AVR
Audio recorders
connect an analog audio recorder's inputs to the AVr's analog audio rec out connectors.
the recorded signal is determined by the source's record out setting in the Source Setup
menu. See Additional Source Setup Menu Items, on page 19, for more information.
AVr Analog Audio
recorder connectors
Stereo Audio cable
(not supplied)
Analog recording device
Video recorders
connect an analog video recorder's video input connector to the AVr's composite monitor
out connector. you can record any composite video signal. to record the audio and video
from the source device, connect the AVr's Analog rec out connectors to the analog video
recorder's audio inputs.
NOTE: If you have connected the AVR's Composite Monitor Out video connector
to your TV, you cannot connect a VCR to the AVR for recording.
AVr Analog
AVr Analog
Audio recorder
Video recorder
connectors
connectors

Connect to Your Home Network

use a cat. 5 or cat. 5e cable (not supplied) to connect the AVr's network connector to
your home network to enjoy Internet radio and content from dlnA
that are connected to the network.
AVr
network
connector
cat. 5/5e cable
(not supplied)
to Stereo Analog
record Inputs
Analog Audio/Video
cable (not supplied)
to Analog Audio/Video
record Inputs
Analog Video recording device
-compatible devices
®
network
modem
to
home
network
and
Internet
Making Connections, continued

Connect the Radio Antennas

• Connect the supplied FM antenna to the AVR's FM 75Ω radio Antenna connector. for
the best reception, extend the fm antenna as far as possible.
• Bend and fold the base of the supplied AM antenna as shown and connect the antenna
wires to the AVr's Am and gnd connectors. rotate the antenna as necessary to
minimize background noise.
Am Antenna
AVr
(supplied)
Antenna
connectors
fm Antenna (supplied)

Connect IR Equipment

If you place the AVr inside a cabinet or facing away from the listener so that the AVr's Ir
sensor is not within line-of-sight of the remote control, connect an external Ir receiver,
such as the harman kardon he 1000 (available separately) to the AVr's Ir In connector.
AVr Ir remote
IR IN
In connector

Connect the Trigger Output

If your system has equipment that can be controlled by a dc trigger signal, connect it to
the AVr's trigger out connector with a mono 1/8-inch (3.5mm) mini-plug interconnect
cable. the AVr will supply a 12V dc (100mA) trigger signal at this connection whenever
it is powered on.
AVr
device with trigger
in connector
bend and fold base
external Ir
receiver
AVr and Source
devices Installed
Inside of cabinet
mono 1/8-inch
(3.5mm)
mini-plug
Interconnect
(not supplied)
15
