Elektrotechnik Schabus SHT 5001 Operating Instructions Manual

Water detector
Hide thumbs Also See for SHT 5001:

Advertisement

Quick Links

Download this manual
OPERATING INSTRUCTIONS
Water detector
SHT 5001
Item number:
400748
• DIN EN 502 top-hat rail housing
• 2 signaling lines, 2 potential-free changeover relays
• 2/24 V battery and 230 V~ mains possible simultaneously
• Priority 230 V : 12V battery = UPS function
All rights, technical changes, errors and misprints reserved.
to the product

Advertisement

loading
Need help?

Need help?

Do you have a question about the SHT 5001 and is the answer not in the manual?

Questions and answers

Related Manuals for Elektrotechnik Schabus SHT 5001

Summary of Contents for Elektrotechnik Schabus SHT 5001

  • Page 1 OPERATING INSTRUCTIONS Water detector SHT 5001 Item number: 400748 to the product • DIN EN 502 top-hat rail housing • 2 signaling lines, 2 potential-free changeover relays • 2/24 V battery and 230 V~ mains possible simultaneously • Priority 230 V : 12V battery = UPS function...
  • Page 2 Intended use The SHT 5001 is a water detector for fi xed installation in a small distri- bution board or fuse box. It has 2 alarm lines, each connected to its own alarm relay, and 2 inputs each for passive water sensors (AC) or mini fl oat...
  • Page 3 The connected sensors and mini fl oat switches are not tested. The SHT 5001 is operated with mains voltage from the public power supply and/or 12 / 24 V DC voltage from external batteries / rechargeable batteries.
  • Page 4 Overview of the connections: All connections are designed as screw terminals. Open the screws, insert the wire or stranded wire and close the screw again. Please do not over- tighten the screws. The wire should not be able to slip out by itself, but the screw terminals do not serve as strain relief! 1 / 2 / 3: L, N, PE Operating voltage for mains operation 100-240 V~ / 50-60Hz...
  • Page 5 Operating voltage (1, 2, 3 or 13, 14) Connect an AC mains voltage of 100 to 240 V and 50 to 60 Hz to 1 L, 2 N and 3 PE. The device is immediately ready for operation. Alternatively, connect the voltage from a 12 V or 24 V rechargeable battery, a battery or a battery-supported on-board power supply to 13 + and 14 -.
  • Page 6 Lengths of up to 300 m with 2x 0.14 mm² LiYY cables have been successfully tested by Elektrotechnik Schabus and represent the real advantage of the new SHT 5001 over its predecessor, which could not handle thicker cables and could only handle cables up to 50 m.
  • Page 7 With the new SHT 5001, 100 m of cable with max. 2x 0.14 mm² can be achieved at the AC input, whereas only 50 m was possible with the previous version.
  • Page 8 TEST button By pressing the TEST button, the SHT 5001 water detector simulates that both detection lines are activated, as if both sensors were detecting water. The connected water sensors or mini fl oat switches are not tested.
  • Page 9 Red SENSOR LED The red SENSOR LED indicates whether and which signaling line is activa- ted. The SENSOR LED lights up when signal line 1 is activated and fl ashes for signal line 2. If both signaling lines have been activated, the LED fl ashes between brigh- ter and darker.
  • Page 10 General Elektrotechnik Schabus GmbH & Co. KG is not liable for damages and/or losses of any kind, e.g. individual or consequential damages, resulting from the fact that no alarm signal is given by the water detector despite changes in the water level.
  • Page 11 Return shipment If your device is defective, please contact us: Phone +49 (0) 80 36 / 67 49 79 - 0 Email info@elektrotechnik-schabus.de Please state your full address and the reason for the return. We will send you a return label by e-mail free of charge (only within Germany). Under no circumstances should you send us an unfree parcel, as we will not accept it! Unauthorized returns that do not constitute a complaint will be charged to you retrospectively.
  • Page 12 QR-Code zum Download oder Nachbestellen unter: Elektrotechnik Schabus GmbH & Co. KG +49 (0) 80 36 / 67 49 79 - 0 Baierbacher Str. 150 MAIL info@elektrotechnik-schabus.de D-83071 Stephanskirchen www.elektrotechnik-schabus.de 400748-AN-SHT5001-240717-SCHABUS...
