NVX XF Series User Manual

2-way coaxial speakers for select harley-davidson motorcycles
Hide thumbs

Advertisement

Quick Links

Download this manual
XF-SERIES
2-WAY COAXIAL SPEAKERS
FOR SELECT HARLEY-DAVIDSON
MOTORCYCLES
XFHD65F
XFHD65R
USER MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the XF Series and is the answer not in the manual?

Questions and answers

Related Manuals for NVX XF Series

Summary of Contents for NVX XF Series

  • Page 1 XF-SERIES 2-WAY COAXIAL SPEAKERS FOR SELECT HARLEY-DAVIDSON MOTORCYCLES XFHD65F XFHD65R USER MANUAL...
  • Page 2 THANK YOU FOR CHOOSING NVX Thank you for choosing NVX XF-Series speakers for your motorcycle. Whether you are an established audio guru or replacing your speakers for the first time, you will soon be immersed in the nuance and warmth of your music like never before.

  • Page 3: Specifications

    SPEAKERS MOTORCYCLE SPECIFICATIONS XF-SERIES XFHD65F XFHD65R 92 dB 92 dB Sensitivity 40-25,000 Hz 40-25,000 Hz Frequency Response 150 watt each speaker 150 watt each speaker RMS power 300 watt each speaker 300 watt each speaker Peak power 2 Ω 2 Ω Impedance FEATURES MEASUREMENTS...

  • Page 4: Section 1 - Xfhd65F Front Fairing Speaker Installation Instructions

    XF-SERIES INSTALLATION 2014–Current Harley-Davidson Touring Models: • Compatible with both standard and Boom! Audio systems. • For models with a factory amplifier, always disconnect the battery before installation to prevent electrical issues. • Use only 2-ohm stable amplifiers if upgrading your system for best performance and to protect your equipment. SECTION 1 –...
  • Page 5 • The factory grille can remain, or you may replace it with the supplied NVX metal mesh grille, using the three factory screws on the inside of the fairing. Note: The NVX grille features two holes and one “keyhole” slot. The keyhole should face the radio for proper alignment. Using the factory grille may slightly reduce high-frequency output.
  • Page 6 2014 and newer Harley-Davidson touring models feature an alignment pin inside the front speaker enclosures, intended to fit into a hole in the factory speaker frame. Since NVX XFHD65F speakers do not have this alignment hole, the pin must be carefully removed (by cutting or grinding) to allow the speaker to sit flush in the enclosure.

  • Page 7: Section 2 - Xfhd65R Rear Tour Pack Speaker Installation Instructions

    • Once connected, set the speaker in place and install the supplied NVX or original grilles. Secure with the four original screws. Note: The factory rubber nutserts can be finicky—start all four screws loosely before tightening them down gradually and evenly.
  • Page 8 • Non-defective returns or products not eligible for warranty service will Louisville, KY 40210 be returned freight collect. Failure to follow the steps listed above may void your warranty. Any questions can be directed via email to cs@nvx.com or via mail at the address listed above.
