7" MOTORISED TOUCHSCREEN DVD MULTIMEDIA
PLAYER with BLUETOOTH & NAVIGATION
SCREEN
GPS NAVIGATION
LCD MONITOR
DVD/CD/MP3
GENERAL
- WVGA Digital TFT LCD (800 x 480 Pixels)
- CORTEX A9 Processor
- WinCE 6.0 Operating System
- 7" Touch Screen Dynamic User Interface
- Motorised Monitor with Tilt/Close Functions
- ISO 1-DIN Mounting
- Reversing Camera Input
- Park Brake Trigger
- Steering Wheel Control Ready (Resistor Type)
- 4.1 Ch Line Out: Front, Rear, Subwoofer
- RCA Line In (Rear)
- Video Line Out
- Video Line In (Rear)
- Speaker Impedance 4-8 Ohm
- Dimensions: 178W x 50H x 165D mm
- RMS Power 4 Ch x 25 Watts
- Max Power 4 Ch x 45 Watts
- 12 Volt DC (10.5-15.8V) Negative Ground
AUDIO CONTROL
- Rotary Volume Encoder
- 3 Band EQ
- Loud / Mute
All manuals and user guides at all-guides.com
AX1577NAV
BLUETOOTH
FRONT PANEL
TUNER
- PLL Synthesized AM/FM Stereo
- Xtreme Long Range Tuner
- Interference Absorption Circuit
- FM 87.5-108 MHz; AM 522-1620 KHz
- 30 Station Presets
- 18FM/12AM Memory
- Station Seek / Scan / Auto Store
- Local / Distant Control
- Digital Clock
- 12/24 Hour Mode
MULTIMEDIA
- USB Input (Front Panel)
- 2 AV-IN (Front Panel & Rear RCA)
- Video RCA OUT (Rear)
- Reversing Camera Input (Rear)
NAVIGATION
- Built-In IGO Navigation
- 30 Day Map Upgrade
Designed as a complete vehicle in-
fotainment system, integrating an ar-
ray of technologies & media sources.
The generous 7" LCD user interface
is
motorised,
into a compact single DIN chassis.
• 7 Inch LCD Display
• Reversing Camera Input
• Motorised Monitor
DVD/CD PLAYER
- Preset EQ (Classic, Pop, Rock, Flat)
- DVD/VCD/CD/CD-ROM/MP3/DIVX/
WMA/JPEG
- PAL/NTSC Video System
- Auto Loading
- Electronic Shock Protection
- Zoom/Slow/Multi-Angle/Last Position Memory
- Intro/Repeat/Random Play/Track Up-Down
- Select Folder/Track/File Search
BLUETOOTH
- Bluetooth in Phone Mode
- Bluetooth Antenna
- Phone Contacts / History
- Dial Pick-Up/Call Transfer
- Audio Streaming (A2DP)
INCLUDED
- Remote Control
- External Microphone
- External GPS Antenna
- Micro SD Map Card
- ISO Wiring Harness
allowing
retraction
2
YEAR
WARRANTY
Advertisement
Table of Contents
Related Manuals for Axis Car Audio AX 1577NAV
Summary of Contents for Axis Car Audio AX 1577NAV
- Page 1 All manuals and user guides at all-guides.com AX1577NAV 7” MOTORISED TOUCHSCREEN DVD MULTIMEDIA PLAYER with BLUETOOTH & NAVIGATION Designed as a complete vehicle in- fotainment system, integrating an ar- ray of technologies & media sources. The generous 7” LCD user interface motorised, allowing retraction...
-
Page 2: Safety Precautions
All manuals and user guides at all-guides.com Safety Precautions t h e f u s e Please read through these power cord instructions so you will know how to this manual in a safe place for Only connect the unit to a 12-volt power Please contact your nearest dealer if one of the following symptoms is experienced:... -
Page 3: Table Of Contents
All manuals and user guides at all-guides.com Contents Safety Precautions ........1 Before using ..........3 Video Setup Front Panel Rotate Pictures Zoom Bluetooth Mode ........15 Basic Operations ........8 Mute Power On / Off Playing Source Selection Settings ...........17 EQ Menu Select Preset Equalizer Radio Mode ..........10 Select Radio as Playing Source Other Modes ..........20... -
Page 4: Before Using
All manuals and user guides at all-guides.com Before using Front Panel MUTE Operation Description TFT Display Open: Dimmer Mode; Press TFT Display Close: Time Mode. Press and hold TFT Display Open: TFT Display Off Press Next Press and hold Scan(Frequency rom High to Low) Press Previous Press and hold... -
Page 5: Auxiliary Lcd
All manuals and user guides at all-guides.com Before using Operation Description AV IN2 jack Press Eject Press TFT Display Close/Open TFT Display Open: TILT+(Step) ; Press TFT Display Close: Previ w. TFT Display Open: TILT+(Continuation); Press and hold TFT Display Close: Scan and Auto Store. TFT Display Open: TILT-(Step);... - Page 6 All manuals and user guides at all-guides.com Before Using Remote Control OPEN/CLOSE DVD MENU SLOW...
- Page 7 All manuals and user guides at all-guides.com Before Using Operation Description Press Change Current Source. Press TFT Display Close/Open. Press Press DVD Title. Press Press Press Navi ation/Power On Press Dimmer Mode Press and hold TFT Display Off Press Press Slow Play / Dial / Receive call Press ]-Play Photo:UP-DOWN Mirror;...
- Page 8 All manuals and user guides at all-guides.com Before Using Notes on Remote Control Usage Uninstall Battery Install Battery PULL OUT PUSH IN...
-
Page 9: Basic Operations
All manuals and user guides at all-guides.com Basic Operations Parking Brake Inhibit Playing Source Selection Press the [ SRC ] button to change between the brake switch, the display on the available playing sources. The playing mode TFT monitor will when is displayed on the screen. -
Page 10: Select Preset Equalizer
All manuals and user guides at all-guides.com Basic Operations Select Preset Equalizer Adjust Fader/Balance Adjust EQ Parameters fader range: 0 to 7. fader range: 0 to 7. 0 to 7. to 7. Notes:... -
Page 11: Radio Mode
All manuals and user guides at all-guides.com Basic Operations Radio Mode Set Date /Time Tuner TFT Display · Set Date ] or [ ] to set year, month · Set Time Mode · Set Time istant ] or [ ] to set hour and ·... -
Page 12: Select Radio As Playing Source
All manuals and user guides at all-guides.com Radio Mode Select Radio as Playing Source Preset Station Open the Source Menu and then touch stations he unit can store 30 stations Select One Radio Band Intro/Scan or touch the [ ] icon on the user interface Press the [ ] icon to intro. -
Page 13: Touch Screen Controls
All manuals and user guides at all-guides.com Playback Mode Load a Disc You can play video, audio or images stored on the following discs: Note: Connect an USB Device Eject a Disc Press the [ Remove an USB Device Touch Screen Controls Play/Pause information Controlling Playback... -
Page 14: Previous/Next
All manuals and user guides at all-guides.com Playback Mode Previous/Next ] Repeat single: Play the current ] / [ ] icon on the screen to skip ] Repeat all: Play all in the all Search for a Folder ] Repeat folder: Play all in the current For Video Files Repeat A-B For Audio Files... -
Page 15: Video Setup
All manuals and user guides at all-guides.com Playback Mode Select Subtitle Language Elapsed Time 00:01:20 00:30:17 ] repeatedly to select a Direct Track Entry icon on screen control to display the direct Video Setup ] to access video setup mode, touch [ ] or [ Rotate Pictures... -
Page 16: Bluetooth Mode
All manuals and user guides at all-guides.com Bluetooth Mode You can make or receive phone calls with Disconnect Bluetooth Device Pair the Bluetooth-enabled Devices Note: Make a Call following list: [Missed calls] the Bluetooth device ID in the [Received calls] pairing list. -
Page 17: Adjust Bluetooth Settings
All manuals and user guides at all-guides.com Bluetooth Mode Music Mode A2DP AVRCP Note: You can select to receive calls Adjust Bluetooth Settings... -
Page 18: Display System
All manuals and user guides at all-guides.com Settings Display System Adjust General Settings General settings Options Description Europe East Europe Enter Enter Calibration When the touch operation is no sensitive calibrate the touch screen through calibration setting function. Adjust the response positions of the touch panel as followings: 1. -
Page 19: Adjust Sound Settings
All manuals and user guides at all-guides.com Settings Adjust Sound Settings Sound settings Options Description Flat On/Off Reverse Mute On/Off Adjust Video Settings Video settings Options Description Normal Mirror Night Normal Parking On / Off above warning screen will prevent the driver watching images. Adjust Disc Rating DVD rating Options... -
Page 20: Device Connections
All manuals and user guides at all-guides.com Settings Adjust Volume Settings ] or [ Adjust Reset Settings Language settings Description Reset Factory Reset Volume Reset Video Device connections Notes of connection Never pass the yellow power cord through the into the engine compartment... -
Page 21: Other Modes
All manuals and user guides at all-guides.com Other Modes Listen to Other Devices S t e e r i n g W h e e l C o n t r o l You can connect an external audio/video device Programming Reset MUTE... -
Page 22: Device Connections
All manuals and user guides at all-guides.com Device connections Par Brake Cable Connections Pink Wire Reverse Driving Cable Connections... -
Page 23: Installation And Uninstall
All manuals and user guides at all-guides.com Installation and uninstall Notes of installation Remove the unit manufactured for this unit Dash Board amage to electrical components such as the laser unit more than 30 degree vertically may positive first and then the negative Trim ring installation Installation procedures Trim ring uninstall... - Page 24 All manuals and user guides at all-guides.com General Reference Supply Voltage ..............12V(DC) Operating Voltage Range ............. 11 - 16V(DC) Max Operating Current ................15A ..........Car Battery Negative Pole Dimensions(WXHXD) ............178X50X(165+25)mm Weight(main unit) ..................2.3kg Signal Noise Ratio .................. Residual Noise Sensitivity(S/N=30dB) ..........Frequency Response(±3dB) .............
-
Page 25: Region Code
All manuals and user guides at all-guides.com Supported formats: · WMA v9 or earlier · Directory nesting up to a maximum of 8 levels · Number of albums/ folders:maximum 99 · Number of tracks/ titles:maximum 999 · ID3 tag v2. 0 or later Unsupported formates: shown in the display. -
Page 26: Troubleshooting
All manuals and user guides at all-guides.com Troubleshooting Problem Cause Corrective action General Unit fuse blown. Install new fuse with correct rating. Car battery fuse blown. Install new fuse with correct rating. Unit can not power on Illegal operation Reset the unit. Battery depleted. -
Page 27: Wire Connections
All manuals and user guides at all-guides.com Wire Connections... - Page 28 All manuals and user guides at all-guides.com AX1577NAV...
