- Page 1 INSTALLATION INSTRUCTIONS 3" SIDE BAR 2019-2024 TOYOTA RAV4 PART# 3S-T123T www.tacautoparts.com...
- Page 2 3INCH SIDEBAR 2019-2024 TOYOTA RAV4 PARTS LIST: Driver/Left Sidebar 10mm x 30mm x 2,5mm Flat Washers Passenger/Right Sidebar 10mm Lock Washers Driver/Left Front Mounting Bracket 10-1.50mm Hex Nuts Passenger/Right Front Mounting Bracket 8-1.25mm x 40mm Bolt Plates Driver/Left Center Mounting Bracket 8mm Plastic Retainers Passenger/Right Center Mounting Bracket 8mm x 24mm x 2mm Flat Washers...
- Page 3 3INCH SIDEBAR 2019-2024 TOYOTA RAV4 9. Select (1) 10mm L-Shapped Bolt, (Figure 12B). Insert the L-Shapped Bolt into the hole in the inner floor panel. Slide (1) 10mm Plastic Retainer on the threads of the bolt plate to hold the bolt in place, (Figure 12C).
- Page 4 3INCH SIDEBAR 2019-2024 TOYOTA RAV4 Passenger/Right Side Installation Pictured (Fig 2) Passenger/Right Front mounting location (Fig 3) Hold Mounting Brackets up to the mounting locations and mark the plastic cover (Passenger/Right Front pictured) Remove rubber plugs (Fig 4) Passenger/Right Front mounting location, cut along dotted lines (Fig 5) Passenger/Right Center mounting location (Fig 6) Passenger/Right Center mounting...
- Page 5 3INCH SIDEBAR 2019-2024 TOYOTA RAV4 Passenger/Right Side Installation Pictured Rear Rear (Fig 7) Passenger/Right Rear mounting location (Fig 8) Passenger/Right Rear mounting location cut along dotted lines IMPORTANT: Cut the plastic covers enough to allow the mounting brackets to mount against the body Front (Fig 9A) Passenger/Right Front Cover Rear...
- Page 6 3INCH SIDEBAR 2019-2024 TOYOTA RAV4 Passenger/Right Side Installation Pictured Rear Front (Fig 10B) Passenger/Right Front Plastic Cover with cuts (Fig 11) Trim rubber sealing to allow bracket to mount against the body 8mm Bolt Plate 8mm Plastic Retainer 10mm L-Shaped Bolt 10mm Plastic Retainer (Fig 12A) 8mm Bolt Plate Front...
- Page 7 3INCH SIDEBAR 2019-2024 TOYOTA RAV4 Passenger/Right Side Installation Pictured 8mm Bolt Plate 10mm L-Shaped Bolt 8mm Plastic Retainer 10mm Plastic Retainer 8mm Flat Washer Locking Plate 8mm Lock Washer 10mm Flat Washer 8mm Hex Nut 10mm Lock Washer 10mm Hex Nut L-Shaped Bolt Plastic Retainer Locking Plate...
- Page 8 3INCH SIDEBAR 2019-2024 TOYOTA RAV4 Passenger/Right Side Installation Pictured Front (Fig 17) Passenger/Right Center Bracket installed Rear (2) 8mm Bolt Plates (2) 8mm Plastic Retainers (Fig 18) Passenger/Right Rear mounting location (Plastic covers removed for instruction purposes) (2) 8mm Bolt Plates (2) 8mm Plastic Retainers (2) 8mm Flat Washers (2) 8mm Lock Washers...
- Page 9 3INCH SIDEBAR 2019-2024 TOYOTA RAV4 Driver/Left Side Installation Pictured Front (2) 8mm Combo Bolts (Fig 22) Passenger/Right Sidebar installation Front Front (Fig 23) Remove plastic cover Rear (Fig 24) Driver/Left Front Cover (Fig 25) Driver/Left Rear Underside Cover www.tacautoparts.com Page 8 of 8 5/16/19 (AL)
