9.2 Generator Operation Notes
1) The two wires start signal DRYO_1A and DRYO_1B of the Generator is used to
automatically control the start and stop of the Generator.
2)Make sure the inverter units software version support Generator function.
USER->INQUIRE->FIRMWARE
3) When the generator is used in inverter parallel situation, the two wires start
signal is only needed to be connected to the master unit. The wiring and the setting
of the Generator should be exactly same.
4)Please check the diagram above.
9.3 Generator Setting
The Generator setting page can be visited in the following steps in the screen:
USER->1. SETUP->PASSORD CHECK->16.Generator
9.3.1 Setting
Interface
Generator.
1.START SOC.
2.STOP SOC
3.ChgCurrToBAT
4.MAX RUN TIME
5.COOLDOWN
6.CONTRL
7.POWER
FIRMWARE
ARM:
V1.XX.XX
DSP:
V1.XX.XX
V1.XX.XX
DSP:
V1.XX.XX
This interface shows Generator setting.
1.
When the SOC of battery is lower than the
setpoint,the Generator drycontact is enabled and
Generator Manual operation is disabled, the
connected Generator will be started.
2.
When the SOC of battery is higher than the
setpoint,the Generator drycontact is enabled and
Generator Manual operation is disabled, the
connected Generator will be stopped.
3.
It indicates the maximum current that the inverter
charges the battery from Generator.
4.
It indicates the longest time Generator can run in
one day, when time is up, the Generator will be
turned off. The value 240 means 24hours in which
state the Generator will not be shut down all the
time. The unit is 0.1 hour.
5.
It indicates the waiting time of the Generator to
restart after it has reached the running time.The
unit is 0.1 hour.
Description
61
