Part List
PIECE
DESCRIPTION
A
Back
Seat
B
C
Left side
D
Right side
Hardware List
PIECE
DESCRIPTION
T Bolt & nut
HW1
Extra bolt
HW2
Allen Key
HW3
QUANTITY
1x
1x
1x
1x
QUANTITY
6x
M6x70
1x
M6x45
1x
JONATHAN Y
MODEL# BNH101
Product Dimension: 59.06" L x 23.62 "D x 34.65"H
Advertisement
Related Manuals for JONATHAN Y BNH101
Summary of Contents for JONATHAN Y BNH101
- Page 1 Part List PIECE DESCRIPTION PICTURE QUANTITY Back JONATHAN Y MODEL# BNH101 Seat Product Dimension: 59.06" L x 23.62 ”D x 34.65”H Left side Right side Hardware List PIECE DESCRIPTION PICTURE QUANTITY T Bolt & nut M6x70 Extra bolt M6x45 Allen Key...
- Page 2 PREPARATION Tool required for assembly (included): Allen Key. M6x70 Step 1: Attach the Left side (C) to the Back (A) and the Seat (B) as shown in the picture .Using the T Bolt & nut (HW1) to fix the Back (A) , Seat (B) by the Allen key (HW3) and Extra bolt (HW2).
- Page 3 PREPARATION Tool required for assembly (included): Allen Key. M6x70 Step 2: Attach the Right side (D) to the Back (A) and the Seat (B) as shown in the picture .Using the T Bolt & nut (HW1) to fix the Back (A) , Seat (B) by the Allen key (HW3) and Extra bolt (HW2).
