- Page 1 PF1 Intelligent Pet Water Dispenser Manual Please read this manual carefully and keep it properly before using the product.
- Page 2 Federal Communications Commission (FCC) Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 3: Table Of Contents
Contents Precautions List of Parts Product Introduction Product Installation Product Usage Instructions Connecting to the APP Key Button Description Indicator Description Maintenance Performance Failure Table Basic Parameters Maintenance Record Services And Support... -
Page 4: Precautions
Precautions Use safety instructions This product and all accessories are not edible. Please use it indoors in a dry environment. Please do not place this product on high places. Keep the machine horizontally during use, and do not tilt or overturn it. Do not use hot water in the water storage tank. -
Page 5: List Of Parts
List of Parts PF1 Intelligent Pet Water Dispenser Manual Please read this manual carefully and keep it properly before using the product. Machine Filter Element Power Adapter Manual Product Introduction Handle Drinking Tray Water Tube Pump Filter Filter Tray Sponge... -
Page 6: Product Installation
Foot Pad Power Cord Product Installation Tips: It is recommended to replace the filter element, pump filter sponge and water tube once a month. Thoroughly cleaning the water storage tank, drinking tray, filter assembly, filter element, pump filter sponge, pump, etc. of the water dispenser at least once every seven days. -
Page 7: Product Usage Instructions
Filter Element Filter Tray 3. Refer to the above figure and install the * If the pump falls off, refer to the above filter element. figure and connect it with the water tube. Product Usage Instructions In order to avoid the interference of the sensor and preventing the accuracy of data reported from being affected, the following points should be considered when the device is placed: 1. -
Page 8: Connecting To The App
Connecting to the APP Download and install the App Method 1: Scan the QR code to download Method 2: Open the mobile app store, and install the App according to the prompts search for "petgugu", download and given. install it. Android petgugu... -
Page 9: Key Button Description
Key Button Description Function Key Short Press: Switching between water dispense modes. Eco Mode: When the water volume does not appear to have any changes, water will be dispense intermittently gushing for 30 seconds, then after it will stop for 3 minutes. When a pet is drinking the water and water volume changes, continuous uninterrupted water will be dispensed, until the water dispenser’s water volume stopped having fluctuations for 30 seconds then the device will stop the dispensing of water. - Page 10 Wi-Fi Setup Indicator White flashing: Enters the networking state and wait for Wi-Fi connection. If the networking is not successful within 3mins, the indicator will go out. White is always bright: Wi-Fi connection is successful. Low Water Level Indicator When the water level is below the warning water level, the indicator flashes in white. Please add water and the light will go out automatically after the water is added.
-
Page 11: Maintenance
Maintenance I. Cleaning And Maintenance of Pet Water Dispenser Please do not put it under direct sun light, so as not to accelerate the yellowing and aging of the machine. Please disconnect the power supply, clean the whole machine, and ensure that the bottom connector is dry. - Page 12 III. Steps For Cleaning The Pet Water Dispenser 1. Separate the drinking tray from the 2. Remove and thoroughly clean the pump water storage tank and pour out the assembly and water tube, and pay remaining water, disassemble and special attention to removing the hair wash the drinking tray and filter and dirt in between the gaps.
- Page 13 IV. Steps For Replacing The Filter Element On The Pet Water Dispenser 1. Take up the drinking tray and remove 2. Disassemble the filter assembly, take the filter assembly. out the filter element, and remove the hair and dirt on the filter assembly. 3.
-
Page 14: Performance Failure Table
Performance Failure Table Serial Performance Failure Solution Number Key function Unplug the adapter and wait 30s before plugging it in to failure restart the machine. If this operation cannot clear the issue, The indicator please contact after-sales service. is not on Check whether the water tube is blocked. -
Page 15: Basic Parameters
Basic Parameters Product Name Intelligent Pet Water Dispenser Product Net Weight 1.5kg Model ABS (body, drinking tray) Main Materials PC (water storage tank) 5.2V 2.0A Input Parameters Working Temperature 5°C~50°C Rated Power 10.0W Working Humidity 10%-80%RH Product Dimension 240×191×187.5mm Power Cord Length 1.5m/1.8m Product Capacity This Device Contains Radio... -
Page 16: Maintenance Record
Maintenance Record Name of Maintenance Center: Maintenance Center Tel: Delivery Date: Cause of Failure: Failure Situation in Repair: Certificate of Change or Refund: Signature of Maintenance Personnel: Stamp of Maintenance Center: Services And Support Email: service@petgugu.com Website: www.petgugu.com... - Page 18 Scannen Sie den QR-Code, um das Online-Handbuch auf Deutsch zu erhalten. Scannez le QR code pour obtenir le manuel en ligne en français. Scansiona il codice QR per ottenere il manuale online in italiano. Escanee el código QR para obtener el manual en línea en español.
