- Page 1 Installation and user manual 5SX 1250VA Rack 2U 5SX 1750VA Rack 2U 5SX 3000VA Rack 2U Copyright © 2015 EATON All rights reserved. 5SX 1~3 KVA EU_EN 5SX 1~3 KVA US_EN Page 1...
- Page 2 • I EC 62040-4: Environmental aspects - Requirements and reporting CE mark CE compliance contact : Eaton I.F. - 110 rue Blaise Pascal - 38330 Montbonnot Saint Martin - France The EC Declaration of Conformity is available upon request for products with a CE mark.
- Page 3 During the replacement of the Battery Module, it is imperative to use the same type and number of • element as the original Battery Module provided with the UPS to maintain an identical level of performance and safety. In case of doubt, don't hesitate to contact your EATON representative. 5SX 1~3 KVA US_EN Page 3...
-
Page 4: Table Of Contents
1. Introduction ................5 1.1 Environmental protection ................... 5 2. Presentation ................6 2.1 Standard installations ....................6 2.2 Rear panels ........................7 2.3 Control panel ......................... 8 2.4 LCD description ......................8 2.5 UPS setting through the LCD ..................9 3. -
Page 5: Introduction
Before installing your 5SC, please read the booklet presenting the safety instructions. Then follow the indications in this manual. To discover the entire range of EATON products and the options available for the 5SC range, we invite you to visit our web site at www.eaton.com/powerquality or contact your EATON representative. -
Page 6: Presentation
2. Presentation 2.1 Standard installations Rack installation Description Weights Dimensions (kg/lb) W*H*D (mm/inch) 5SX 1250VA Rack 2U 24.9/54.7 441.2*86.2*522 / 17.4*3.4*20.5 5SX 1750VA Rack 2U 26.4/58.7 441.2*86.2*522 / 17.4*3.4*20.5 5SX 3000VA Rack 2U 34.5/75.9 441.2*86.2*647 / 17.4*3.4*25.5 5SX EBM 48V 2U 30.3/66.4... -
Page 7: Rear Panels
2.2 Rear panels & 5SX 1250VA Rack2U 5SX 1750VA Rack2U (1) USB communication port (2) RS232 communication port (3) Connector for automatic recognition of optional battery modules (4) Slot for optional communication card (5) Connector for ROO (remote ON/OFF) or RPO (Remote Power Off) control ⑧... -
Page 8: Control Panel
2.3 Control panel The UPS has a three-button LCD. It provides useful information about the UPS itself, load status, events, measurements and settings. (12) ON/OFF button (13) Scroll down ⑫ (14) Mute alarm ⑫ ① ⑭ 2.4 LCD description ⑰ ⑯... -
Page 9: Ups Setting Through The Lcd
2.5 UPS setting through the LCD Release scroll down button to select menu (1) In low sensitivity mode (Lo) UPS will tolerate more fluctuations in power and will go on battery power less often. If the connected load is sensitive to power disturbances, keep the sensitivity as Standard (Std). LCD shut off if no activity for 3 minutes. -
Page 10: Installation
3. Installation 3.1 Unpacking and contents check ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ 5SX UPS ( 2 4 ( 2 4 ) ) ) ) ( 2 4 ( 2 4 2 supports for tower position ( 2 5 ( 2 5 ) ) ) ) ( 2 5... -
Page 11: Installation Of Rack Models
Use provided screws on step 36 of installation. Using a longer screw could present a safety risk. ○ ○ ○ ○ ○ ○ ○ ○ ○ The rails and necessary hardware are supplied by EATON. Page 11 5SX 1~3 KVA AUS_EN... -
Page 12: Installation Of Tower Models
U P S . ○ The UPS can now communicate with EATON power management software. Installation of the communication cards (optional) It is not necessary to shut down the UPS before installing a communication... - Page 13 • Pins 1, 3, 4, 5, 6, 10: not used Characteristics of the contact RS232 communication port • Pin 2: common (user) • Pin 7: low battery • Pin 8: operation on battery power • Pin 9: UPS ON, equipment supplied n.o.: normally open contact When a signal is activated, the contact is closed between the common (pin 2) and the pin for the corresponding signal.
-
Page 14: Ups Remote Control Functions
3.5 UPS remote control functions The 5P offers a choice between two remote control functions. • RPO: Remote Power Off allows a remote contact to be used to disconnect all the equipment connected to the UPS. Restarting the UPS requires manual intervention. •... -
Page 15: Operation
4. Operation 4.1 Start-up and Normal operation To start the UPS: 1. Verify that the UPS power cord is plugged in. 2. Press the button on the UPS front panel for at least 2 seconds. 3. Check the UPS front panel display for active alarms. If the indicator is on, do not proceed until all alarms are cleared. -
Page 16: Maintenance
5. Maintenance 5.1 Troubleshooting Operation status Possible cause Action Remove some of the equipment Power requirement exceeds the UPS capacity Overload from the UPS. The UPS continues (greater than 105 % of nominal). to operate, but may shutdown if the load increases.The alarm resets when the condition becomes inactive. -
Page 17: Battery-Module Replacement
M o u n t i n g t h e n e w b a t t e r y m o d u l e Carry out the above instructions in reverse order. • To ensure safety and high performance, use only batteries supplied by EATON. • Take care to firmly press together the two parts of the connector during remounting. -
Page 18: Appendices
6. Appendices 6.1 Technical specifications 5SX 1250VA 5SX 1750VA 5SX 3000VA Rack 2U Rack 2U Rack 2U Output Power 1250 VA 1750 VA 3000 VA @ 240 V 1125 W 1575 W 2700 W AC Input power Rated input voltage Single phase 220-240 V Input voltage range 184 to 276 V... -
Page 19: Glossary
6.2 Glossary Time during which the load can be supplied by the UPS operating on battery power. B a c k u p t i m e B a c k u p t i m e B a c k u p t i m e B a c k u p t i m e Internal UPS test to check battery status.
