- Page 1 PW5 Smart Cat Litter Box Toilet User Manual Please read this manual carefully and keep it properly before using the product.
-
Page 2: Table Of Contents
Contents Safety Precautions Points for Users to Note Regarding Pet Usage Recommendations Packing list Product Description Upper Shell Assembly Sand Tank Assembly Base Assembly Preparation Before Use Button Instructions Indicator Light Explanation Feature Introduction APP Download Maintenance and Care I. Maintenance and Care Guidelines II. -
Page 3: Fcc Caution
FCC Caution This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 4: Safety Precautions
Safety Precautions * Please follow the instructions for using this product to avoid malfunction, other unexpected losses, and potential dangers. This product is not suitable for individuals with diminished physical, sensory, or mental capabilities, or lack of experience and knowledge, including children, to use alone. Unless they are supervised or guided by those responsible for their safety or family members after successful binding with the app. -
Page 5: Points For Users To Note
resolution. Do not attempt to disassemble and repair the product yourself to avoid accidents. (Examples of abnormalities or malfunctions include: - Power cord damage, such as cracks or exposed cores. - Abnormal heating, deformation, or discoloration of the product, power plug, or power cord. - After moving the power cord, the product may not power on at times. -
Page 6: Packing List
One-minute/ two-way faucet Inlet pipe Outlet pipe Robot (PW5) Throat clamp Sand collection bag Note: The illustrations of products, accessories, user interfaces, etc. in the manual are schematic and for reference only. Due to product updates and upgrades, there may be slight differences between the actual product and the illustrations. -
Page 7: Product Description
Product Description Upper shell assembly Sand tank assembly Base assembly... -
Page 8: Upper Shell Assembly
— Upper Shell Assembly Sand tank cover Air outlet Function buttons (For detailed information, please refer to the instruction manual.) Connector pins Automatic sand addition port Air purification filter Camera Fill light UV sterilization lamp... -
Page 9: Sand Tank Assembly
— Sand Tank Assembly Filter mesh Sand tank Cat litter pad Sand tank rotating gear Filter mesh Cat litter pad buckle Cat litter addition MAX line Cat litter pad... -
Page 10: Base Assembly
— Base Assembly Connector contacts Sand tank bracket Mesh-driven wheel Roller Sand collection opening Sand collection bin Cleaning bin inlet Sand tank bracket Power interface Drain outlet Water inlet... -
Page 11: Preparation Before Use
Preparation Before Use 1. Installation Environment -Due to the product's need for water intake and drainage, please place the product in an area equipped with a faucet and floor drain. -Position the product on a flat, hard surface. Clear any debris around the product, maintaining a distance of at least 5cm from other objects (such as walls) to avoid excessive vibration and noise during product operation. - Page 12 3. Confirm the Faucet Connection for the Water Inlet Pipe The water inlet pipe joint is a four-way quick connector. Check if the faucet has a four-way connector structure. If the faucet does not have a four-way connector, replace the faucet with the one provided in the accessories, which is a one-to-two faucet.
- Page 13 6. Connect the drain pipe -Slip the hose clamp onto the L-shaped interface of the drain pipe. -Forcefully push the L-shaped interface of the drain pipe into the product drain interface, then rotate the locking knob on the hose clamp to secure the drain pipe to the product drain outlet. -Insert the other end of the drain pipe interface into the floor drain.
- Page 14 7. Adding Cat Litter ①. After removing the upper shell component, add cat litter to the sand bin. * Note that the amount of cat litter added to the sand bin should not exceed the MAX line indicated inside the sand bin (approximately 6.5L). ②.
- Page 15 8. Install the Litter Bag Pull out the litter bin from the product, place the litter bag into the litter bin, smooth the edges of the litter bag, and push the litter bin back into the product. Sand collection 9. Connect the Power Insert the power cord interface into the power interface on the back of the product, and plug the power plug into the power outlet.
-
Page 16: Button Instructions
Button Instructions Button Indicator Lights Smooth Cat Litter Button Wi-Fi Button Auto-Cleaning Button Smooth Cat Litter Button Press this button lightly, the button indicator light flashes white slowly (once every 3 seconds), the sand bin rotates back and forth 40° three times, smoothing the cat litter on the cat litter pad. Wi-Fi Button Long press for 3 seconds, the button indicator light flashes white slowly, and the device enters Wi-Fi pairing mode. -
Page 17: Indicator Light Explanation
Indicator Light Explanation * If there is no operation within one minute, the indicator light will automatically turn off. Flat Cat Litter Key Indicator Light White slow flashing: The machine is leveling cat litter. White steady light: Leveling cat litter is completed. Wi-Fi Key Indicator Light White slow flash: ①Enters pairing mode, waiting for Wi-Fi connection;... -
Page 18: Feature Introduction
Feature Introduction Auto-Cleaning Fully automated intelligent burying and cleaning of cat excrement, clean and sterile, freeing hands, and odor-free; cat owners no longer need to manually scoop cat litter to clean cat excrement. Video Monitoring High-definition looping video automatically records the number of times the cat uses the toilet, allowing cat owners to check the cat's defecation status on the app at any time, understanding the cat's health. -
Page 19: App Download
APP Download This product is integrated with the petgugu APP, and users can download and install the app through the following methods. Method 1: Scan the QR code and download install the App according to the prompts. Method 2: Open the mobile app store, search for "petgugu", download and install. -
Page 20: Maintenance And Care
Maintenance and Care I. Maintenance and Care Guidelines Please avoid placing the product in direct sunlight to prevent accelerated yellowing and aging. For an optimal user experience, it is recommended to clean the product monthly to ensure a hygienic environment for your cat. Disconnect the product from the power source before performing cleaning and maintenance. -
Page 21: Cat Litter Replacement Guide
Silicone Handle III. Cat Litter Replacement Guide 1. Clean the old cat litter from the litter compartment Simultaneously press the Wi-Fi button and the automatic cleaning button, and the device enters one-key cat litter dumping mode. Pour the old cat litter in the litter compartment into the bottom collection bin. - Page 22 3. Add cat litter -You can use the mobile app to control the sand storage bin to automatically add cat litter to the litter compartment. -You can directly add an appropriate amount of cat litter to the litter compartment (be careful not to exceed the MAX line).
-
Page 23: Cleaning Guide
IV. Cleaning Guide 1. Remove the Sand Bin Assembly Refer to the previous section on emptying the cat litter from the sand bin assembly. After disconnect- ing the device's power, lift the upper shell assembly and then remove the sand bin assembly. * Due to electronic components inside the device, neither the upper shell assembly nor the base assembly can be washed with water. - Page 24 ②. Use your hands to push along the edge of the cat litter pad towards the center, releasing the buckle between the edge of the cat litter pad and the inner part of the sand bin. Then, remove the cat litter pad.
-
Page 25: Common Issues
5. Reassemble After Cleaning After cleaning and ensuring that any residual moisture on the product has dried, reassemble the product in sequence, then reconnect the power to use it again. Common Issues 1. No response from the device after connecting the power? ①Please confirm the product's power line connection and check if the home power is on and the socket is functioning properly. -
Page 26: Basic Parameters
7. Unable to connect to the app? ①Confirm that the device is within Wi-Fi signal range and that the entered Wi-Fi username and password are correct. ②Make sure that the network Wi-Fi being used is a 2.4G frequency network. * If encountering unresolved or unsolved issues, please contact customer service for consultation. Do not attempt to disassemble or repair the machine independently to avoid safety incidents. -
Page 27: After-Sales Service
After-sales Service Purchase Information User Name User Contact Number User Mailing Address and Postal Code Purchase Date Maintenance Records Maintenance Center Name Maintenance Center Phone Number Date of Sending for Repair Cause of Malfunction Description of Malfunction during Repair Refund Proof Signature of Maintenance Personnel Seal of Maintenance Center * Out-of-Warranty Scenarios... -
Page 28: Service And Support
When returning for replacement or repair, please send the receipt and the machine together. If there are gifts or invoices, please include them in the return shipment. Service and Support Email: service@petgugu.com Website: www.petgugu.com Certificate OF Qualification Inspected And Approved... - Page 29 Scannen Sie den QR-Code, um das Online-Handbuch auf Deutsch zu erhalten. Scannez le QR code pour obtenir le manuel en ligne en français. Scansiona il codice QR per ottenere il manuale online in italiano. Escanee el código QR para obtener el manual en línea en español. コードをスキャンして、日本語のオンライン...
