- Page 1 Operating Manual QuickServer FS-QS-2XX0-F Start-up Guide Revision: 3.B Document No.: T18627 Print Spec: 10000005389 (EO) MSAsafety.com...
- Page 2 1000 Cranberry Woods Drive +1 408 964-4443 +31 33 808 0590 Cranberry Township, PA 16066 USA +1 800 727-4377 Email: smc-support.emea@msasafety.com Email: smc-support@msasafety.com For your local MSA contacts, please go to our website www.MSAsafety.com © MSA 2024. All rights reserved...
-
Page 3: Table Of Contents
8.3.1 Using the FS-GUI to Load a Configuration File 8.3.2 Retrieve the Configuration File for Modification or Backup Test and Commission the QuickServer 8.4.1 Accessing the FieldServer Manager MSA Grid - FieldSever Manager Setup Registration Process User Setup Finish Registering the FieldServer... - Page 4 10.5 Internet Browser Software Support Additional Information 11.1 Change Web Server Security Settings After Initial Setup 11.1.1 Change Security Mode 11.1.2 Edit the Certificate Loaded onto the FieldServer 11.2 Change User Management Settings 11.2.1 Create Users 11.2.2 Edit Users 11.2.3 Delete Users 11.2.4 Change FieldServer Password 11.3 QuickServer Part Numbers...
-
Page 5: About The Quickserver
NOTE: For troubleshooting assistance refer to Section Troubleshooting, or any of the troubleshooting appendices in the related driver supplements. Check the MSA Safety website for technical support resources and documentation that may be of assistance. The QuickServer is cloud ready and connects with MSA Safety’s Grid. See Section... -
Page 6: Equipment Setup
2 Equipment Setup Equipment Setup Mounting The gateway can be mounted using the DIN rail mounting bracket on the back of the unit. Physical Dimensions QuickServer Start-up Guide... -
Page 7: Installation
3 Installation Installation DIP Switch Settings 3.1.1 Bias Resistors To enable Bias Resistors, move the BIAS- and BIAS+ DIP switches to the right in the orientation shown above. The bias resistors are used to keep the RS-485 bus to a known state, when there is no transmission on the line (bus is idling), to help prevent false bits of data from being detected. -
Page 8: Termination Resistor
3 Installation 3.1.2 Termination Resistor If the gateway is the last device on the serial trunk, then the End-Of-Line Termination Switch needs to be enabled. To enable the termination resistor, move the TERM dip switch to the right in the orientation shown in above. The termination resistor is also used to reduce noise. -
Page 9: Connecting The R1 & R2 Ports
3 Installation Connecting the R1 & R2 Ports For the R1 Port only: Switch between RS-485 and RS-232 by moving the number 4 DIP Switch left for RS-485 and right for RS-232 (see images in Section 3.1 DIP Switch Settings). The R2 Port is RS-485. -
Page 10: 10/100 Ethernet Connection Port
3 Installation 10/100 Ethernet Connection Port NOTE: Do not use shielded Ethernet cables. The Ethernet Port is used both for Ethernet protocol communications and for configuring the gateway via the Web App. To connect the gateway, either connect the PC to the router’s Ethernet port or connect the router and PC to an Ethernet switch. -
Page 11: Power Up The Gateway
4 Power up the Gateway Power up the Gateway Check power requirements in the table below: Power Requirement for QuickServer External Gateway Current Draw Type QuickServer Family 12VDC 24VDC/AC FS-QS-2XX0-F (Typical) 250mA 125mA NOTE: These values are ‘nominal’ and a safety margin should be added to the power supply of the host system. -
Page 12: Connect The Pc To The Gateway
5 Connect the PC to the Gateway Connect the PC to the Gateway Connecting to the Gateway via Ethernet Connect a Cat-5 Ethernet cable (straight through or cross-over) between the local PC and QuickServer . 5.1.1 Changing the Subnet of the Connected PC The default IP Address for the QuickServer is 192.168.2.101, Subnet Mask is 255.255.255.0. -
Page 13: Setup Web Server Security
6 Setup Web Server Security Setup Web Server Security Login to the FieldServer The first time the FieldServer GUI is opened in a browser, the IP Address for the gateway will appear as untrusted. This will cause the following pop-up windows to appear. •... - Page 14 6 Setup Web Server Security • Additional text will expand below the warning, click the underlined text to go to the IP Address. In the example below this text is “Proceed to <FieldServer IP> (unsafe)”. • When the login screen appears, put in the Username (default is “admin”) and the Password (found on the label of the FieldServer).
-
Page 15: Select The Security Mode
6 Setup Web Server Security Select the Security Mode On the first login to the FieldServer, the following screen will appear that allows the user to select which mode the FieldServer should use. NOTE: Cookies are used for authentication. NOTE: To change the web server security mode after initial setup, go to Section 11.1 Change Web Server Security Settings After Initial Setup. -
Page 16: Https With Own Trusted Tls Certificate
6 Setup Web Server Security 6.2.1 HTTPS with Own Trusted TLS Certificate This is the recommended selection and the most secure. Please contact your IT department to find out if you can obtain a TLS certificate from your company before proceeding with the Own Trusted TLS Certificate option. •... -
Page 17: Setup Network
NOTE: The FieldServer Manager tab (see image above) allows users to connect to the Grid, MSA Safety’s device cloud solution for IIoT. The FieldServer Manager enables secure remote connection to field devices through a FieldServer and its local applications for configuration, management, maintenance. -
Page 18: Using Fs-Gui To Input Network Settings
7 Setup Network Using FS-GUI to Input Network Settings To navigate from the FS-GUI page to the Network Settings page follow the below instructions: • Find the Navigation tree across the left side of the screen. • Click the arrow next to the FieldServer title/CN number to expand the tree. •... -
Page 19: Routing Settings
7 Setup Network Routing Settings The Routing settings make it possible to set up the IP routing rules for the FieldServer’s internet and network connections. • Click the Add Rule button to add a new row and set a new Destination Network, Netmask and Gateway IP Address as needed. -
Page 20: Ethernet 1 Network Settings
7 Setup Network Ethernet 1 Network Settings To change the FieldServer IP Settings, follow these instructions: • Enable DHCP to automatically assign IP Settings or modify the IP Settings manually as needed, via these fields: IP Address, Netmask, Default Gateway, and Domain Name Server1/2. NOTE: If the FieldServer is connected to a router, the IP Gateway of the FieldServer should be set to the same IP Address of the router. -
Page 21: Configuring The Quickserver
8 Configuring the QuickServer Configuring the QuickServer Retrieve the Sample Configuration File The configuration of the QuickServer is provided to the QuickServer’s operating system via a comma-delimited file called “CONFIG.CSV”. If a custom configuration was ordered, the QuickServer will be programmed with the relevant device registers in the Config.csv file for the initial start-up. -
Page 22: Load The Updated Configuration File
8 Configuring the QuickServer Load the Updated Configuration File 8.3.1 Using the FS-GUI to Load a Configuration File • In the main menu of the FS-GUI screen, click “Setup”, then “File Transfer” and finally “Update”. • Browse and select the .csv file, open, then click “Submit”. •... -
Page 23: Retrieve The Configuration File For Modification Or Backup
8 Configuring the QuickServer 8.3.2 Retrieve the Configuration File for Modification or Backup To get a copy of the configuration file for modifying or backing up a configuration on a local computer, do the following: • In the main menu of the FS-GUI screen, click “Setup”, then “File Transfer”. •... -
Page 24: Test And Commission The Quickserver
NOTE: For troubleshooting assistance refer to Section Troubleshooting, or any of the troubleshooting appendices in the related driver supplements and configuration manual. MSA Safety also offers a technical support on the MSA Safety website, which contains a significant number of resources and documentation that may be of assistance. -
Page 25: Msa Grid - Fieldsever Manager Setup
MSA Grid - FieldSever Manager Setup The MSA Grid is MSA Safety’s device cloud solution for IIoT. Integration with the MSA Grid - FieldServer Manager enables the a secure remote connection to field devices through a FieldServer and hosts local applications for device configuration, management, as well as maintenance. - Page 26 9 MSA Grid - FieldSever Manager Setup • To register, fill in the user details, site details, gateway details and account credentials. ◦ Enter user details and click Next ◦ Enter the site details by entering the physical address fields or the latitude and longitude then click Next...
- Page 27 ◦ Enter Name and Description (required) then click Next ◦ Click the “Create an Grid FieldServer Manager account” button ◦ Enter a valid email and click the Create Account button to send a “Welcome to the MSA Grid” invite to the email address entered...
-
Page 28: User Setup
Process), follow the instructions below to set up login details: • The “Welcome to the MSA Grid - FieldServer Manager” email will appear as shown below. NOTE: If no email was received, check the spam/junk folder for an email from notification@fieldpop.io. - Page 29 9 MSA Grid - FieldSever Manager Setup • Click the “Complete Registration” button and fill in user details accordingly. • Fill in the name, phone number, password fields and click the checkbox to agree to the privacy policy and terms of service.
-
Page 30: Finish Registering The Fieldserver
9 MSA Grid - FieldSever Manager Setup Finish Registering the FieldServer • Enter the new Username and Password set up in Section 9.2 User Setup. • Once the device has successfully been registered, a confirmation window will appear. Click the Close button and the following screen will appear listing the device details and additional information auto-populated by the QuickServer. -
Page 31: Login To The Fieldserver Manager
9 MSA Grid - FieldSever Manager Setup Login to the FieldServer Manager After the gateway is registered, go to www.smccloud.net and type in the appropriate login information as per registration credentials. NOTE: If the login password is lost, see the MSA Grid - FieldServer Manager Start-up Guide for recovery instructions. -
Page 32: Troubleshooting
10 Troubleshooting Troubleshooting 10.1 Communicating with the QuickServer Over the Network • Confirm that the network cabling is correct. • Confirm that the computer network card is operational and correctly configured. • Confirm that there is an Ethernet adapter installed in the PC’s Device Manager List, and that it is configured to run the TCP/IP protocol. -
Page 33: Taking A Fieldserver Diagnostic Capture
10 Troubleshooting 10.2 Taking a FieldServer Diagnostic Capture When there is a problem on-site that cannot easily be resolved, perform a Diagnostic Capture before contacting support. Once the Diagnostic Capture is complete, email it to technical support. The Diagnostic Capture will accelerate diagnosis of the problem. -
Page 34: Led Functions
10 Troubleshooting 10.3 LED Functions 10.4 Factory Reset Instructions For instructions on how to reset a FieldServer back to its factory released state, see ENOTE FieldServer Next Gen Recovery. 10.5 Internet Browser Software Support The following web browsers are supported: •... -
Page 35: Additional Information
11 Additional Information Additional Information 11.1 Change Web Server Security Settings After Initial Setup NOTE: Any changes will require a FieldServer reboot to take effect. • Navigate from the QuickServer landing page to the FS-GUI by clicking the blue “Diagnostics” text on the bottom of the screen. -
Page 36: Edit The Certificate Loaded Onto The Fieldserver
11 Additional Information 11.1.2Edit the Certificate Loaded onto the FieldServer NOTE: A loaded certificate will only be available if the security mode was previously setup as HTTPS with own trusted TLS certificate. • Click Security in the Navigation panel. • Click the Edit Certificate button to open the certificate and key fields. •... -
Page 37: Change User Management Settings
11 Additional Information 11.2 Change User Management Settings • From the FS-GUI page, click Setup in the Navigation panel. • Click User Management in the navigation panel. NOTE: If the passwords are lost, the unit can be reset to factory settings to reinstate the default unique password on the label. -
Page 38: Create Users
11 Additional Information 11.2.1Create Users • Click the Create User button. • Enter the new User fields: Name, Security Group and Password. ◦ User details are hashed and salted NOTE: The password must meet the minimum complexity requirements. An algorithm automatically checks the password entered and notes the level of strength on the top right of the Password text field. -
Page 39: Edit Users
11 Additional Information 11.2.2Edit Users • Click the pencil icon next to the desired user to open the User Edit window. • Once the User Edit window opens, change the User Security Group and Password as needed. • Click Confirm. •... -
Page 40: Delete Users
11 Additional Information 11.2.3Delete Users • Click the trash can icon next to the desired user to delete the entry. • When the warning message appears, click Confirm. 11.2.4Change FieldServer Password • Click the Password tab. • Change the general login password for the FieldServer as needed. NOTE: The password must meet the minimum complexity requirements. -
Page 41: Quickserver Part Numbers
11 Additional Information 11.3 QuickServer Part Numbers Interface Connections QuickServer RS-232 RS-485 M-Bus Ethernet LonWorks FS-QS-2X10-F FS-QS-2X20-F FS-QS-1011-F FS-QS-1211-F FS-QS-1221-F FS-QS-1240-F FS-QS-1241-F FS-QS-1A50-F FS-QS-1A51-F FS-QS-1B50-F FS-QS-1B51-F FS-QS-1C50-F FS-QS-1C51-F TX/Rx/GND +/-/Frame Ground 10/100 Base T FTT10 KNX/EIB TP1 NOTE: The 2X10-F and 2X20-F are the same hardware model with 1 port that can be either RS-232 or RS-485. The 2X10-F has a default setting of RS-485 while the 2X20-F has a default setting of RS-232. -
Page 42: Specifications
11 Additional Information 11.5 Specifications FS-QS-2XX0-F One 3-pin Phoenix connector with: RS-485/RS-232 (Tx+ / Rx- / gnd) One 3-pin Phoenix connector with: RS-485 (+ / - / gnd) Electrical Connections One 3-pin Phoenix connector with: Power port (+ / - / Frame-gnd) One Ethernet 10/100 BaseT port Input Voltage: 12-24VDC or 24VAC Current draw: 24VAC 0.125A... -
Page 43: Fieldserver Manager Connection Warning Message
11 Additional Information 11.7 FieldServer Manager Connection Warning Message • If a warning message appears instead of the page as shown below, follow the suggestion that appears on screen. ◦ If the FieldServer cannot reach the server, the following message will appear •... -
Page 44: Limited 2 Year Warranty
Limited 2 Year Warranty MSA Safety warrants its products to be free from defects in workmanship or material under normal use and service for two years after date of shipment. MSA Safety will repair or replace any equipment found to be defective during the warranty period.
