Redline PARLUX FBA-TAILGATE-PARLUX-TRIPLE-60-RED-TUNDRA Installation Manual

Triple tailgate light bar (2pc) for 2007-2021 tundra gen 2
Hide thumbs
1
2
3
4
5

Advertisement

Quick Links

Download this manual
REDLINE
PARLUX
TRIPLE TAILGATE LIGHT BAR ( 2PC )
FOR 2007~2021 TUNDRA GEN 2
1X
Triple Redline LED Bar
1X
Plastic Aligner (*Use this part for Option 1, Step 4-5)
1X
EVA foam (*Use this part for Option 1, Step 4-5)
Heat Shrinkable
2X
Connector
INSTALLATION GUIDE
WHAT'S INCLUDED
4X
Mounting
Clips
1
Adhesive
1X
Booster

Advertisement

loading
Need help?

Need help?

Do you have a question about the PARLUX FBA-TAILGATE-PARLUX-TRIPLE-60-RED-TUNDRA and is the answer not in the manual?

Questions and answers

Related Manuals for Redline PARLUX FBA-TAILGATE-PARLUX-TRIPLE-60-RED-TUNDRA

Summary of Contents for Redline PARLUX FBA-TAILGATE-PARLUX-TRIPLE-60-RED-TUNDRA

  • Page 1 TRIPLE TAILGATE LIGHT BAR ( 2PC ) FOR 2007~2021 TUNDRA GEN 2 INSTALLATION GUIDE WHAT'S INCLUDED Triple Redline LED Bar Plastic Aligner (*Use this part for Option 1, Step 4-5) EVA foam (*Use this part for Option 1, Step 4-5) Heat Shrinkable...

  • Page 2: Installation

    INSTALLATION STEP1 Before mounting the Redline Light Bar, perform a bench test by connecting the Redline LED Light Bar to the vehicle. Ensure all the lighting functions work. *RECOMMENDATION: For a successful install, we encourage you to carefully remove the truck's tailgate from the vehicle to achieve the best results.
  • Page 3 LED Bar, carefully plan and mark the INSTALLATION desired bracket mounting locations, taking placement into consideration to ensure a straight application. STEP5 Securely mount the Redline LED Bar to your vehicle using the provided screws and clips to ensure a solid installation.
  • Page 4 If you are not using the OPT7 Easy Connect USCAR 7 Pin to 4 Pin Harness with Reverse Wire, here is another option to connect the Redline Light Bar Reverse Function. Remove the OEM tail lights to locate the OEM reverse wire, using the provided...

  • Page 5: Hard Wiring

    OPT7 Easy Connect USCAR 7 Pin to 4 Pin Harness with Reverse Wire HARD WIRING If hard-wiring, use image below to identify wire color functions and pair them to appropriately identified wires on vehicle. TO REDLINE LED BAR TRAILER HARDWIRE HARNESS Ground White/Ground...
