placement of the instrument is very important. Eddies from require no adjustments. Recalibration may be necessary after trees, buildings, or other structures can greatly influence wind some maintenance operations. Periodic calibration checks are speed and wind direction observations.

  • Page 4: Maintenance

    MAINTENANCE 6. REPLACE MAIN HOUSING a) Place main housing over vertical shaft bearing rotor. Be Given proper care, the Wind Monitor-JR MA should provide years careful to align indexing key and channel in these two of service. The only components likely to need replacement due to assemblies.

  • Page 5: Emc Compliance

    12 months from date of initial purchase. Liability is limited to repair or replacement of defective item. A copy of the warranty policy may be obtained from R. M. Young Company. CE COMPLIANCE This product has been tested and complies with European CE requirements for the EMC Directive.

  • Page 6: Cable & Wiring Diagram

    CABLE & WIRING DIAGRAM MODEL 04106 WIND MONITOR JR-MA 04106-90(H) Page 5...
  • Page 7 BEARING REPLACEMENT & POTENTIOMETER ADJUSTMENT 04106-90(H) Page 6...
  • Page 8               18502 FERRITE CHOKE R. M. YOUNG COMPANY 2801 Aero Park Drive , Traverse City, Michigan 49686 U.S.A. 04106-90(H) TEL (231) 946-3980 FAX (231) 946-4772 Page 7...
