Orno OR-CR-205 Instruction Manual

OR-CR-205
Instruction
The product adopts good sensitivity detector, integrated circuit. It gathers automatism,
convenient safe, saving-energy and practical functions. It utilizes the
infrared energy from human as control-signal source, it can start the
load at once when one enters detection field. It can identify day and
night automatically. It is easy to install and used widely.
SPECIFICATION:
Power Source: 220 -240V/AC
160°
Power Frequency: 50Hz
Ambient Light: 3-2000LUX (adjustable)
Time-Delay : min:10sec±3sec
Max:7min±2min
Rated Load: 1200W (incandescent lamp)
300W (energy-saving lamp)
Detection Distance: 9m max (<24℃)
FUNCTIONS:

LUX adjustment: The consumer can adjust work ambient light. It can work in the daytime
and at night when it is adjusted on the "sun" position (max). It can work in the ambient light
less than 3LUX when it is adjusted on the "moon" position (min). As for the adjustment
pattern, please refer to the testing pattern.

Time-delay is added continually: When it receives the second induction signals after the
first induction, it will compute time once more on the rest of the first time-delay basic.(set
time)
 Time-delay adjustment: It can be set according to the consumer's desire. The minimum
time is 10sec±3sec. The maximum is 7min±2min.

The switch: "ON" 、 "OFF"、"PIR".
Good sensitivity
Detection Range:
Working Temperature:-20~+40℃
Working Humidity :< 93%RH
Installation Height: 1m-1.8m
Power Consumption:0.45W (work)
0.1W (static)
Detection Motion Speed: 0.6-1.5m/s
Poor sensitivity
