30RAP010-150 (60 Hz)
30RAP070-150 (50 Hz)
with Puron
®
10 to 150 Nominal Tons (60Hz)
70 to 150 Nominal Tons (50Hz)
The AquaSnap chiller is an effective all-
in-one package that is easy to install and
easy to own. AquaSnap chillers operate
quietly and efficiently. Value-added
features include:
• Rotary scroll compression
• HFC Puron
• Low-sound AeroAcoustic™ fan system
• Easy to use ComfortLink controls
• Optional integrated hydronic pump
package (60 Hz only) with VFD
(variable frequency drive) compatible
motors, with optional VFD on size 070-
150 models
a30-4826
• Coil design flexibility—Microchannel
coil technology available on all units,
and RTPF coil technology available on
sizes 070-150
• Accessory fluid storage tank on size
010-060 models
• Optional digital scroll compressors on
size 010-090 models
Features/Benefits
Carrier's superior chiller
design provides savings at
initial purchase, at installa-
tion, and for years afterward.
Costs less right from the start
Carrier's AquaSnap chillers feature a
compact, all-in-one package design that
installs quickly and easily on the ground
or the rooftop. The optional pump and
hydronic components (60 Hz only) are
already built in; this costs less than buy-
ing and installing the components indi-
vidually. The chiller's fully integrated and
pre-assembled hydronic system (60 Hz
only) installs in minutes. No other chiller
in this class installs so easily and inex-
pensively. The preassembled and inte-
grated hydronic module utilizes top-qual-
ity components and pumps to ensure
years of reliable operation.
®
AquaSnap
Air-Cooled Chillers
Refrigerant (R-410A)
(35 to 528 Nominal kW)
(246 to 528 Nominal kW)
®
refrigerant (R-410A)
Form 30RAP-11PD
