- Page 1 FLYWHEEL HORSEPOWER 246 kW 330 HP @ 1850 rpm OPERATING WEIGHT PC400-7: 41400 – 42250 kg 91,270 – 93,140 lb PC400LC-7: 42400 – 43300 kg 93,480 – 95,460 lb PC400-7 PC400LC-7 Photo may include optional equipment. YDRAULIC XCAVATOR...
-
Page 2: Operating Weight
PC400-7 PC400-7 HYDRAULIC EXCAVATOR Y D R A U L I C X C A V A T O R FLYWHEEL HORSEPOWER ALK- ROUND Harmony with Environment 246 kW 330 HP @ 1850 rpm ● Economy mode saves fuel consumption (reduced by approx. 20%). OPERATING WEIGHT ●... - Page 3 PC400-7 PC400-7 HYDRAULIC EXCAVATOR Y D R A U L I C X C A V A T O R RODUCTIVITY EATURES High Production and Low Substantially Improved Fuel Consumption Stability High production and low fuel consumption are Improved lateral stability is achieved by increasing the achieved through the following two operation counterweight (330kg 730lb) and improving the balance of the modes:...
- Page 4 PC400-7 PC400-7 HYDRAULIC EXCAVATOR Y D R A U L I C X C A V A T O R ORKING NVIRONMENT Safety Features OPG (FOG) capable with The cab interior optional bolt-on top guard. is spacious and provides a comfortable working environment…...
-
Page 5: Maintenance
PC400-7 PC400-7 HYDRAULIC EXCAVATOR Y D R A U L I C X C A V A T O R AINTENANCE EATURES Self-Diagnostic Monitor VALUE ADDED OPTIONS The PC400-7 features the most advanced diagnostics Multi-Function Color Monitor system in the industry. The Komatsu exclusive system identifies maintenance items, reduces diagnostic times, indicates oil and filter replacement hours and displays error codes. -
Page 6: Specifications
PC400-7 PC400-7 HYDRAULIC EXCAVATOR Y D R A U L I C X C A V A T O R PECIFICATIONS DIMENSIONS Arm Length 2400 mm 7'10" 2900 mm 9'6" 3380 mm 11'1" 4000 mm 13'1" Overall length 11905 mm 39'1"... - Page 7 LIFTING CAPACITY LIFTING CAPACITY A: Reach from swing center Cf: Rating over front A: Reach from swing center Cf: Rating over front B: Bucket hook height Cs: Rating over side B: Bucket hook height Cs: Rating over side C: Lifting capacity : Rating at maximum reach C: Lifting capacity : Rating at maximum reach...
- Page 8 LIFTING CAPACITY WITH LIFTING MODE ON MULTI-FUNCTION COLOR MONITOR LIFTING CAPACITY WITH LIFTING MODE ON MULTI-FUNCTION COLOR MONITOR A: Reach from swing center Cf: Rating over front A: Reach from swing center Cf: Rating over front B: Bucket hook height Cs: Rating over side B: Bucket hook height Cs: Rating over side...
-
Page 9: Standard Equipment
STANDARD EQUIPMENT • Alternator, 35 Ampere, 24V • Engine, Komatsu SAA6D125E • Track guiding guard, center section • Auto-Decel • Engine overheat prevention system • Track roller • Automatic engine warm-up system • Fan guard structure —PC400-7, 7 each side •...
