- Page 1 OWNER’S MANUAL EXL-SQ65CX MANUAL DEL USUARIO 6.5" 2-WAY COMPONENT SET JUEGO DE COMPONENTES DE 6.5" Y 2 VIAS. ENGLISH | ESPAÑOL...
- Page 2 EXL-SQ65CX GENERAL SPECIFICATIONS / ESPECIFICACIONES GENERALES Nominal Diameter ................6.5" / Diámetro Nominal Nominal Impedance ..............4 Ohm / Impedancia Nominal RMS Power Handling .............. 150W / Manejo de Potencia RMS MAX Power Handling ............... 500W / Manejo de Potencia MAX Sensitivity (1w/1m) .
- Page 3 TWEETER MEASUREMENTS / ESPECIFICACIONES DEL TWEETER Overall Diameter (without Adapter) / Diámetro Tota l (sin Adaptador) ....1.69" / 43mm Overall Depth (without Adapter) / Profundidad Total (sin Adaptador) ....0.74" / 19mm Front Mount Baffle Cutout / Corte del Orificio de Montaje ........1.92" / 49mm Mounting Depth / Profundidad de Montaje .
- Page 4 EXL-SQ65CX WOOFER 3.14" / 80mm 5.62" / 143mm...
- Page 5 CROSSOVER 2.59” / 66mm 4.72” / 120mm...
- Page 6 EXL-SQ65CX TWEEETER 1.91" / 48.7mm 0.06" / 1.7mm...
- Page 7 TWEEETER 0.06" / 1.7mm 1.94" / 49.3mm...
- Page 8 FOR MORE INFORMATION PLEASE VISIT DS18.COM We LIKE IT LOUD...
