- Page 1 Electric Standing Desk suppo rt@abo rde rprodu cts.com(24/7) Assembly Height Adjustment Range Video Vertical Range 28.3”- 46.5” 72-118cm Size：140/160cm Power Input Speed Motion Noise <55dB 100V-240V 20 mm/s...
- Page 3 Tools Needed Not Included) Phillips Screwdriver Pistol Drill STEP 1 Assembling and Connecting the Desk legs Supplied Parts and Hardware Screws Screws Large Allen Key M6×8mm M8×37mm S=5mm Right Leg Left Leg Crossbar (x1) Leg Base (x2)
- Page 4 M6×8mm(x4) S=5mm S=5mm Desk Board Connectors Note the direction of the desk board connectors. M8×37mm(x2) S=5mm Make sure that the desk foot pad is facing upwards. Large Allen Key S=5mm TEAM LIFT HEAVY You may need assistance with this step.
- Page 5 Attaching the Side Plates and the STEP 2 Transmission Rod Supplied Parts and Hardware Screws Large Allen Key Small Allen Key Side Plate Transmission rod M6×8mm S=5mm S=2mm M6×8mm(x4) S=5mm Ensure the installation is facing outwards, with the arrow pointing outwards.
- Page 6 Can be stretched Coupling nut Loosen the coupling nut. Limit Block Attention: Step 1：Place the transmission rod into the hex hole. Step 2：Make sure the "Limit Block" is fully in the hex hole of the leg. Step 2 Step 1 Limit Block Left Leg...
- Page 7 Step 1 Observe whether the two legs are on the same level. Right Leg Left Leg The distances in the image are the same, indicating that they are on the same horizontal line. Step 2 If the height is same, ignore this step and proceed to the next step of installation.
- Page 8 Step 1 Step 2 1. Loosen the connecting nut. 2. Pull out the transmission rod to the required length NOTE: Make sure the set screw faces out Insert the other end of the transmission rod to the slot on the leg (You may rotate the rod slightly for better installation).
- Page 9 S=2mm Fig 1 Secure the transmission rod to the motor drive Small Allen Key S=2mm shaft by turning the set screw clockwise. Fig 2 Tighten the coupling nut.
- Page 10 STEP 3 Assembling and Attaching the Desktop Supplied Parts and Hardware Screws Wood Tip Headphone Hanger Tabletop Connector M5×15mm Tabletop Control Panel Tip: indicate pre-drilled hole locations Bottom...
- Page 11 Wood Tip (x6) Ensure both table top pieces facing one another, and the wood tip holes facing each other. Bottom Please install the office desk on the floor or carpet to avoid damage. Tabletop Be careful not to install it Connector (x2) in the middle position.
- Page 12 M5×15mm(x10) Make sure the pre-made holes for the control panel are on the same side as the motor. Make sure to tighten the screws vertically. Mind your head ! MID YOUR HEAD...
- Page 13 M5×15mm(x6) Headphone Hanger(x2) Attach the control panel and hooks to the desktop.
-
Page 14: Connecting The Cables
STEP 4 Connecting the Cables Supplied Parts and Hardware Cable Clip Power Cable Clip (x2) (x1) Power NOTE: An example of a cable clip layout is indicated below. However, the cable clips can be arranged according to your needs. Tip:When flipping the desk over ,do not allow the controller to collide with the ground,which could cause damage. -
Page 15: Height Adjustment
Instructions for Using the Control Panel Memory Height Usage and Setting 1. Press the " " or " " or " " or " " button to invoke its corresponding height. The height adjustable desk will automatically move to the corresponding position. 2. -
Page 16: Typical Questions
Common Installation Problems and Solutions Typical Questions Solution 1. Left leg Unable to Synchronize lift Scan the QR code to view the solution. (Only one leg is moving up/down). Contact our customer service and we will send the product 2. Product Missing Accessories . to you as quickly as possible ( Contact details are below). - Page 17 Hand Control Protection and Alarm If the desk has been running continuously for a long time, this protection mechanism may be triggered. In such cases, reconnect the power or wait for at least 18 minutes before using. If the desk vibrates or collides during movement, an alarm will sound, and the desk will immediately stop and move in the opposite direction for a certain distance before automatically releasing.
