Test Report

Radiated Emissions, 30MHz to 1GHz

Test Requirement:
Test Method:
Frequency Range:
Measurement Distance:
Class / Severity:
Limit:
Detector:

E.U.T. Operation

Operating Environment:
Temperature:
EUT Operation:

Measurement Data

An initial pre-scan was performed in the chamber using the spectrum analyser in peak detection
mode. Quasi-peak measurements were conducted based on the peak sweep graph. The EUT was
measured by BiConiLog antenna with 2 orthogonal polarities.
This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for
electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and
jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company's findings at the time of its intervention only and within the limits of
Client's instructions, if any. The Company's sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the
transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or
appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law.
Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only.
SGS Hong Kong Ltd. 5/F - 8/F & 28/F -29/F, Metropole Square, 2 On Yiu Street, Siu Lek Yuen, Shatin, N.T., Hong Kong. t (852) 2334 4481-9 f (852) 2764 3126 www.hk.sgs.com
No. 2024608/EE
FCC Part15 B
ANSI C63.4
30MHz to 1GHz
3m
Class B
40.0 dBµV/m between 30MHz & 88MHz
43.5 dBµV/m between 88MHz & 216MHz
46.0 dBµV/m between 216MHz & 960MHz
54.0 dBµV/m above 960MHz
Peak for pre-scan (120kHz resolution bandwidth)
Quasi-Peak if maximised peak within 6dB of limit
24.0 °C Humidity:
Test the EUT in Communicate with XBOX 360 mode, build the connection between
EUT and XBOX 360, keep EUT working normally.
Date : Sep 08 2011
50 % RH Atmospheric Pressure:
Page 11 of 19
1004 mbar
