- Page 1 SigenStor Home User Manual Three-phase System Version: 01 Release date: 2024-01-30 1 / 36...
- Page 2 Therefore, description in this document is provided for reference purpose only and constitutes neither an offer nor an acceptance. Sigenergy Technology Co., Ltd. may change the information at any time without notice.
-
Page 3: Table Of Contents
Contents 2.1 Product Introduction ......................9 2.2 Appearance Introduction ....................12 Appearance and Dimensions ..................12 Port Introduction ......................13 2.3 Label Description ........................ 14 2.4 Introduction to Typical Networking .................. 15 5.1 Working Mode........................24 5.2 LED Indicator State ......................24 5.3 mySigen App Query ...................... - Page 4 User Manual Revision History Version Date Description 2024.01.30 First official release. 4 / 36...
- Page 5 User Manual Overview Introduction This document mainly introduces the product introduction, networking, system operation and maintenance of the devices in the SigenStor Home Three-phase system. Readers This document is suitable for product users and professionals Sign Definition The following signs may be used in the document to indicate security precautions or key information.
- Page 6 User Manual Safety Precautions Basic Information Before installing, operating, and maintaining the equipment, familiarize yourself with this document. The "Danger ", "Warning", "Caution" items described in this manual are only supplementary to all precautions. The Company shall not be liable for equipment damage or property loss caused by the following reasons: Failure to obtain approval from the national, regional power authority.
- Page 7 User Manual Equipment damage caused by improper operations such as disassembling, replacing, or modifying the software code without authorization. Equipment damage caused by force majeure (such as war, earthquake, fire, storm, lightning, flood, debris flow, etc.). Damage caused by the failure of the natural environment or external power ...
- Page 8 User Manual Do not use the equipment if it has any defects. If the equipment appears abnormal (for example, battery pack leakage or appearance distortion), contact your installer. Carbon dioxide fire extinguishers and ABC dry powder fire extinguishers are ...
-
Page 9: Product Introduction
User Manual Introduction to energy storage system Product Introduction Inverter Product Function Model No. Name code specification Sigen Energy Controller SigenStor EC 5.0 TP 5.0 kW Three Phase Sigen Energy Controller SigenStor EC 6.0 TP 6.0 kW Three Phase Inverter; it can Sigen Energy Controller SigenStor EC 8.0 TP be used in... - Page 10 User Manual Sigen Storage Controller SigenStor AC 12.0 TP 12.0 kW Three Phase Sigen Storage Controller SigenStor AC 15.0 TP 15.0 kW Three Phase Sigen Storage Controller SigenStor AC 17.0 TP 17.0 kW Three Phase Sigen Storage Controller SigenStor AC 20.0 TP 20.0 kW Three Phase Sigen Storage Controller SigenStor AC 25.0 TP...
- Page 11 User Manual Power Sensor Product Function Model No. Name code specification Sigen Sensor TP-DH Sigen Power Sensor （SDM630MODBUS V2） Three Phase DH Sigen Power Sensor Sigen Sensor Data Three Phase TP-CT120-DH(SDM630MCT acquisition External CT 120 A 40mA/120A) for grid connection Power Sigen Power Sensor points...
-
Page 12: Appearance Introduction
User Manual 2.2 Appearance Introduction Appearance and Dimensions Inverter and Battery Pack CommMod 12 / 36... -
Page 13: Port Introduction
User Manual Port Introduction SigenStor EC/ SigenStor AC/Sigen Hybrid Left View Name Marking Decorative cover strip light connector Network interface RJ45 1/ RJ45 2 DC input interface PV1+/PV2+/ PV3+/PV4+/ PV1-/PV2- /PV3-/PV4- AC output interface Communication interface Ground screw Switch button ON/OFF DC switch DC SWITCH... -
Page 14: Label Description
User Manual 2.3 Label Description Symbols Definition Warning! Life at risk. The equipment has potential hazards after running. Take proper protection when operating the equipment. After the equipment is powered off, the discharge of internal components is delayed. Wait 10 minutes until the equipment is fully discharged according to the label time. -
Page 15: Introduction To Typical Networking
User Manual Introduction to Typical Networking Our company’s products can be used for Home energy storage system. The Home energy storage system consists of photovoltaic panels, inverters, battery packs, master control switches, loads, power grids, etc. The main function of Home energy storage system is to store the direct ... - Page 16 User Manual Whole Home Backup Networking Diagram ( A. PV panel SigenStor EC/SigenStor AC /Sigen Hybrid SigenStor BAT D. Gateway Backup Distribution panel Backup Electric equipment Diesel generator Power grid mySigen Router Antenna CommMod When B is SigenStor AC, A is not configured. ...
- Page 17 User Manual Networking Diagram (Partial Home Backup) A. PV panel SigenStor EC/SigenStor AC /Sigen Hybrid SigenStor BAT D. Gateway Backup Distribution panel E2. Non-Backup Distribution panel F1. Backup Electric equipment Non-Backup Electric equipment Diesel generator Power sensor Power grid mySigen Router Antenna CommMod...
- Page 18 User Manual transition between PV, storage and diesel power generation. It is recommended to use FE and WLAN for communication with inverter. CommMod users must top up their own 4G data plan after a period of 2 years. Networking Diagram (Non-backup Networking) A.
- Page 19 User Manual CommMod users must top up their own 4G data plan after a period of 2 years. The rated voltage of the AC switch of the distribution panel should be not less than 380Va.c., and the rated current is recommended, that is, not less than the maximum output current of an inverter ×...
- Page 20 User Manual Site Selection Requirements The warranty applies when the equipment has been installed properly for its intended use and in accordance with the operating instructions. Installation Environment Requirements Do not install the equipment in smoky, flammable, or explosive environments.
- Page 21 User Manual Do not install the equipment in mobile scenarios such as RVS, cruise ships, and trains. You are advised to install the equipment in places that are easy to access, install, operate, maintain, and view indicator status. When installing the equipment in the garage, do not install the equipment ...
- Page 22 User Manual The maximum operating temperature range applicable to the equipment is -20°C to 55°C, and the recommended optimal operating temperature range is 10°C ≤ T ≤ 35°C. When the battery pack temperature is below 0°C, immediate charging is ...
- Page 23 User Manual Equipment Installation and Wiring Only company authorized personnel should install and connect the equipment. For details, see SigenStor Home Installation Guide - Three-phase System A1. 23 / 36...
-
Page 24: Working Mode
User Manual System Operation 5.1 Working Mode There are four operating modes of the energy storage system: Sigen AI Mode, Self-Consumption Mode, Fully Fed to Grid Mode, Time-based Control Mode. The Sigen AI Mode is recommended. Sigen AI Mode can be used in some countries, which is explicitly stated on ... - Page 25 User Manual night, the batteries are discharged to ensure that the inverter can maximize the output. Self-Consumption Mode When there is sufficient solar power, the electric energy generated by the PV system will first be used to power the loads, with any excess energy being stored in the batteries.
- Page 26 User Manual Backup Reserve: If there is a Gateway in the network, you can manually set the "Backup Reserve" value in mySigen App. When the grid is connected, the battery stops discharging when the set backup SOC is reached; when the grid is powered down, the battery power from the backup can be used.
-
Page 27: Led Indicator State
User Manual 5.2 LED Indicator State SigenStor EC/ SigenStor AC/Sigen Hybrid Indicator Indicator Color State Description Always on The DC side is connected but not running. Always on The DC side is running. The DC side is not connected. Flash The DC side is faulty. - Page 28 User Manual Indicator Color State Description The management system is not connected. Flash Connected to local App. Always on Connected to the management system using an FE or WLAN. Always on Connected to the management system over 4G. Flash Insufficient traffic for Sigen CommMod. CommMod Indicator Name State...
-
Page 29: Mysigen App Query
User Manual 5.3 mySigen App Query The App can be downloaded in the following two ways. For details, see mySigen App User Manual. 29 / 36... -
Page 30: Routine Maintenance
User Manual System Maintenance 6.1 Routine Maintenance To ensure the long-term running of the equipment, you are advised to perform routine maintenance according to this section. Inspection Inspection method Power off Maintenance content or not cycle System Check the decorative cover regularly Once every cleaning for shielding and dirt. -
Page 31: Equipment Powering-On/Power-Off
User Manual 6.2 Equipment Powering-on/Power-off Scheme 1: App operation In the mySigen app, tap "Settings" to turn the device on or off. Scheme 2: Manual operation Follow the steps shown to remove the side and top decorative cover, and press the ON/OFF switch button. - Page 32 User Manual In case of prolonged inactivity of the equipment (such as being offline for several consecutive days or having minimal operational hours), the system will issue a reminder. If no feedback is received from you, the equipment will be automatically turned off as a precautionary measure for safety.
-
Page 33: Low Soc
User Manual 6.3 Low SOC The self-discharge characteristic of battery pack will cause power loss. If the equipment is not charged for a long time, it may be damaged due to overdischarge of power. When the battery is low, charge the equipment in time. Under normal circumstances, the equipment can charge itself according to the running condition. -
Page 34: Emergency Treatment
User Manual 6.4 Emergency Treatment Emergency in case of Fire Please shut down the equipment or disconnect the main power switch when it is safe. The high temperature may distort or damage the battery pack, resulting in electrolyte overflow or toxic gas leakage. Do not go near the battery pack and wear protective equipment. - Page 35 User Manual Emergency in case of Battery Pack Malfunctions When the battery pack has abnormal odor, electrolyte leakage, or heat, do not touch it, and contact professional personnel immediately. Professionals must wear protective equipment such as goggles, rubber gloves, gas masks, and protective clothing to protect themselves. The electrolyte is corrosive and contact may cause skin irritation or ...
-
Page 36: Technical Parameter
User Manual Appendix 7.1 Technical Parameter For details about equipment parameters, see the Data sheets of the product. 36 / 36...
