- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 223471KE (B1-B3) Eastern King Bed REVISION 0 : 09/15/2024 COASTERFURNITURE.COM PAGE 1 OF 6...
-
Page 2: Assembly Tips
B3 (BOX 3) 4PCS BED RAIL BED SLAT 2PCS BED SLAT SUPPORT 8PCS WITH LEVELER 223471KE (B1) 223471KE (B2) FROM BOX 1 FROM BOX 2 HEADBOARD FOOTBOARD COMPLETE NOTE: Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item. -
Page 3: Hardware Identification
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the store immediately. 2. This product is for home use only and not intended for commercial establishments. HARDWARE IDENTIFICATION Z-B1 (BOX 1) - HARDWARE PACK IS LOCATED IN 223471KE (B1) LONG BOLT FLAT WASHER... - Page 4 223471KE(B1-B3) ITEM: ASSEMBLY INSTRUCTIONS STEP 1 * BACK V IEW STEP 2 PAGE 4 OF 6 COASTERFURNITURE.COM...
- Page 5 223471KE(B1-B3) ITEM: ASSEMBLY INSTRUCTIONS STEP 3 STEP 4 PAGE 5 OF 6 COASTERFURNITURE.COM...
- Page 6 223471KE(B1-B3) ITEM: ASSEMBLY INSTRUCTIONS STEP 5 STEP 6 COMPLETE PAGE 6 OF 6 COASTERFURNITURE.COM...
- Page 7 223471 KE(B1-B3) ITEM: Inner Size : 81.50''W X 77.00''D 83.75" 18.00" 17.25" 77.00" 78.75" 4.00" 57.00" 8.00" 13.50" 6.00" 82.00" 78.25" 86.00" 81.50" Note: Dimension tolerance ±5% COASTERFURNITURE.COM...
