- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. ASKO D3152XLWH Owner's Manual Shop genuine replacement parts for ASKO D3152XLWH Find Your ASKO Dishwasher Parts - Select From 210 Models -------- Manual continues below part list --------...
- Page 2 Available Replacement Parts for ASKO D3152XLWH 428814 SPACERS...
- Page 3 Use & Care Guide Dishwasher ASKO D3152XL...
- Page 4 And this is what we try to give you. When you buy an ASKO product, we want you to feel assured that the inside is as good as the outside and that the ethics and morals on which we built this machine are just as high as the quality and performance you get from it.
-
Page 5: Table Of Contents
Contents Page Options Contents Temperature Drying Before doing your first wash Delayed start Read the directions of use Express Take care with certain materials Upper basket Check the door Press start Check water hardness level Machines with water softener Changing options Do you want to load more dishes? Safety If the machine is switched off at... - Page 6 Rinse aid Screw the dishwasher into place Pour in rinse aid Select dosage Fitting fixed kick-plate Salt Fitting strip seal Pour in salt (on floor plinth covering plate) NB! Not all models Settings Setting water hardness Service & guarantee Fault indications Own comments 34-35 Troubleshooting...
-
Page 7: Before Doing Your First Wash
Before doing your first wash Read the directions of use Do you have a machine with a Read the directions of use before starting to water softener? use your machine, especially the Safety, If you are unsure whether your machine has a Child Safety and Basic Course sections. -
Page 8: Safety
Safety General Overfill protection • Read and keep the directions for use! The overfill protector starts pumping out • Installation of water, drainage and elec- water and closes off the water intake if the tricity must be carried out by a qualified machine’s water level exceeds the normal professional. -
Page 9: Child Safety
Child Safety! Child safety lock Child-safe dishwashing A child safety lock is fitted to prevent children • Use the knife basket, or knife holder, for from opening the door of the dishwasher. all long/sharp items. 1. Activate the child safety lock by pressing in the door latch and turning the screw slot (up in •... -
Page 10: Parts Of The Dishwasher
Parts of the dishwasher* 1. Knife basket 2. Upper basket 3. Spray arms 4. Lower basket 5. Cutlery basket 6. Rinse aid dispenser 7. Dishwasher detergent compartment 8. Main switch 9. Program panel 10. Filter 11. Type plate * Details may differ depending on model and market! Technical information Height... -
Page 11: Baskets
Baskets* Upper basket 1. Wine glass shelf 2. Cup shelf 3. Knife stop 4. Folding door 5. Knife basket *Details may differ depending on the model and market! Lower basket Cutlery basket Knife basket... -
Page 12: Control Panel
Control panel 6. 1/2 load 1. Program selector 7. Display window 2. Temperature options 8. Rinse aid indicator 3. Drying options 9. Start/stop 4. Delayed Start 1-9h 10. Salt indicator (applies to dishwashers 5. Express with water softeners) Dispenser 1. Compartment for main wash dish- washer detergent 2. -
Page 13: Basic Course
Basic Course Below are step by step instructions to help you achieve the best possible dishwashing results. Load the baskets correctly! Thanks to Super Cleaning System™, you do not need to rinse the dishes under Detergent dosage running water. Convenient and environmentally friendly! Scrape off large Detergent should be dispensed in accordance food particles before loading the machine. -
Page 14: Select Program
Quick wash Press the main power switch Select Quick Wash if the dishes are very lightly soiled. This program is used for very lightly soiled glass and china, e.g. coffee Select program cups. Select a program by pressing the program selector one or more times until the required Rinse &... -
Page 15: Options
Options The machine will now count down the time Select options each hour until the machine starts, and then show the remaining wash time in the To select an option, press one of the option display window. buttons • To cancel Delayed start, press and hold the Start/Stop button for 3 seconds. -
Page 16: Press Start
Press Start/Stop After dishwashing The dishwasher will now start. It manages Once the machine has finished, it is the entire wash automatically. Ensure that drawing a very small amount of power. the door is properly closed or the machine Should you wish to discontinue this switch will not start. -
Page 17: Eco-Dishwashing
Eco-dishwashing Only wash with a full load Waiting to run the wash until the machine is full saves energy. Wash at a lower temperature If the load is only lightly soiled, you can lower the temperature. Select program with Eco drying If you select an Auto/Heavy/Normal or Delicate Wash program with Eco dry, this will save energy. -
Page 18: Fragile Dishes
Fragile dishes A number of household goods are not suit- Wood able for machine washing. There can be Wooden articles should only be machine many reasons for this. Certain materials washed if they are labelled as dishwasher cannot withstand intense heat, others can proof. -
Page 19: Standard Program
Standard program Consumption Time Option Program procedure Energy kWh Min. (appr.) Water Program Main Final Cold Warm Cold Warm Temp. Pre- Drying wash Rinses rinse water water Litres water water °C wash °C °C (20°C) (60°C) (20°C) (60°C) Auto wash 0 / 1 40-60 2 / 3 X 0,8-1,4 0,7-1,0 115-185 95-160... -
Page 20: Display
Display Display window When you have selected the program, the display shows the length of time the program took the last time it was used. When you have started the machine, the display window shows how much of the program time remains. This time can vary a little from one occasion to another depending on the temperature of the inlet water, the amount of dishes, the... -
Page 21: Cleaning
Cleaning Cleaning The dishwasher’s inner container is made of stainless steel and is kept clean through normal use. However, if you have calciferous (hard) water, lime deposits can form in the dishwasher. In this case, run a normal wash program with two tablespoons of citric acid in Coarse the dishwasher detergent compartment. -
Page 22: Spray Arms
If you still cannot start the machine and a humming noise can be heard, then the overfilling protection has been activated. • Shutoff the water • Remove the plug from the wall socket • Call Service CAUTION! Do not forget to replace the pump plug. Spray arms The holes and bearings can occasionally become clogged. -
Page 23: Rinse Aid
Rinse aid Pour in rinse aid Select dosage Rinse aid, helps quicken the drying The dispenser is usually set at 1= soft water. process. However, depending on the water hard- ness, it may be necessary to change the Machines with indicator on the panel dosage. -
Page 24: Salt
Salt (Salt dispensers are not used in Australia or New Zealand machines) Pour in salt Before using a dishwasher with a water softening filter, you must fill the salt com- partment with salt. Use coarse salt or spe- cial salt for dishwashers. Cover for the salt compartment It is best to fill with salt when you are about to do a wash, as the dishwasher needs to... -
Page 25: Settings
Settings *NB! Salt dispensers are not used in Australia or New Zealand machines. Setting water hardness If you have a dishwasher with a water softener, you may need to change the setting, de- pending on the hardness level of the water. Phone your local Water Board to check the water hardness in your area. -
Page 26: Fault Indications
Fault indications Display Type of fault Action flashes Too much water Phone service in the dishwasher flashes Fault with water inlet Check that the water is on flashes Valve leakage Switch off the water tap and con- tact service flashes Blocked drain See ‘Possible causes’... -
Page 27: Troubleshooting
Troubleshooting Problems Possible causes Action • Lift off the arms and clean. The dishes are not clean. • The spray arms are not rotating. • Avoid large packs. • Old dishwasher detergent. NB! Detergent is a perishable. • Dispense according to the •... -
Page 28: The China Has A Whitish-Blue Sticky Film
Possible causes Action Problems The china has a whitish- • Too high dosage of rinse • Reduce dosage. See the blue sticky film. aid. chapter on rinse aid. If the water is very soft, you could try diluting the rinse aid (1 part rinse aid, 1 part water). -
Page 29: Water Remains In The Machine
Problems Possible causes Action 1 minute appears in the The program is taking longer No action; next time the display than estimated. program is run the corrected time will be displayed. • Obstruction in the drain Water remains in the •... -
Page 30: Performance Information
Performance information Test dosage Normal wash Main wash 25 gram Standart detergent. Rinse aid dosage 3. Energy labelling Australia: AS/NZS 2007 Dishwasher program: Normal wash, Economy temp. 45°C, Economy drying. For the drying performance test the door should be opened upon completion of the drying cycle a distance of 35 mm at V. -
Page 31: Installation
Installation Suggestions on positioning the Built-in installation dishwasher The dishwasher can be built in, fully free- standing or semi-freestanding. CAUTION! 860-910 Connection to electricity, water and drain- 860- age must be carried out by a suitably quali- 140- fied person. A. -
Page 32: Connection To Water
Connection to water CAUTION! There must be a shut-off tap on the water The lead must be removed from the socket supply pipe. The shut-off tap should be while the work is carried out! easily accessible. Connection to drainage The water supply pipe has a connection When the drain hose is routed to a with a 1/2”... -
Page 33: Positioning The Machine
Positioning the machine 5. Check that the height of the machine corresponds to the height from the floor to the A. Adjusting freestanding dishwashers underside of the work surface. Tighten the 1. Adjust the height of the dishwasher with locking nuts (locking nut) on the rear feet. the four steel feet. -
Page 34: Screw The Dishwasher Into Place
Not all models Slide the dishwasher into place Screw the dishwasher into place • Pull the drainage hose and connection The enclosed plastic plugs are used for cover- pipe when the machine is pushed into ing the screw holes if the dishwasher is to be place. -
Page 35: Service & Guarantee
Service & guarantee Service Guarantee Before calling for service, check to see For guarantee details, see the guarantee whether the faults is due to something that card. you can rectify yourself. See Trouble shooting pages 25-27. -
Page 36: Own Comments
Own comments... - Page 37 Own comments...
-
Page 38: Quick Guide
Quick Guide 1. Loading baskets Scrape off large food particleas before loading the machine. 2. Dispensing dishwasher detergent The detergent compartment has a small compartment for pre-wash and one for main wash. 3. Ensure that the spray arms can rotate freely 4.
