DS18 JP6NEO.FR Owner's Manual

6.5" neodymium loudspeaker with plug & play enclosure for jeep jl/jlu/jt dashboard
Hide thumbs

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
JP6NEO.FR
MANUAL DEL USUARIO
6.5" NEODYMIUM LOUDSPEAKER
WITH PLUG & PLAY ENCLOSURE
FOR JEEP JL/JLU/JT DASHBOARD.
ALTAVOZ DE NEODIMIO DE 6.5" CON CAJA PLUG
& PLAY PARA SALPICADERO DE JEEP JL/JLU/JT.
SPECIALLY MADE FOR:
HECHO ESPECIALMENTE PARA:
ENGLISH | ESPAÑOL

Advertisement

loading
Need help?

Need help?

Do you have a question about the JP6NEO.FR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DS18 JP6NEO.FR

Summary of Contents for DS18 JP6NEO.FR

  • Page 1 OWNER’S MANUAL JP6NEO.FR MANUAL DEL USUARIO 6.5" NEODYMIUM LOUDSPEAKER WITH PLUG & PLAY ENCLOSURE FOR JEEP JL/JLU/JT DASHBOARD. ALTAVOZ DE NEODIMIO DE 6.5" CON CAJA PLUG & PLAY PARA SALPICADERO DE JEEP JL/JLU/JT. SPECIALLY MADE FOR: HECHO ESPECIALMENTE PARA: ENGLISH | ESPAÑOL...

  • Page 2: Herramientas Necesarias

    Please visit DS18.tools for a full Visite DS18.tools para ver un video de installation video. instalación completo.
  • Page 3 DASH DISASSEMBLY / DESMONTAJE DEL TABLERO (FIGURE A) / (FIGURA A) (FIGURE B) / (FIGURA B) 1.Unclip and remove the panel below the steering column. Remove (2) Phillips screw exposed. (Figures A,B) Soltar y quitar el panel debajo de la columna de dirección.
  • Page 4 JP6NEO.FR 5. Remove (8) Phillips screws securing the instrument panel on the left side, and airbag panel on the right side. (Figure F, G) Quite los (8) tornillos Phillips que sujetan el panel de instrumentos en el lado izquierdo y el panel de la bolsa de aire en el lado derecho.
  • Page 5 (FIGURE K) / (FIGURA K) (FIGURE L) / (FIGURA L) 9.Remove (4) 10mm screws and (1) 8mm screw securing the dashboard brace. The brace only needs loosened to aid in removing the speaker pod in the next step. (Figure K, L) Quite (4) tornillos de 10 mm y (1) tornillo de 8 mm que sujetan la abrazadera del tablero.
  • Page 6 JP6NEO.FR PASSENGER SIDE SPEAKER REMOVAL / EXTRACCIÓN DEL ALTAVOZ DEL LADO DEL PASAJERO (FIGURE O) / (FIGURA O) (FIGURE P) / (FIGURA P) 12. Starting from the right side, unclip and 11. Open the passenger door, then unclip and remove the trim panel from the grab-bar. Remove remove the panel on the side of the dash.
  • Page 7 (FIGURE S) / (FIGURA S) (FIGURE T) / (FIGURA T) 16. Unclip and slightly release the airbag panel, 15. Looking in the glovebox cavity up high, remove just enough to expose (3) Phillips screws securing (2) 13mm screws securing the back of the the passenger side dash panel.
  • Page 8 INSTALLING THE PODS / INSTALACIÓN DE LAS CÁPSULAS PASSENGER SIDE SPEAKER REMOVAL / EXTRACCIÓN DEL ALTAVOZ DEL LADO DEL PASAJERO 1.Install the new DS18 pods with the speaker included connecting the supplied speaker connector to the factory speaker harness. (Figure A) Instale las nuevas cápsulas DS18 con el...

  • Page 9: General Specifications

    GENERAL SPECIFICATIONS: Nominal Speaker Diamete ..........6.5" / 165mm Nominal Impedance .

  • Page 10: Especificaciones Generales

    JP6NEO.FR ESPECIFICACIONES GENERALES: Diámetro nominal del bocina ..........6.5" / 165mm Impedancia Nominal .
  • Page 11 DERECHA RIGHT DERECHA WARRANTY GARANTÍA Please visit our website DS18.com for more information Visita nuestra página web DS18.com para obtener más on our warranty policy. información sobre nuestra garantía. We reserve the right to change products and specifications Nos reservamos el derecho de cambiar productos y at any time without notice.
  • Page 12 FOR MORE INFORMATION PLEASE VISIT DS18.COM...
