- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 223476 Bench REVISION 0 : 09/15/2024 COASTERFURNITURE.COM PAGE 1 OF 3...
- Page 2 223476 ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
- Page 3 223476 ITEM: ASSEMBLY INSTRUCTIONS STEP 1 DO NOT TIGHTEN THE BOLTS DO NOT TIGHTEN THE BOLTS STEP 2 TIGHTEN ALL THE BOLTS TIGHTEN ALL THE BOLTS STEP 3 COMPLETE COASTERFURNITURE.COM PAGE 3 OF 3...
- Page 4 223476 ITEM: 50.00" 17.00" 18.00" 6.50" 4.00" 46.50" 13.50" 16.50" 49.50" Note: Dimension tolerance ±5% COASTERFURNITURE.COM...
