Hookup Diagrams
Stereo Speaker Hookup
Connect the powered speaker to the passive speaker and a source device for stereo audio output.
Bluetooth Stereo Speaker Hookup
Connect wirelessly to a Bluetooth device for stereo audio streaming.
Front & Rear Panel Descriptions
Power Connector
Connect the supplied AC power cord to this IEC jack for powering the monitor.
Power Switch
Turns the monitor on and off. The front panel logo illuminates when powered.
Inputs
Connect a line-level signal from a computer, mixer, or other audio source.
Stereo Input
Connect a line-level signal from devices like MP3 players or smartphones.
Location Select
Adjusts monitor performance based on proximity (desktop vs. bookshelf).
Powered Speaker Position Select
Selects whether the powered monitor is on the left or right side of the setup.
Wire Terminals
Connect speaker wires from the powered to the passive monitor.
Phones Output
Connect stereo headphones for private listening.
Tone Knob
Adjusts the overall tone of the audio playback.
Volume Knob
Adjusts the global output level and powers the monitor on/off.
Bluetooth
Enables pairing, connecting, and controlling audio playback via Bluetooth.
