KOOLMORE
R E S E R V E
718-576-6342
support@koolmore.com
USER MANUAL
KOOLMORE RESERVE
WINE COOLER
PANEL READY
Models:
KM-CW28DZ-BPR, KM-CW28DZ-WPR, KM-CW46DZ-BPR
KM-CW46DZ-BPR, KM-CWB24-BPR, KM-CWB24-WPR
Before using, please read the operating instructions carefully to
ensure proper application and achieve satisfactory results.
@©0 L,I,}00@>
Advertisement
Table of Contents
Related Manuals for KoolMore KM-CW28DZ-BPR
Summary of Contents for KoolMore KM-CW28DZ-BPR
- Page 1 USER MANUAL R E S E R V E KOOLMORE RESERVE WINE COOLER PANEL READY Models: KM-CW28DZ-BPR, KM-CW28DZ-WPR, KM-CW46DZ-BPR KM-CW46DZ-BPR, KM-CWB24-BPR, KM-CWB24-WPR @©0 L,I,}00@> 718-576-6342 Before using, please read the operating instructions carefully to support@koolmore.com ensure proper application and achieve satisfactory results.
- Page 2 Stay informed with the latest information for your KoolMore Reserve Appliance. If you need any assistance or have questions, our customer support team is here to help.
- Page 3 LO[fj!ftffllf !Rim INTRODUCTION Leave these instructions with the appliance. INSTALLER: Read this manual carefully before installing and starting up, and save it for future use. If you CUSTOMER: pass on the product to another person, hand over this instruction manual along with it. Retain your sales receipt or canceled check.
- Page 4 LO[fj!ftffllfl:f!Rim SAFETY To reduce the risk of fire, electrical shock or injury when using the appliance, follow basic precautions, including the following: WARNINGS If you receive a damaged product, immediately contact your dealer or builder. Do not install or use a damaged appliance.
- Page 5 Disconnect the power cord from the electrical outlet. Air the room in which the appliance is located for several minutes and contact the Customer Service for advice. The more coolant there is in an appliance, the larger the room it should be installed in. In the event of a leakage, the appliance is in a small room, there is the danger of combustible gases building For every ounce of coolant, at least 325 cubic feet of room space is required.
- Page 6 Do not cover shelves with aluminum foil or any other shelf material which may prevent air circulation. In the event of a power outage, minimize opening the door. Never clean appliance parts with flammable fluids. These fumes can create a fire hazard or explosion.
-
Page 7: Product Features
PRODUCT FEATURES Built-in or Free-standing installation with single, dual or three temperature zone, depending on your model. Continuously variable electronic temperature control with digital display and SMARTLIGHT touchpad input. Temperature can be set from 5° to 20°C (41° to 68°F) for either compartment and can be displayed in either Fahrenheit or Celsius degrees. -
Page 8: Installation
INSTALLATION Before First Use: Remove all exterior and interior packing. Clean the interior surface with lukewarm water • using a soft cloth. The unit may have residual odors at first, they will disappear as the unit cools. • Important: Before connecting the Wine Cellar to the power source, let it stand upright for approximately 24 hours. -
Page 9: Electrical Connection
BUILT-UNDER INSTRUCTIONS Make sure your installation does not block the front ventilation grille. If the unit is fully integrated to be installed for fitting kitchen plinth, make sure that the ventilation gaps in the plinth are at least 300 square centimeters and remove the ventilation grilles, so that warm air can disperse unhindered. -
Page 10: Extension Cord
EXTENSION CORD Because of potential safety hazards under certain conditions, it is strongly recommended that you do not use an extension cord with this appliance. However, if you must use an extension cord it is absolutely necessary that it be a UL/CUL-Listed, 3-wire grounding type appliance extension cord having a grounding type plug and outlet and that the electrical rating of the cord be 115 volts and at least 10 amperes. - Page 11 OVERLAY PANEL DOOR DESIGN GUIDE Door panel preparation Depending on the wine cellar model prepare the overlay panel to the dimensions shown below. Then attach the handle to the overlay panel by using the flat head screws and drive the screws flush with the panel if needed.
-
Page 12: Operation
OPERATION OPERATING YOUR APPLIANCE The Wine Cellar should be placed in a position where the ambient temperature is between 60 °F and 95°F. If the ambient temperature is above or below this range, the performance of the unit may be affected. For example, placing your unit in extreme cold or hot conditions may cause interior temperatures to fluctuate. - Page 13 The interior light indicator will flash when the multi-key function is selected. To perform the multi-key function, lightly touch and hold the first key, then touch the rest key for at least 5 seconds and then release all keys. Setting the Temperature Control The unit has two separate temperature zones.
-
Page 14: Settings Mode
function, lightly touch and hold the first key, then touch the rest key for at least 5 seconds and then release all keys. Setting the Temperature Control The unit has two separate temperature zones. The temperature of both zones can be set between 41°F and 68°F. -
Page 15: Temperature Display
key twice. Use the UP and DOWN keys to select the brightness of the interior lighting when the door is close. When the door is open, the interior lighting returns to its normal level. LO: off when the door is close or open L1: dimmest setting L2: medium setting L3: brightest setting (default) (same level as when door is... -
Page 16: Door Alarm
After a prolonged power outage. When a large number of items are added to the unit simultaneously or when there's a significant influx of ambient air due to rearranging or removing items. When the appliance's door is not properly closed. If there is a fault with the appliance itself. -
Page 17: Operating Noises
Shabbos mode can be canceled by repeating the same process, and it will automatically turn off after 96 hours. ECO DEMO MODE Eco Demo mode can be activated for exhibition or salesroom purposes. In this mode, the compressor and all fan motors are switched OFF, while the lights remain ON. For models with LED Displays, you can activate Eco Demo mode by touching and holding the "UP,"... -
Page 18: Wine Serving Temperature Chart
with walls, furniture, or other tubing. In open-plan kitchens or partition walls, the operating noise may be more noticeable due to the surrounding architecture. DEFROSTING/ HYGROMETRY / VENTILATION The unit is equipped with an automatic defrost system that operates during the "Off-cycle." During defrosting, condensate collects in the drain trough behind the rear wall of the unit, and some of it flows through the drainage hole into the drip tray near the compressor. - Page 19 RECOMMENDED SERVING TEMPERATURES FOR VARIOUS WINE STYLES •F Wine Style Champagne NV, Sparkling, Spumante 43 Dry White Semillon, Sauvignon Blanc Champagne Vintage Dry White Chardonnay Dry White Gewurztraminer, Riesling, Pinot grigio Sweet White Sauternes, Barsac, Montbazillac, Ice Wine, Late Harvest Beaujolais Sweet White Vintage: Sauternes...
-
Page 20: Maintenance
MAINTENANCE WARNING To avoid possible injury due to electric shock, disconnect the power cord or turn off power at the circuit breaker panel or fuse box before cleaning the appliance. Clean only the parts of the appliance listed in this manual. Clean them only in the manner specified. Do not use a steam cleaner to clean this appliance. -
Page 21: Power Failure
Wash the shelves with a mild detergent solution. Wring excess water out of the sponge or cloth when cleaning any area of the controls. The sealing gasket around the door must be cleaned regularly to prevent discoloration and prolong service life. Use clean water. After cleaning the sealing gasket, check that it continues to provide a tight seal. - Page 22 possible condensation, mold or odors forming. The appliance should be installed in the coolest area of the room, away from heat producing appliances, and out of the direct sunlight. Ensure that the unit is adequately ventilated. Never cover air vents. Clean dust and dirt from the condenser at regular intervals.
-
Page 23: Troubleshooting
TROUBLESHOOTING PROBLEMS WITH YOUR APPLIANCE You can solve many common problems easily, saving you cost of a possible service call. Try the suggestions below to you can solve the problem before calling customer service. PROBLEM POSSIBLE CAUSE REMEDY Nothing works. Appliance does not Appliance is not connected to a Connect the appliance. - Page 24 crackling noises. The appliance is not properly Level the appliance with the level. adjustable feet.
- Page 25 The door will not close properly. The appliance not properly Level the appliance with the level. adjustable feet. door was reversed and not Level the appliance with the adjustable feet. properly re-installed. The gasket is dirty. Check the door hinge and reassemble correctly.
-
Page 26: Limited Warranty
Should you discover any such defect within the warranty period, Koolmore Supply, Inc., reserves the right to repair or replace the product without charge, or to cover the cost of replacement parts and repair labor needed to correct defects present at the time of purchase or resulting from regular usage, when the appliance has been installed, operated, and maintained as per the instructions provided.
