LEXGO L30 MAX User Instruction

Hide thumbs

Advertisement

Table of Contents

USER INSTRUCTION
THIS USER INSTRUCTION APPLIES TO LEXGO ESCOOTER OF L10/L20/L30
ORIGINAL INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L30 MAX and is the answer not in the manual?

Questions and answers

Related Manuals for LEXGO L30 MAX

Summary of Contents for LEXGO L30 MAX

  • Page 1 USER INSTRUCTION THIS USER INSTRUCTION APPLIES TO LEXGO ESCOOTER OF L10/L20/L30 ORIGINAL INSTRUCTIONS...
  • Page 4 WHAT’S IN THE Charger BOX? Charging cable NFC bracelet NFC card Screws Allen keys Pump adapter...
  • Page 5 L20 LITE (L30 LITE, L30 MAX)

  • Page 6: Install & Connect

    INSTALL & CONNECT INSTALL THE HANDLEBAR INTO STEM TUBE. APPLY SCREWS IN AND TIGHTEN THEM WITH 1. CONNECT TOOLS SUPPLIED. THE CABLES, HEAD TO HEAD...
  • Page 7 NFC ACTIVATION IMPORTANT: PLEASE ACTIVATE YOUR NFC TAG BEFORE FIRST USE. QUICK-PRESS TIMES POWER ON SCOOTER, ON POWER BUTTON, TO HAVE A SPINNING CIRCLE IN DASHBOARD. GET THE NFC CARD OR BRACELET CLOSE TO NFC INDUCTION AREA TO ACTIVATE IT, TO GET A LIGHTUP GREEN CIRCLE. NFC INDUCTION AREA UNLOCK YOUR ESCOOTER •...
  • Page 8 VIRTUAL WHAT IF I LOST ALL PASSWORD MY NFC TAGS OR I FORGOT THEM WITH ME? UNLOCK NO WORRIES! USE PASSWORD PRESS TIMES THE INITIAL PASSWORD: UNLOCK SCOOTER BY VIRTUAL PASSWORD 1. POWER ON SCOOTER. 2. PRESS THROTTLE TO CHANGE THE NUMBER ON DASHBOARD, THEN PRESS POWER BUTTON ONCE TO GET THE 1ST DIGIT. 3.
  • Page 9 SET A NEW PASSWORD RESET A NEW PASSWORD WE HIGHLY SUGGEST THAT YOU SHOULD BEFORE YOUR FIRST USE! OTHERWISE YOU MAY LOSE YOUR SCOOTER! POWER ON SCOOTER. UNLOCK IT BY NFC OR INITIAL PASSWORD. ENTER PASSWORD SETTING MODE RESET NEW PASSWORD PRESS THROTTLE TO CHANGE THE DIGIT ON DASHBOARD 5 TIMES PRESS POWER BUTTON...
  • Page 10 STEM PASSWORD (Available only for some models) RIGHT PUSH TO NEW PASSWORD SET A 0000 THE INITIAL STEM PASSWORD: WE HIGHLY SUGGEST THAT YOU SHOULD RESET A NEW PASSWORD! 1. TURN TO INITIAL PASSWORD. 2. PUSH THE SETTING BUTTON TO THE RIGHT. 3.
  • Page 11 HOW TO LOCK? TURN THE NUMBER WHEELS RANDOMLY TO LOCK. TURN THE NUMBER WHEELS TO 0000. BIND THE LOCK STEEL WIRE TO PULL OUT THE STEEL WIRE. A POLE AND PLUG INTO THE LOCK HOLE. HOW TO UNLOCK? TURN THE NUMBER WHEELS TO 0000. PRESS DOWN PRESS AND HOLD THE LOCK BUTTON AND TAKE THE STEEL WIRE FROM THE HOLE.

  • Page 12: Operation Command

    OPERATION COMMAND SMART SWITCH IS LEXGO’S UNIQUE AND SPECIAL FEATURE FOR CONTROLLING OUR ECO-SYSTEM DEVICE, SUCH AS SMART HELMET, ETC. VOLUME - /PREV SONG POWER BUTTON ONCE ON/OFF CONTROL: PRESS TO THE PREVIOUS SONG. PRESS SECONDS LONG PRESS FOR VOLUME -.
  • Page 13 HANDLEBAR HOW TO OPERATE BRAKE BATTERY INDICATOR DASHBOARD SMART SWITCH THROTTLE SPEEDMETER SPEED MODE...
  • Page 14 DASHBOARD 1. HEADLIGHT ON 2. LEFT TURNING 3. RIGHT TURNING 0 0 0 1 4 4. BATTERY INDICATOR 5. PHONE CALL 6. HELMET CONNECTED 7. TRIP RANGE ACCUMULATED RANGE 8. ERROR ICON 9. CRUISE CONTROL MODE 10. SPEED MODE 11. SPEED 12.
  • Page 15 PRESS TRIPLE (ONLY L10) NFC ACTIVATION PRESS 4 TIMES RESET VIRTUAL PASSWORD PRESS 5 TIMES BLUETOOTH ON/OFF PRESS 6 TIMES CHANGE SPEED UNIT PRESS 7 TIMES (KM/H AND MPH) THE USER GUIDE APPLIES TO LEXGO SCOOTER MODELS INCLUDING L10/L11/L20 LITE/L20/L30/L30 LITE/L30 MAX...
  • Page 16 START KICK TO A SPEED OVER 3KMH OR 1.8MPH. PRESS THROTTLE,TWO FEET STANDING ON DECK NOTE : THE SCOOTER WON'T START BY PRESSING THROTTLE IN STILL STATUS FOR SAFETY PROTECTION. MAKE TURNS SHIFT YOUR BODY WEIGHT AND TURN THE HANDLEBAR SLIGHTLY...
  • Page 17 ACCELERATION & BRAKE THROTTLE PRESS TO ACCELERATE. BRAKE PRESS TO BRAKE. IMPORTANT HINT: WHEN BATTERY IS IN LOW LEVEL, OF THE FLASHING BATTERY INDICATOR ON DASHBOARD, THE SPEED LIMITATION FUNCTION WILL BE ACTIVATED. YOUR ACCELERATION WILL BE LIMITED, AND THE MAX SPEED WILL BE SLOWER. PLEASE CHARGE YOUR SCOOTER IMMEDIATELY.

  • Page 18: Cruise Control

    CRUISE CONTROL TWICE QUICKLY PRESS THE THROTTLE TO BOTTOM TO START CRUISE CONTROL OVER SPEED AT 5 KMH OR 3.2MPH. ANY BRAKING OR THROTTLE ACCELERATION WILL END IT. DOUBLE CLICK HINT: YOU ARE STRONGLY SUGGESTED TO USE CRUISE CONTROL FUNCTION ONLY WHEN YOU ARE IN OPEN SPACE WITHOUT ANY OTHER TRAFFIC.
  • Page 19 SMART LEXGO IS THE FIRST ONE TO BUILD AN ECO-SYSTEM OF SMART ACCESSORIES CONNECTING TO LIGHT VEHICLE FOR SAFER RIDING. SOME OF OUR PRODUCTS ARE EQUIPPED WITH OUR INNOVATIVE TECHNOLOGY OF SMART HELMET HELMET FUNCTION. THIS FUNCTION ENABLES YOU TO RIDE YOUR SCOOTER OF MORE SAFETY AND CONVENIENCE, WHICH IS AWARDED BY CLASSEDITORI AS 100 TOP PRODUCTS 2023.
  • Page 20 HOW TO CONNECT SMART HELMET TO SCOOTER FOR FIRST USE? POWER ON AND UNLOCK SCOOTER 3 TIMES PRESS PHONE BUTTON, THEN PRESS BUTTON TO GET YOUR SCOOTER IN PAIRING MODE, WITH A FLASHING HELMET ICON ON DASHBOARD. POWER ON HELMET, HELMET AUTOMATICALLY PAIRS TO VEHICLE. FRONT LIGHT ON HELMET STAYS IN WHITE, AND REAR LIGHT FLASHES IN RED.
  • Page 21 SAFE FOLDING FOR MODELS:L10/L11 PRESS DOWN PRESS THE REAR FENDER TO UNLOCK THE HOOK HOOK THE LOCK BY LIFTING THE STEM PUSH THE BUTTON UP, AND PRESS LEVER DOWN TO PUSH LEVER BACK TO THE STEM AND LOCK IT THE RIGHT POSITION TO UNLOCK THE FOLDING SYSTEM...
  • Page 22 SAFE FOLDING FOR MODELS:L20/L30 UNLOCK THE HOOK FROM THE REAR FENDER HOOK THE LOCK BY LIFTING THE STEM PUSH THE BUTTON UP, AND PRESS LEVER DOWN TO PUSH LEVER BACK TO THE STEM AND LOCK IT THE RIGHT POSITION TO UNLOCK THE FOLDING SYSTEM...
  • Page 23 FOLDING MAINTENANCE THE FOLDING MECHANISM IS A CRITICAL AND KEY PART OF THE SCOOTER. A TIGHT FOLDING MECHANISM IS THE FIRST IMPORTANT GUARANTEE TO A SAFE RIDING. PLEASE MAKE SURE IT IS ALWAYS IN A TIGHT AND SOLID STATUS. THE FOLDING MECHANISM MAY BE LOOSENED A LITTLE AFTER LONG-PERIOD USE OR VIOLENT USE. PLEASE CHECK BEFORE EACH RIDE TO MAKE SURE THAT THE FOLDING MECHANISM IS IN SOLID CONDITION.
  • Page 24 SAFETY WARNING!!! MAKE SURE TO HAVE A RIGHT AND TIGHT LOCKING WHEN FOLDING! WHEN FOLDING, PLEASE MAKE SURE THE FOLDING LEVER IS IN RIGHT POSITION TO RESULT IN A COMPLETE LOCK. LOCK LEVER NOT OPEN LOCK LEVER NOT OPEN ENOUGH LOCK LEVER IN OPEN POSITION HEAR A CLICK!!! NOT COMPLETELY HOOKED!
  • Page 25 CHARGING ● USE ONLY THE CHARGER PROVIDED. ● DO NOT TURN ON THE SCOOTER DURING CHARGING. ● ENSURE THE BATTERY BEING CHARGED FOR 4-5 HOURS TO GET A FULL CHARGE. ● REMOVE CHARGER IN TIME. PLEASE DON’T LEAVE THE SCOOTER BEING CHARGED ALONE OR LEAVE IT IN CHARGING FOR OVERNIGHT!!! Charger indicator CHARGING PORT Charging...
  • Page 26 TECH SPEC L20 LITE L30 LITE L30 MAX Tire Type 8"solid tyre 8.5"air tyre 8.5"air tyre 8.5"air tyre 10"air tyre 10"air tyre 10"air tyre Display Full function color LED display Motor (W) 250W 350W 350W 350W 350W 400W 400W Battery V/Capacity 36V 5.2Ah 187WH 36V 7.5Ah 270WH 36V 6Ah 216WH...

  • Page 27: Error Diagnostics

    ERROR DIAGNOSTICS CODE ICON ERROR NO STORAGE FOR TOTAL MILEAGE HALL ERROR THROTTLE ERROR MOTOR BLOCKED ERROR SHORT CIRCUIT ERROR CONTROLLER ERROR DASHBOARD COMMUNICATION ERROR BATTERY OVER-VOLTAGED ERROR MOTOR OVER-TEMPERATURE ERROR BRAKE ERROR...

  • Page 28: Safety Instruction

    SAFETY INSTRUCTION IMPORTANT! READ CAREFULLY AND KEEP FOR FUTURE REFERENCE. WARNING! KEEP PLASTIC COVERING AWAY FROM CHILDREN TO AVOID SUFFOCATION. WARNING! NEVER USE THE PRODUCT OUT OF THE SPACES AUTHORIZED BY THE REGULATIONS OF EN17128: 2020 CLASS 2. IMPORTANT HINTS: THE MAXIMUM SPEED OF THE SCOOTER IS 20KM/H OR 25KM/H. WE MAKE DIFFERENT SPEED SETTING BASED ON THE FINAL SALES TERRITORIES TO FOLLOW THE REGULATIONS.
  • Page 29 DURING THE RIDE • DON’T ALLOW HANDS, FEET, HAIR, BODY PARTS, CLOTHING, OR SIMILAR ARTICLES TO COME IN CONTACT WITH MOVING PARTS, WHEELS, OR DRIVE TRAIN, WHILE THE MOTOR IS RUNNING. • DO NOT PERFORM RACING, STUNT RIDING, OR OTHER MANEUVERS, WHICH MAY CAUSE LOSS OF CONTROL, OR MAY CAUSE UNCONTROLLED USER OR PASSENGER ACTIONS OR REACTIONS.
  • Page 30 • IF THE FOLDING MECHANISM IS SHAKY OR LOOSEN, PLEASE TIGHTEN IT IMMEDIATELY BY INSTRUCTION IN THIS BOOK. • COMPONENTS SHALL BE MAINTAINED AND REPAIRED IN ACCORDANCE WITH LEXGO SPECIFICATIONS AND ONLY THE LEXGO AUTHORIZED REPLACEMENT PARTS WITH INSTALLATION PERFORMED BY DEALERS OR OTHER SKILLED PERSONS SHOULD BE USED.
  • Page 31 Declaration of Conformity (DOC) Yueyang aidaxing intelligent technology limited hereby declares that this equipment complies with the basic requirements of Directive 2014/30/EU and other relevant provisions. Limited Warranty Statement Any questions, please do not hesitate to contact our customer service hotline. Customer service：...
  • Page 33 GOPAL is the trademark owner of LEXGO. All specifications are subject to GOPAL without prior notice.
