PulseTech 870PT Quick Start Manual

QUICKSTART GUIDE
Digital Battery Tester and Analyzer
Negative Clamp
(BLACK, -)
Positive Clamp
(RED, +)
Included with your purchase:
(1) 870PT Battery Tester
(1) User Manual
(1) Quick Start Guide
Main Features
• Battery, Cranking, & Charging System Tester
• 6V, 12V, and 12V Start Stop Battery Test
• 12V & 24V Cranking/Charging System Test
• 6V/12V Internal Resistance Test
• TFT-LCD Display w/Intuitive User Interface
• USB Type-C Wired Connection
• Supports Result Management Software
• Update Firmware In-Field via PC Software
• Built-in 2" Thermal Printer & Customizable
Facility Information
• Detachable/Replaceable 5.9' Cable
• Built-in Clamp and Cable Diagnostic Capability
• Strong and Durable Heavy-Duty Case Design
• Recall and Print Last 500 Test Results
• 12-Month Warranty
pulsetech.com
(1) Paper Roll
(6) AA Batteries
(1) USB Cable
GETTING STARTED
Caution
Suggested ambient operating temperature:
0°C (32°F) to 50°C (122°F).
Operation and Use
Each time you connect the tester to a battery, the
tester will run a quick cable verification to ensure a
proper connection. If the connection checks out OK,
the tester will proceed to the Home Screen. If the con-
nection is poor, the display will show "CHECK CABLE".
Select Cable Diagnosis to make sure if the cable is
damaged or not. Check cable connections for visible
signs of damage, as you may need to re-connect the
clamps to the battery or replace the cable end.
Please see the included 870PT Manual for full use and
setup details. A downloadable version is also available
at pulsetech.com on the product page for the 870PT.
• (800) 580-7554
Built-In 2"
Thermal
Printer
w/Clear
Cover
Adjustable
Brightness
LCD Display
USB Port
Input and
Navigation
Buttons
5.9' Clamp
Cable with
Quick-Detach
