B Series
LED Explosion Proof Light
Without globe:
B
With globe:
Note: The globe is optional for B, B2, B3 only.
Globe is not available for B4.
Certifications:
Marking ATEX
II 3 G Ex ec IIC T6...T3 Gc
II 2 D Ex tb IIIC T85°C...T100°C Db
II 2 G Ex eb mb IIC T5...T6 Gb
II 2 D Ex tb IIIC T80°C...T100°C Db
Marking IECEx
Ex ec IIC T6...T3 Gc
Ex tb IIIC T85°C...T100°C Db
Ex eb mb IIC T5...T6 Gb
Ex tb IIIC T80°C...T100°C Db
Standard Materials:
Housing: Copper-free aluminum
Lens: Tempered glass
B2
B3
Marking UL844 (North American)
Class I, Division 2, Groups A, B, C, D
Class II, Division 1, Groups E, F, G
Class II, Division 2, Groups F, G
Class III
Marine Marking
NEMA 4X
UL1598A
ABS
Hardware: Stainless steel
Mounting Bracket: Stainless steel
B4
IP66
01
Advertisement
Table of Contents
Related Manuals for Sokply B Series
Summary of Contents for Sokply B Series
- Page 1 B Series LED Explosion Proof Light Without globe: With globe: Note: The globe is optional for B, B2, B3 only. Globe is not available for B4. Certifications: Marking ATEX Marking UL844 (North American) II 3 G Ex ec IIC T6...T3 Gc...
-
Page 2: Key Features
LED Explosion Proof Light - B Series Key Features: Dimmable and battery backup function is available. High-quality SMT LED and Meanwell driver. Heavy-duty and high impact resistance. Replaceable LED board and drivers. Integrated junction box for driver. Marine rating powder coated finish treatment. - Page 3 LED Explosion Proof Light - B Series Dimensions: B2 Series Without globe: With globe: 9.57inch ∅9.06inch B Series Without globe: With globe: ∅10.63inch 0.43inch 2.75inch ∅10.63inch 6.30inch B3 Series B3 Series Without globe: With globe: ∅14.57inch ∅14.57inch B3 Series B4 Series...
-
Page 4: Packing Information
LED Explosion Proof Light - B Series Photometry: -/+180 -/+180 -/+180 -150 -150 -150 -120 -120 -120 6000 3000 1600 12000 6000 3200 18000 9000 4800 24000 12000 6400 30000 15000 8000 Beam angle: 40° Beam angle: 60° Beam angle: 90°... - Page 5 LED Explosion Proof Light - B Series Wall Mounting Flexible metal conduit 3/4 NTP(At least 6x Teeth 16# Spanner 2-Fixing screw need to tighten) 13# Spanner 1. Take the fixture and accessory out from carton box, ghten 3. Drill 2x hole as Shown in Fig.2, the distance can be 91~140mm, 4.
- Page 6 LED Explosion Proof Light - B Series Arm Mounting by Opening Driver Box This installation method is only for Model B. It can not be applied on Model B2, B3, and B4 because they are too heavy. Only one electrician is required for this installation.
