Summary of Contents for Dolonm ILA33775
- Page 1 ASSEMBLY INSTRUCTIONS TWIN HOUSE FLOOR BED ILA33775...
-
Page 2: Detail View
Detail View... -
Page 3: Part List
Part List Leg HB (Left Front) - 1pc Leg HB (Left Back) - 1pc Leg FB (Right Front) - 1pc Leg FB (Right Back) - 1pc Side rail (Front) - 1pc Side rail (Back) - 1pc Long guard rail (Back) - 1pc Support guard rail (Right) - 1pc Short guard rail (Front) - 1pc Upper HB (Left Front) - 1pc... -
Page 4: Hardware List
Hardware List 8*30mm Wood dowel (4pcs) Wood dowel (4pcs) Hex-Head bolts (11pcs) 35mm 65mm Hex-Head bolts (9pcs) Hex-Head bolts (2pcs) Wood screw bolts (7pcs) 1/4"*15 (9.5mm) (1/4")4.5*58mm Horizontal-Hole bolts (20pcs) Allen key (1pc) ASSEMBLY TOOLS REQUIRED ( NOT INCLUDED ) - Page 5 STEP 1: 4PCS 4PCS Note:Part 7 will face up with the "x" mark on it, otherwise it cannot be tightened STEP 2: 2PCS...
- Page 6 STEP 3: 2PCS 2PCS STEP 4: 2PCS 2PCS...
- Page 7 STEP 5: 4PCS 4PCS Note:Part 7 will face up with the "x" mark on it, otherwise it cannot be tightened STEP 6: 2PCS 10PCS 10PCS...
- Page 8 STEP 7: 2PCS 2PCS 2PCS...
