NVX XF Series User Manual

2-way coaxial speakers for select harley-davidson motorcycles
Hide thumbs

Advertisement

Quick Links

Download this manual
XF-SERIES
2-WAY COAXIAL SPEAKERS
FOR SELECT HARLEY-DAVIDSON
MOTORCYCLES
XFHD5F
XFHD5R
USER MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the XF Series and is the answer not in the manual?

Questions and answers

Related Manuals for NVX XF Series

Summary of Contents for NVX XF Series

  • Page 1 XF-SERIES 2-WAY COAXIAL SPEAKERS FOR SELECT HARLEY-DAVIDSON MOTORCYCLES XFHD5F XFHD5R USER MANUAL...
  • Page 2 THANK YOU FOR CHOOSING NVX Thank you for choosing NVX XF-Series speakers for your motorcycle. Whether you are an established audio guru or replacing your speakers for the first time, you will soon be immersed in the nuance and warmth of your music like never before.

  • Page 3: Specifications

    SPEAKERS MOTORCYCLE SPECIFICATIONS XF-SERIES XFHD5F XFHD5R 94 dB 94 dB Sensitivity 40-25,000 Hz 40-25,000 Hz Frequency Response 150 watt each speaker 150 watt each speaker RMS power 300 watt each speaker 300 watt each speaker Peak power 2 Ω 2 Ω Impedance FEATURES MEASUREMENTS...

  • Page 4: Section 1 - Xfhd5F Front Fairing Speaker Installation Instructions

    Refer to your Harley-Davidson’s factory service manual for detailed disassembly and reassembly procedures. Most installations will reuse the factory screws, hardware, and grilles, so be sure to keep all original components on hand. The following instructions and diagrams will walk you through installing your NVX XFHD5F speakers step-by-step.
  • Page 5 2. Prepare the Grilles (if applicable) While the XFHD5F speakers can be installed behind your factory grille fabric, NVX includes metal mesh grilles designed for a premium look and enhanced durability—specifically for 1998–2013 Harley-Davidson Street Glide, Ultra, Classic, and Standard models. The original grille cloth is typically glued and taped to a plastic mesh;...

  • Page 6: Section 2 - Xfhd5R Rear Tour Pack Speaker Installation Instructions

    2. Install the New Speakers The NVX XFHD5R speakers are designed to integrate seamlessly with the factory wiring. Connect the factory female terminals to the male terminals on the XFHD5R speakers—they will only fit one way. If your bike previously had aftermarket speakers installed, you may need to re-terminate the factory wiring with the appropriate connectors (not included).
  • Page 7 SPEAKERS MOTORCYCLE Note: The factory rubber nutserts in the rear Tour Pack pods can be a bit finicky. We recommend loosely threading all four grille screws first, then gradually tightening each one in sequence until they’re all secure and evenly seated. 3.
  • Page 8 • Non-defective returns or products not eligible for warranty service will Louisville, KY 40210 be returned freight collect. Failure to follow the steps listed above may void your warranty. Any questions can be directed via email to cs@nvx.com or via mail at the address listed above.
  • Page 9 SPEAKERS MOTORCYCLE NOTES _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _...
  • Page 10 Visit: nvx.com • Call: 213.444.1689 • 742 S. 11th St., Louisville, KY 40210...
