Aries Offroad B35-2004 Installation Instructions

PARTS LIST:
1 Bull Bar
4 12-1.75mm x 30mm Hex Head Bolts
PROCEDURE:
1. REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT. READ
INSTRUCTIONS CAREFULLY.
2. Locate and remove the factory tow hooks underneath the vehicle (Figure 2). Save hardware
for later use.
3. Locate Passenger Side Mounting Bracket and loosely attach it to vehicle by using the factory
bolts removed in step two (Figure 3). Passenger Side shown in Figure 3. Repeat this step for
Driver Side Mounting Bracket.
4. Once the Mounting Brackets are loosely installed, with help position the Bull Bar on the outer
side of the Mounting Brackets and attach it with the included (4) 12-1.75 mm x 30mm Hex
Head Bolts, (4) 12mm Nylock Nuts, and (8) 12mm Flat Washers (Figure 3).
5. Level and adjust the Bull Bar and tighten all hardware at this time.
Passenger
Side Bracket
Remove
these bolts
INSTALLATION INSTRUCTIONS
TOYOTA TUNDRA 2007-2010
PART NUMBER B35-2004/35-2004
Figure 2
4 12mm lock Nuts
8 12mm Flat Washers
Figure 1
12mm Hardware
Driver Side
Bracket
Factory Bolts
Figure 3
