Technical Data
Wi-Fi Socket Range Extender
Brief product description:
Eliminate dead spots and expand your
Wi-Fi coverage with the Wi-Fi Socket
Range Extender.
Product Images
Technical Specifications
Standard(s)
Rating
Contact Gap
Switch Type
Terminal Capacity - L & N
RoHS Directive
WEEE Directive
Mounting Box Depth (Min)
Fixing Centres
Features:
• Improved Wi-Fi coverage throughout your home
• Works with all wireless broadband routers
• Easy to install and setup with one touch WPS
• N300 Wi-Fi Technology - Up to 300Mbps data transfer speed
• Perfect for streaming music and videos or playing online games
• Suitable for Computers, Tablets, Mobile Phones,
Games Consoles, TVs
• Single band (2.4Ghz)
• No plug-in adapters - keeps socket free for use
922WR
BS 1363-2l
13 Amp 240V~
3.0mm minimum
Single Pole
3 x 2.5mm², 3 x 4.0mm² & 2 x 6.0mm²
Yes
Yes
25mm
120.6mm
Advertisement
Related Manuals for British General 922WR
Summary of Contents for British General 922WR
- Page 1 • Perfect for streaming music and videos or playing online games • Suitable for Computers, Tablets, Mobile Phones, Games Consoles, TVs • Single band (2.4Ghz) • No plug-in adapters - keeps socket free for use Product Images 922WR Technical Specifications Standard(s) BS 1363-2l Rating 13 Amp 240V~ Contact Gap 3.0mm minimum...
- Page 2 • Windows® XP 32(SP3 or greater),Windows Vista® 32/64, or Windows 7 32/64, Windows 8 32/64, Windows10 32/64; or Mac OS® X v10.5 or above • Internet Explorer® 10.0, Firefox® 20, Google Chrome™ 25, or Safari® 5.1 Line Diagrams 922WR Packaging Information Cat No. Description Packaging Type Barcode...
-
Page 3: Installation Information
Wi-Fi Socket Range Extender Installation Information Safety Warning For your safety, this product must be installed in accordance with local building regulations. If in any doubt, or where required by the law, consult a competent person who is registered with an electrical self-certification scheme. Further information is available online or from your Local Authority. Please read carefully and use in accordance with these safety wiring instructions. -
Page 4: Technical Data
Technical Data Wi-Fi Socket Range Extender + USB Charger Brief product description: Features: Eliminate dead spots and expand your • 1x 2.1A USB outlet for charging your mobile devices Wi-Fi coverage with the Wi-Fi Socket • Improved Wi-Fi coverage throughout your home Range Extender. - Page 5 Wi-Fi Socket Range Extender + USB Charger Wireless Specifications Setup Wiring Specification • WPS - Wi-Fi Protected Setup® or via web browser • 2 gang switched socket with outboard rockers • Red rocker indicators (printed) Wireless Band • Terminal capacity: 3 x 2.5mm², 3 x 4.0mm² or 2 x 6mm² •...
- Page 6 Wi-Fi Socket Range Extender + USB Charger Installation Information Safety Warning For your safety, this product must be installed in accordance with local building regulations. If in any doubt, or where required by the law, consult a competent person who is registered with an electrical self-certification scheme.
