NEEWER Z2PRO-S Manual

Catalog
Foreword
Precautions
Package Contents
Name of components
Battery
Power Management
Mount / Unmount flash
Flash Mode: TTL Autoflash
1. TTL Mode
2. FEC(Flash Exposure Compensation)
3. HSS: High Speed Sync
4. Second-Curtain Sync
M: Manual Flash
Multi: Stroboscopic Flash
Wireless Flash Shooting: Wireless (2.4G) Transmission
1. Wireless Settings
2. Flash Group Mode Selection
3. Setting the communication channel
4. Wireless ID Settings
5. Scan for a free, unused channel
6. Built in 2.4G Wireless Q and X Systems
7. TTL: Automatic wireless flash photography
8. M: Manual Wireless Flash Shooting
9. Multi: Wireless Flash Shooting with Manual Flash
Wireless Flash Shooting: Wireless (2.4G) Transmission
Other Applications
1. Sync Triggering
2. Auto Focus Assist Beam
3. TCM - One key switching TTL/M mode
4. Bounce Flash
5. ZOOM: Set the flash coverage
6. Modeling Lamp
7. Modeling Flash
C.Fn: Setting Custom Functions
Protection Function
Technical Data
Troubleshooting
Firmware upgrade
Restore factory settings
Compatible Cameras
Foreword
EN EN
02
Thank you for your purchase of a
02
Z2PRO-S is a TTL speedlite flash designed for Sony cameras. With
03
TTL auto flash, you will automatically get the accurate amount of
flash exposure for variable lighting conditions, thereby improving
03
your overall shooting experience. The following features set it
06
apart from the competition:
07
Maximum flash power of 76Ws, 81 levels of dimming (1/1~1/256)
08
08 3000mAh Li-polymer battery with an autonomy of 600 flashes at
full power, 1.5 seconds fast recharge.
The upgraded quartz tube supports up to 100,000 flashes during
its lifespan.
Supports TTL auto flash, which can be used as the TX or RX unit
11
of a wireless multi-lamp flash system - making shooting easier
and faster.
12
13
Screen for an intuitive display and easy operation.
Built-in 2.4GHz wireless transmission, Integrated transmitter and
receiver with a large radius.
Supports manual frequency flash mode, HSS/second curtain sync
/FEC and other TTL functions.
Stable output, High speed continuous flash and color temperature
with good even lighting.
Firmware will be upgraded as the camera is updated.
21
Precautions
21
1. Always keep this product dry.
2. Keep this product out of reach of children.
3. Do not disassemble or modify the product.
4. Do not subject to any form of physical shock. The product
shouldn't be exposed to fire or an environment where the
temperature exceeds 50 degrees.
5. Do not fire the flash directly into the eyes which could result in
23
visual impairment.
25
6. Do not use the product near chemicals, flammable gases or
26
other volatile substances which may cause fire or
27 electromagnetic interference.
28
7. Do not use in the rain or in damp conditions.
28
8. Turn off the product immediately, if it appears to be operating
abnormally, and try to troubleshoot the likely cause.
28
9. Failure to comply with the recommendations and warnings
listed in the manual will invalidate the warranty.
01 02
product.
