- Page 1 LIUMB050A_eng-00 Instruction Manual for the use and the maintenance of battery and battery charger Original instructions Part E: LPM04 rechargeable battery ULC932B battery charger...
- Page 3 WHICH THE AUTEC CCS IS INTENDED TO BE INSTALLED, to perform an in-depth and accurate risk assessment to determine if the Autec CCS is suitable for operating a Machine in conditions of safety and operational effectiveness, taking into account the conditions...
- Page 4 It is also the responsibility of the Manufacturer and of the design professionals of the Machine on which the Autec CCS is to be installed and used to be certain that the structure, condition, organization and markings of the Machine as installed at the facility is appropriate for and will allow for the safe and reliable use and control of the Machine through the Autec CCS interface.
- Page 5 Laws, Regulations and Standards, even local, and that such Users and other Persons do in fact at all times operate or work with the Autec CCS safely and ONLY in compliance with Autec instructions and warnings and with all applicable Laws, Regulations and Standards, even local.
-
Page 7: Table Of Contents
Conformity with standards ................. 12 Contacts and useful addresses ................. 13 Warranty ......................13 Technical assistance and spare parts ..............13 LPM04 rechargeable battery ................... 14 Technical data ....................14 Plate ......................... 14 Warnings for use ....................15 First aid ......................16 Instructions for use ................... -
Page 8: Information On The Use Of Instructions
(Part A) of the Manual provided with the CCS. Structure of the Instruction Manual The Manual for the use and maintenance of Autec CCSs consists of different parts, that altogether form the Manual; the Manual must be read carefully, understood and applied by the CCS's Owner, User and by all those Persons that, for any reasons, may operate with the CCS or with the Machine where it is installed. - Page 9 Autec CCS and of the Machine, system, device or Machinery system where the CCS is installed. The Manufacturer of the Machine on which the Autec CCS is installed, and the Owner and User of the Machine, must make sure that the Instruction Manual and all of its parts are included in the Instruction Manual of the Machine.
-
Page 10: Caption And Terminology
Caption and terminology Contact Autec if any of the instructions, symbols, warnings or images are not clear and understandable. In this part of the Manual, the terms listed below have the same meaning explained in the corresponding paragraph of the general part (Part A):... -
Page 11: To Whom The Instructions Are Addressed
Regulation for the storage of instructions are described in the paragraph with the same title in the general part: please refer to that part. Intellectual property Restrictions connected to intellectual property are described in the paragraph with the same title in the general part: please refer to that part. AUTEC LIUMB050A_eng-00... -
Page 12: Brief Product Presentation
Brief product presentation Battery and battery charger The object of this part of the Manual is the LPM04 battery, that is meant to be used inside an Autec CCS's Remote station, and the corresponding ULC932B battery charger, that is needed to recharge it. -
Page 13: Contacts And Useful Addresses
Contacts and useful addresses The CCSs are produced by Autec Srl – Via Pomaroli, 65 - 36030 Caldogno (VI) - Italy. You can find contacts for Autec, its distributors, dealers and authorized service centres on the website www.autecsafety.com. Warranty General warranty conditions are indicated both in the relevant sheet provided together with this documentation, and in the specific page on the website www.autecsafety.com. -
Page 14: Lpm04 Rechargeable Battery
LPM04 rechargeable battery The LPM04 rechargeable battery is used to provide power to Autec Remote stations with compatible battery housing (please check this in "Part C" of the Instruction Manual). Contacts Technical data plate Technical data Type Li-ion Voltage 7.4V... -
Page 15: Warnings For Use
Do not charge, use or store the battery at temperatures exceeding the limits provided in paragraphs 3.1 and 3.6. The LPM04 battery cannot be used by People with reduced physical, sensory or mental capabilities, and by children. Do not leave the battery under charge if the charge cycle does not end within the “Max. -
Page 16: First Aid
The battery must be charged in the "SAFE AREA", i.e. without explosion-risk gases and/or dusts. Autec cannot be held responsible for any use that does not comply with the provisions and directions provided in the Manual, and for any damage that may result from improper, incorrect or irrational use of the battery. -
Page 17: Instructions For Use
For example, if storing at a temperature from -20 to 25°C (from -4 to 77°F), it is recommended to run a charge-discharge cycle of the battery every 90 days. After each charge-discharge cycle, bring the battery back to the ideal half charge condition before storing it again. AUTEC LIUMB050A_eng-00... -
Page 18: Shipping And Transportation
After long idle periods, it may be needed to carry out several battery discharge/ charge cycles to achieve the best performance. Shipping and transportation Refer to standards UN 3480 and UN 3481 to ship and transport Li-ion batteries. LIUMB050A_eng-00 AUTEC... -
Page 19: Battery Disposal
The crossed-out wheeled bin marked on batteries indicates that they must be disposed of separately from household waste, in conformity with the EU Directive 2006/66/EC and its amendments, and with local regulations. AUTEC LIUMB050A_eng-00... -
Page 20: Ulc932B Battery Charger
ULC932B battery charger The ULC932B battery charger is used to charge the LPM04 rechargeable battery used in Autec CCSs. Power supply cable Jack plug Socket Contacts LEDs Technical data plate Technical data Power supply voltage 12-24V Absorbed current 0.8-0.4A Output voltage 8.3V... -
Page 21: Plates
The ULC932B battery charger can be powered by a 12/24V battery, with a power supply unit equipped with safety isolating transformer or with the mains adapter provided by Autec. Never use the battery charger and/or the mains adapter if they are damaged. -
Page 22: Positioning
(max. 4mm/0.16In diameter). It is also possible to fix the power supply cable so that it will not be torn: when fixing the device, place the cable as shown in the figure. LIUMB050A_eng-00 AUTEC... -
Page 23: Warnings For Use
Autec cannot be held responsible for any use that does not comply with the provisions and directions provided in the Manual, and for any damage that may result from improper, incorrect or irrational use of the battery charger and/or of the mains adapter. -
Page 24: Instructions For Use
NOTE: do not force insertion. The battery slides easily into place and ensures that the positive (+) and negative (-) poles are correctly connected only if it is inserted with the plate facing the compartment, so that the battery's contacts match the battery charger 's contacts. LIUMB050A_eng-00 AUTEC... -
Page 25: Disposal
Disposal When disposing of a battery charger, its components must be managed as separate waste. When disposing of a battery charger, please comply with the provisions and/or the regulations in force in the country where it is used. AUTEC LIUMB050A_eng-00... -
Page 26: Malfunctions
Move the battery to a place The battery temperature is not whose temperature is within the within the “Charge temperature” “Charge temperature” range and range provided in paragraph 3.1. allow it to stabilize. Then charge the battery. LIUMB050A_eng-00 AUTEC... - Page 27 Remote station with a Battery run time is significantly Dirty contacts on the battery and/ non-abrasive cloth or brush and a shorter than normal. or on the Remote station. generic electrical contact cleaner. Then charge the battery. AUTEC LIUMB050A_eng-00...
- Page 28 If the problem persists after attempting the suggested solution, contact the support service of the Machine Manufacturer. LIUMB050A_eng-00 AUTEC...
- Page 32 Via Pomaroli, 65 - 36030 Caldogno (VI) - Italy Tel. +39 0444 901000 - Fax +39 0444 901011 info@autecsafety.com - www.autecsafety.com MADE IN ITALY...
