Summary of Contents for Eaton 5SC 500i
- Page 1 Installation and user manual 5SC 500i 5SC 750i 5SC 1000i 5SC 1500i Copyright © 2013 EATON All rights reserved. Service and support: Call your local service representative 619-00470-01-i (en)
-
Page 2: Special Symbols
Flickers emission: IEC 61000-3-3 edition 2: 2008 The EC Declaration of Conformity is available upon request for products with a CE mark. For copies of the EC Declaration of Conformity, contact Eaton Power Quality or check Eaton website: www.powerquality.eaton.com Special Symbols... -
Page 3: Table Of Contents
Contents 1. Introduction ..................4 1.1 Environmental protection ....................4 2. Presentation ..................5 2.1 Standard installation ......................5 2.2 Rear panels ........................5 2.3 Control panel ........................6 2.4 LCD description .........................6 2.5 UPS setting through the LCD ....................6 3. Installation ..................7 3.1 Unpacking and contents check ..................7 3.2 Communication ports ......................8 4. -
Page 4: Introduction
Before installing 5SC, please read the booklet presenting the safety instructions. Then follow the instructions in this manual. To discover the entire range of EATON products and the options available for the 5SC range, we invite you to visit our web site at www.eaton.com/powerquality or contact your EATON representative. -
Page 5: Presentation
2.1 Standard installation Description Weights (kg/lb) Dimensions (mm/inch) D x W x H 5SC 500i 6.60 / 14.60 240 x 150 x 210 / 9.4 x 5.9 x 8.3 5SC 750i 10.40 / 22.90 340 x 150 x 210 / 13.4 x 5.9 x 8.3 5SC 1000i 11.10 / 24.50... -
Page 6: Control Panel
2. Presentation 2.3 Control panel The UPS has a three-button LCD. It provides useful information about the UPS itself, load status, events, measurements and settings. ON/OFF button Scroll down Mute alarm 2.4 LCD description UPS ON AVR mode Battery mode Internal fault Output load level Battery level... -
Page 7: Installation
3. Installation 3.1 Unpacking and contents check (1) 5SC UPS (2) Quick start and safety instructions (3) User manual and IPSS (Intelligent Power Software Suite) CDROM (4) 2 connection cables for the protected equipment (5) RS232 communication cable (6) USB communication cable Packing materials must be disposed of in compliance with all local regulations concerning waste. -
Page 8: Communication Ports
(6) to the USB (1) or RS232 (2) communication port on the UPS. The UPS can now communicate with EATON power management software. Characteristics of the optocoupler RS232 communications port • Pins 1, 3, 4, 5, 6, 10: not used • Pin 2: common (user) -
Page 9: Operation
4. Operation 4.1 Start-up and Normal operation To start the UPS: 1. Verify that the UPS power cord is plugged in. 2. Press the button on the UPS front panel for at least 2 seconds. 3. Check the UPS front panel display for active alarms. If the indicator is on, do not proceed until all alarms are cleared. -
Page 10: Maintenance
5. Maintenance 5.1 Troubleshooting Operation status Possible cause Action Overload Power requirement exceeds the Remove some of the equipment UPS capacity (greater than 105 % of from the UPS.The UPS continues nominal). to operate, but may shutdown if the load increases.The alarm resets when the condition becomes inactive. -
Page 11: Battery-Module Replacement
Mounting the new battery module Carry out the above instructions in reverse order. ● To ensure safety and high performance, use only batteries supplied by EATON. ● Take care to firmly press together the two parts of the connector during remounting. -
Page 12: Appendices
6. Appendices 6.1 Technical specifications Transformer Filter "AVR" Charger Inverter Battery 5SC 500i 5SC 750i 5SC 1000i 5SC 1500i Output Power 500 VA 750 VA 1000 VA 1500 VA @ 230 V 350 W 525 W 700 W 1050 W AC Input power • Rated input voltage...
