Part List
PIECE
DESCRIPTION
A
Back
Seat
B
C
Left side
D
Right side
E
Front bar
Hardware List
PIECE
DESCRIPTION
Allen screw L
HW1
HW2
Allen screw S
Screw
HW3
Allen Key
HW4
QUANTITY
1x
1x
1x
1x
1x
QUANTITY
4x
M6x80
2x
M6x40
2x
M4x35
1x
JONATHAN Y
MODEL# BNH103
Product Dimension: 51.18" L x 19.29"D x 37.8"H
Advertisement
Related Manuals for JONATHAN Y BNH103
Summary of Contents for JONATHAN Y BNH103
- Page 1 Part List PIECE DESCRIPTION PICTURE QUANTITY Back JONATHAN Y Seat MODEL# BNH103 Product Dimension: 51.18" L x 19.29”D x 37.8”H Left side Right side Front bar Hardware List PIECE DESCRIPTION PICTURE QUANTITY Allen screw L M6x80 Allen screw S M6x40...
- Page 2 PREPARATION Tool required for assembly (included): Allen Key. M6x80 Step 1: Attach the Right side (D) , Front Bar (E) to the Back (A) as shown on the picture .Using the Allen screw (HW1) to fix these parts to the Back (A) the Allen key (HW4) .
- Page 3 PREPARATION Tool required for assembly (included): Allen Key. M6x80 Step 2: Attach the Left side (C) to these parts as shown on the picture .Using the Allen screw (HW1) to fix the Left side (C) as shown on the picture by the Allen key (HW4) .
- Page 4 PREPARATION Tool required for assembly (included): Allen Key. M6x40 Step 3: Using the Allen screw S (HW2) to fix the Back (A) to chair as shown in the picture by the Allen key (HW4) .
- Page 5 PREPARATION Tool required for assembly: Screw driver. M4x35 Step 4: Put the Seat (B) to the chair and using the Screw (HW3) to fix the Seat (B) to the chair both sides by the Screw driver before using as shown on the picture .
