Summarization of Contents
TCO'03 Display Requirements
Ergonomics
Focuses on visual ergonomics and image quality for better working environment and reduced eye strain.
Energy
Highlights energy-saving features beneficial for user and environment, and electrical safety.
Emissions
Covers electromagnetic fields and noise emissions related to the display.
Ecology
Details recycling prep, certified environmental management systems, and restrictions on hazardous materials.
Safety Notice
Precautions
Lists safety measures for monitor placement, ventilation, power source, and handling to prevent hazards.
Special Notes on LCD Monitors
Lamp Disposal
Provides information on mercury content in lamps and proper recycling/disposal procedures according to laws.
Before Operating the Monitor
Features
Lists key features: screen size, display quality, energy efficiency, and design.
Checking the Contents of the Package
Details items expected in the package for user verification.
Installation Instructions
Installation
Step-by-step guide to align, snap, and verify monitor attachment to its base.
Removal
Instructions for safely detaching the monitor's stand base by pressing clips and pulling gently.
Power Source
Explains power cord connection, noting universal supply for different voltage areas.
Setting the Monitor on the Wall
Disassembling the Stand Base
Steps to disconnect cables and carefully remove the stand base from the monitor face-down.
Wall Mounting the Monitor
Guide on purchasing VESA bracket, locating position, fixing bracket, and securing monitor.
Making Connections
Connecting to a PC
Instructions to turn off PC, connect VGA/power cables, then turn on monitor and computer.
Operating Instructions
General Instructions
Explains turning monitor on/off, button locations, cable connection, and power indicator.
Front Panel Control
Power Button
Pressing this button switches the monitor's power ON or OFF.
Power Indicator
Indicates power status: Green for On mode, Orange for Power Saving mode.
MENU/RETURN Button
Navigates OSD menus, returns to previous screens, or exits menus.
Adjust ▲▼ Buttons
Adjusts brightness and navigates OSD options.
【i】Button
Used for confirmation and auto adjustment functions.
Hotkeys
Provides shortcuts for restoring defaults, changing aspect ratio, resolution, and preset modes.
How to Adjust Settings
Brightness and Contrast Settings
Adjusts display brightness, contrast, and X-CONTRAST for optimal image quality.
Input and Signal Settings
Configures input source (VGA/DVI) and enables automatic signal search for connected devices.
Color Settings
Adjusts color temperature (WARM, NATURE, COOL) and custom user RGB levels.
Image Settings
Covers auto adjustment for image optimization and aspect ratio adjustments for display scaling.
System Settings
Audio Input Configuration
Configures audio input for HDMI, recommending PC for no sound output or when using LINE IN.
Volume and Mute Control
Adjusts volume levels and toggles the mute function on or off.
DDC/CI Function
Enables or disables the DDC/CI function for communication between monitor and host.
Factory Reset and Information
Resets monitor settings to default and displays system information like frequency and resolution.
Plug and Play
Plug & Play DDC2B Feature
Explains VESA DDC2B capabilities for monitor identity and display capability communication with the host.
Monitor Operation with No Video Input
States the monitor is non-functional without video input and requires a signal to operate properly.
Technical Support (FAQ)
General Problem Solving (Q&A)
Provides solutions for common problems like power issues, no display, picture distortion, color defects, and sound.
Error Message & Possible Solutions
Cable Connection Errors
Troubleshooting steps for checking signal cable connection and pin integrity.
Unsupported Input Modes
Instructions to set computer to a suitable display mode from the FACTORY PRESET TIMING TABLE.
Factory Preset Timing Table
Lists supported resolutions, horizontal, and vertical frequencies for optimal display compatibility.
Appendix
Specifications
Provides detailed technical specifications: panel size, resolution, power consumption, and dimensions.
