- Page 1 SQ Series User Manual SQ25/SQ50/SQ100/SQ200 4 channels, 200 MSPS logic analyzer and pattern generator www.ikalogic.com | support@ikalogic.com December 28, 2020...
-
Page 2: Table Of Contents
SQ Series User Manual SQ25/SQ50/SQ100/SQ200 Contents SQ Series overview Typical applications ........ - Page 3 SQ Series User Manual SQ25/SQ50/SQ100/SQ200 Limited warranty & limitation of liability Document Revisions (c) Ikalogic SAS 2019 3/18...
-
Page 4: Sq Series Overview
1.8V to 5V, which covers most TTL, CMOS and LVCMOS applications. SQ Series is composed of four devices: SQ25, SQ50, SQ100 and SQ200. All have 4 channels that can be used to capture and/or generate logic signals. The table below shows the mains di erences... -
Page 5: Typical Applications
SQ Series User Manual SQ25/SQ50/SQ100/SQ200 SQ25 SQ50 SQ100 SQ200 Di erential input pairs Typical applications By combining logic analyzer and pattern generator capabilities in a single low price device, SQ is a perfect solution for students and small design houses. For more channels and more performances, check SP series logic analyzers. - Page 6 SQ Series User Manual SQ25/SQ50/SQ100/SQ200 • Generate test patterns to stimulate a system without any other equipment. (c) Ikalogic SAS 2019 6/18...
-
Page 7: Warning
SQ Series User Manual SQ25/SQ50/SQ100/SQ200 Warning Read safety information section carefully before using this instrument. (c) Ikalogic SAS 2019 7/18... -
Page 8: Main Characteristics
SQ Series User Manual SQ25/SQ50/SQ100/SQ200 Main characteristics Operating conditions Model SQ25/SQ50/SQ100/SQ200 Temperature 10°C to 40°C Relative humidity < 80% non condensing Altitude < 2000m Timing and measurements SQ25 SQ50 SQ100 SQ200 Sampling rate 25 MHz 50 MHz 100 MHz 200 MHz... -
Page 9: Outputs Specifications
SQ Series User Manual SQ25/SQ50/SQ100/SQ200 SQ25 SQ50 SQ100 SQ200 Input voltage range (10 ms pulse) Low level input 0.8V Adjustable Adjustable Adjustable voltage (Max) High level input Adjustable Adjustable Adjustable voltage (Min) Input threshold 100mV 350mV 350mV 350mV hysteresis Outputs specifications... -
Page 10: Principle Of Operation
USB port performance Versatile trigger system SQ series o er a state of the art trigger system. It’s composed of one FlexiTrig®trigger engines, each FlexiTrig engine can be used in one of those modes: •... -
Page 11: What's In The Box
• Protocol based trigger (e.g. I2C bus address or serial UART character) Finally, an external trigger input and output is available via an accessory called TrigBox. What’s in the box SQ series is shipped with the following items: 1. SQ device 2. USB cable (mini-B to A) 3. -
Page 12: So Ware Quick Start Guide
SQ25/SQ50/SQ100/SQ200 So ware Quick Start guide Start by downloading the latest version of ScanaStudio so ware www.ikalogic.com and following instructions to install both so ware and provided drivers. It is recommended to restart your computer a er the so ware and drivers have been installed. -
Page 13: Mechanical Data
SQ Series User Manual SQ25/SQ50/SQ100/SQ200 Mechanical data Weight: 80g ( 5g depending on model) Figure 4: SQ device dimensions (mm) (c) Ikalogic SAS 2019 13/18... -
Page 14: So Ware Technical Requirements
SQ Series User Manual SQ25/SQ50/SQ100/SQ200 So ware technical requirements Download ScanaStudio so ware on www.ikalogic.com so you can use your device on your favorite platform. SQ devices and ScanaStudio were tested to supports the following platforms: • Windows 7/8/10 • Mac OS 10.9 or later •... - Page 15 SQ Series User Manual SQ25/SQ50/SQ100/SQ200 in a particular installation. If this equipment does cause harmful interference to radio or television reception which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures: •...
-
Page 16: Safety Information
SQ Series User Manual SQ25/SQ50/SQ100/SQ200 Safety information This product complies with safety standards IEC NF/EN 61010-1: 2010, IEC NF/EN 61010-2-030 and UL 61010-1: 2015 To prevent possible electrical shock, fire, personal injury, or damage to the product, read all safety information before you use the product. The following international symbols are used on the product and in this manual. -
Page 17: Limited Warranty And Limitation Of Liability
This warranty extends only to the original buyer or end-user customer of an Ikalogic authorized reseller, and does not apply to fuses, disposable batteries or to any product which, in Ikalogic’s opinion, has been misused, altered, neglected or damaged by accident or abnormal conditions of operation or handling. -
Page 18: Document Revisions
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IKALOGIC SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSSES, INCLUDING LOSS OF DATA, WHETHER ARISING FROM BREACH OF WARRANTY OR BASED ON CONTRACT, TORT, RELIANCE OR ANY OTHER THEORY.
