AUSTRALIAN MONITOR AMIS HE2 Introduction

Dual Channel Hum Eliminator
Introduction
The Australian Monitor Installation Series HE2 hum eliminator is a low cost
tool for eliminating hum & signal noise caused by ground loops. The AMIS
HE2 provides two discreet signal paths via balanced XLR inputs & outputs.
The AMIS HE2 is a passive device & can also be used as a converter of
balanced & unbalanced signals. As part of the AMIS Contractor Tools
range, the AMIS HE2 is an inexpensive hum eliminator that has a multitude
of uses in a wide variety of installations.

Description

• Inputs: This balanced XLR input receives signal from a mic or other
source.
• Output: This XLR output provides a transformer isolated output of the
input signal feed.

Specifications

Frequency Response:
THD:
Insertion Loss
Dimensions:
AMISHE2
10Hz-50kHz
<.01% @ 1kHz
4dB @ 100K ohm load
113mm x 75mm x 40mm
