- Page 1 LARK A1 User Manual...
-
Page 2: Product Overview
Product Overview TX: Transmitter 1. Microphone Pickup Hole Position the microphone pickup hole upward during wear to ensure optimal sound capture performance. 2. Button Functions Power On/Off: Press and hold for 3 seconds to turn the TX on/off. When placed in the charging case while powered off, the TX will automatically turn on and charge Pairing Mode: In the off state, press and hold the button for 6 seconds... - Page 3 3. LED Indicator Guide Blue Light (Slow Flash) Disconnected Blue Light (Fast Flash) Pairing Blue Light (Solid) Connected Green Light (Solid) Noise cancellation on Red Light (Solid) TX muted Yellow Light (Solid) TX1 assigned Pink Light (Solid) TX2 assigned 4. Battery Status Indicator Non-Charging State Red Light Slow Flashing 0%-6%...
- Page 4 RX: Receiver 1. USB-C/Lightning Port For mobile device connection. 2. USB-C Charging Port Supports charging while using. 3. Button Functions Pairing: Press and hold the RX button for to enter pairing mode. Noise Cancellation: Single-click to toggle noise cancellation on/off. TX 1 Mute: Double-click to toggle TX 1 mute.
- Page 5 Charging Case 1. USB-C Charging Port Charges both the charging case and the device. 2. Auto Power On/Off Power On: Automatically activates when removed from the charging case. Power Off: Automatically shuts down when placed back into the charging case. 3.
-
Page 6: Wearing Instructions
Wearing Instructions... - Page 7 Connection USB-C Lightning *Supports charging the device via RX when smartphone battery is low (compatible models only).
-
Page 8: Function Overview
Function Overview For function adjustment, connect TX and mobile RX to your smartphone and configure via the LarkSound APP. 1. Noise Cancellation Three levels: Low (10dB), Medium (15dB), High (20dB) Default: High... - Page 9 2. Volume Gain Control 6 adjustable levels (Level 6 = Max volume) Default: Level 5 3. Audio Channel Mode Options: Stereo / Mono Default: Mono...
- Page 10 4. EQ Modes Presets: Equalization/Low/Bright Default: Equalization 5. Reverb Adjustment Three levels: Light / Medium / Large Default: Off (manual activation required)
- Page 11 6. MIC Identification Indicator lights on both TX and RX distinguish TX 1/ TX 2. 7. TX LED Control Toggle TX indicator lights On/Of...
-
Page 12: Charging Method
Charging Method Charging Case When connected via a USB-C cable, the charging case provides power to the entire device system. Charging Dock When connected via a USB-C cable, the charging dock charges the TX devices. -
Page 13: Firmware Update
Firmware Update 1. When TX is connected to mobile RX, firmware can be updated through the APP. The device will automatically reboot after successful update. TX 1 TX 2 Solid pink light: RX updating * Note: Do not disconnect RX during the process. If the update fails, the APP will display an error prompt. -
Page 14: Specifications
Specifications Mic Sensitivity -37dBV±2dBV@1KHz,94dBSPL Wireless Modulation GFSK 2Mbps Mode Wireless Transmission 2.4 GHz Adaptive Frequency Hopping (AFH) Transmission Range TX: 200m Mic Polar Pattern Omnidirectional Frequency Response 20Hz~20KHz Signal-to-Noise Ratio ≥ 67dB Max Sound Pressure Level 120dB SPL Sample Rate and Bit 48kHz/24Bit Depth TX: 3.8V... - Page 15 App Stores. You can also scan the QR code below to download the app. The LarkSound app is a perfect match for Hollyland wireless microphones. With the app, you'll have access to a range of smart features, such as parameter configurations and firm- ware updates, that work together seamlessly to enhance your microphone performance.
- Page 16 Shenzhen Hollyland Technology Co., Ltd. 8F, 5D Building, Skyworth Innovation Valley, Tangtou Road, Shiyan Street, Baoan District, Shenzhen, 518108, China Made in China...
