- Page 1 Extraction arm KUA-160/H /S /ATEX Installation and user manual https://www.plymovent.com/en/service/manuals www.plymovent.com...
-
Page 2: Table Of Contents
To improve comprehension for people whose first language is not English, we have written parts of this manual in Simplified Technical English (STE). STE is a controlled language originally developed for aerospace industry maintenance manuals. It offers a carefully limited and standardized subset of English, along with specific writing rules. 0000101887/09JAN23/E KUA-160... -
Page 3: Safety Instructions For Use
Das Produkt wurde ausschließlich zum Absaugen und Filtern von Rauch - Schleifen von Werkstücken aus Aluminium und und Gasen entworfen, die bei den gebräuchlichsten Schweißprozessen Magnesium freigesetzt werden. Jede andere oder darüber hinausgehende - Explosionsgefährliche Umgebungen oder Substanzen / Verwendung gilt nicht als bestimmungsgemäß. Gase 0000101887/09JAN23/E KUA-160... -
Page 4: Instructions De Sécurité Pour L'utilisation
- La máquina no la deberán usar niños ni personas con capacidades físicas, sensoriales o mentales reducidas, o con falta de experiencia y conocimientos, a menos que reciban supervisión o instrucciones. 0000101887/09JAN23/E KUA-160... -
Page 5: Istruzioni Di Sicurezza Per L'uso
- sgorbiatura ad arco sufficienti estintori approvati (adatti per classi di incendio ABC). - aspirazione di particelle solide o liquide che siano - Non lasciare attrezzi né altri oggetti nell’unità o sopra di essa. infiammabili, ardenti o incandescenti 0000101887/09JAN23/E KUA-160... -
Page 6: Instrukcje Bezpieczeństwa
- odciągania agresywnych oparów (na przykład kwasu solnego) lub ostrych elementów - odciągania cząsteczek pyłu, które są uwalniane podczas spawania powierzchni pokrytych preparatem gruntującym - odciągania papierosów, cygar, oleju i innych płonących cząstek, obiektów i kwasów 0000101887/09JAN23/E KUA-160... -
Page 7: Preface
- 17 kg (37½ lbs) - wall bracket (H types) - 4 kg (9 lbs) The KUA-160 is an extraction arm with an external middle hinge. The removable hood has a safety mesh. The arm is Performance fitted with a control valve and is 360° rotatable . -
Page 8: Product Description
KUA-160 ATEX safety regulations. Only use this product when in technically KUA-160 ATEX arms are suitable for use in potentially explosive environments. They comply with ATEX directives due “Intended use” as explained in EN-ISO 12100-1 is the use for which the... -
Page 9: Installation
- explosive environments or explosive substances/ Make sure that the product is complete. The gases package contains: This warning does not apply to KUA-160 ATEX arms - extraction arm (pre-assembled) WARNING! - rotating flange Do not use the product for: - arm swivel ring, incl. - Page 10 Fig. III on page 15 gives a summary of the relevant paragraphs per arm type (specifically H, ATEX and S) and the preferred mounting sequence. For mounting of the KUA-160/H (hanging; including ATEX): • proceed with paragraph 4.4 For mounting of the KUA-160/S (standing): •...
- Page 11 For mounting of the hood: • refer to paragraph 4.6 In case of a KUA-160/H ATEX: subsequently proceed with paragraph 4.7 • 4.4.4 Fan mounting To install an extraction fan on the arm, do the following. Fig. 4.4 • Put the fan on the wall bracket.
- Page 12 Fig. 4.6 Rotating flange KUA-160 ATEX Fig. 4.7 The KUA-160 ATEX arm is factory-wise provided with litz wires • Move the hose clamp (C) and the arm swivel ring (incl. between the metal parts, including the spring steel wires of rubber collar) (D) over the hinge rod (B).
-
Page 13: Use
Fig. 5.1 A = 480 mm (19 in.) B = >480 mm (19 in.) Sealed shut-off valve (H-D types only) Fig. 5.2 Correct position of the hood Control valve Handle 0000101887/09JAN23/E KUA-160... -
Page 14: Maintenance
Adjust the friction; refer to the images below for the DISPOSAL adjustment points. After life of the product, dispose of it in accordance Swivel bracket with federal, state or local regulations. “H” types “S” types 10. In case of swivel bracket or hood hinge 0000101887/09JAN23/E KUA-160... -
Page 15: Declarations
DECLARATIONS CE & UKCA Declarations of conformity for machinery We, Plymovent Manufacturing B.V., Koraalstraat 9, 1812 RK Alkmaar, Netherlands, herewith declare, on our own responsibility, that the products: - KUA-160/2H ATEX - KUA-160/3H ATEX - KUA-160/4H ATEX which this declaration refers to, have been manufactured in... - Page 16 1. Start with par. 4.5.1 par. 4.5.2 par. 4.5.3 2. Hood mounting par. 4.6 par. 4.6 par. 4.6 Fig. IV Mounting examples “H” types KUA-160 + FUA KUA-160 + PA-220 + FUA KUA-160/2 KUA-160/3 KUA-160/4 inch inch inch 37½ 1250 10½ 10½...
- Page 17 MATERIAL: - The information contained in this drawing is the sole property of 4x M12 lock nut ® PLYMOVENT. Any reproduction in part GENERAL TOLERANCES: - 3RD ANGLE PROJECTION MATERIAL: - The information contained in this or as a whole without written permission drawing is the sole property of of PLYMOVENT is prohibited.
- Page 18 ANNEX Fig. VIII Exploded view 0000101944 0000102409 0000102989 0000101907 0000101395 0000101903 0000102199 0000102396 0000102384 0000102387 0000102385 0000102388 0000102386 0000102389 0000101904 0000102397 0000102960 0000101906 0000101911 0000101908 0000101550 0000114072 0000101937 0000102525 0000101887/09JAN23/E KUA-160...
- Page 19 0000102384 Inner frame KUA-160/2H, complete 0000101550 Hood with safety mesh 0000102396 Inner tube KUA-160/2 0000101903 Arm swivel ring KUA-160, incl. rubber collar and washer 0000102397 Outer tube KUA-160/2 0000101906 Hose L=400 mm/Ø 163 mm, incl. 2 hose clamps KUA-160/3H ATEX 0000101907 Hose L=650 mm/Ø...
- Page 20 0000101887/09JAN23/E KUA-160 www.plymovent.com...
