Event Viewer and Events Windows

The Event Viewer and Events Windows display SATA device-related events that occur while SATARaid is running. Selecting
categories in the Event Viewer window applies a filter to the Events window so that only messages of the type selected are
displayed. This allows only Warning or Error messages to be seen, for example.

SATARaid Toolbar and Menu Commands

The Toolbar buttons from Left to Right are:
A – RAID Management
B – System View
C – Configure SATARaid
D – Send Configuration
E – Save Configuration
F – Copy Configuration
G – SATARaid Help
All options available via the Command Menu are replicated on the toolbar except Exit and About SATARaid. The Menu
commands are shown below
File
Save Configuration
Copy Configuration
Exit
The commands are documented on the pages that follow.
Copyright © 2003 Silicon Image Inc.
34
Advanced
RAID Management
System View
Configure SATARaid
Send Configuration
Help
SATARaid Help
About SATARaid
SATARaid User's Manual
