Comfort Glow CSBNT Owner's Operation And Installation Manual
(vent-free) gas stove heater
Hide thumbs
Also See for CSBNT:
- Owner's operation and installation manual (24 pages) ,
- Owner's operation and installation manual (26 pages) ,
- Owner's operation and installation manual (56 pages)
Table of Contents
Advertisement
Quick Links
For more information, visit www.desatech.com
For more information, visit www.desatech.com
Models
CSBNT, CSBPT
CSPBNT, CSPBPT
CSPINT, CSPIPT
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result caus-
ing property damage, personal injury, or loss of life.
-- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
-- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's in-
structions.
• If you cannot reach your gas supplier, call the fire
department.
-- Installation and service must be performed by a quali-
fied installer, service agency, or the gas supplier.
This appliance may be installed in an aftermarket*, permanently located, manufactured (mobile)
home, where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This appli-
ance is not convertible for use with other gases.
* Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer
Propane/LP and Natural Gas
Thermostat Control Gas Log Heaters
(Burner System For Cast Iron Stoves)
Save this manual for future reference.
Save this manual for future reference.
(VENT-FREE)
GAS STOVE HEATER
OWNER'S OPERATION AND
INSTALLATION MANUAL
WARNING: Improper installation,
adjustment, alteration, service, or
maintenance can cause injury or
property damage. Refer to this
manual for correct installation and
operational procedures. For assis-
tance or additional information con-
sult a qualified installer, service
agency, or the gas supplier.
WARNING: This is an unvented gas-
fired heater. It uses air (oxygen)
from the room in which it is in-
stalled. Provisions for adequate
combustion and ventilation air must
be provided. Refer to Air for Com-
bustion and Ventilation section on
page 4 of this manual.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Comfort Glow CSBNT
Summary of Contents for Comfort Glow CSBNT
- Page 1 For more information, visit www.desatech.com For more information, visit www.desatech.com Models CSBNT, CSBPT CSPBNT, CSPBPT CSPINT, CSPIPT WARNING: If the information in this manual is not followed exactly, a fire or explosion may result caus- ing property damage, personal injury, or loss of life.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY INFORMATION TABLE OF CONTENTS SAFETY INFORMATION ... 2 PRODUCT IDENTIFICATION ... 3 LOCAL CODES ... 4 PRODUCT FEATURES ... 4 AIR FOR COMBUSTION AND VENTILATION ... 4 UNPACKING ... 6 INSTALLATION ... 6 OPERATING HEATER ... 11 INSPECTING BURNERS ... -
Page 3: Safety Information
SAFETY INFORMATION Continued This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases. Do not place propane/LP supply tank(s) inside any structure. Locate propane/LP supply tank(s) outdoors. If you smell gas •... -
Page 4: Local Codes
LOCAL CODES PRODUCT FEATURES AIR FOR COMBUSTION AND VENTILATION Providing Adequate Ventilation LOCAL CODES Install and use heater with care. Follow all local codes. In the absence of local codes, use the latest edition of The National Fuel Gas Code ANSI Z223.1/NFPA 54*. -
Page 5: Air For Combustion And Ventilation
Example: 2560 cu. ft. (volume of space) x 20 = 51,200 (maximum Btu/Hr the space can support) Add the Btu/Hr of all fuel burning appliances in the space. Vent-free heater ______________ Btu/Hr Gas water heater* ______________ Btu/Hr Gas furnace ______________ Btu/Hr Vented gas heater... -
Page 6: Unpacking
AIR FOR COMBUSTION AND VENTILATION Ventilation Air (Cont.) UNPACKING INSTALLATION AIR FOR COMBUSTION AND VENTILATION Continued Ventilation Air From Outdoors Provide extra fresh air by using ventilation grills or ducts. You must provide two permanent openings: one within 12" of the ceiling and one within 12"... -
Page 7: Clearances To Combustibles
INSTALLATION Continued CAUTION: This heater creates warm air currents. These currents move heat to wall surfaces next to heater. Installing heater next to vinyl or cloth wall coverings or operating heater where impurities (such as, but not limited to, tobacco smoke, aromatic candles, cleaning fluids, oil or kerosene lamps, etc.) in the air exist, may discolor walls or cause odors. -
Page 8: Connecting To Gas Supply
INSTALLATION Connecting To Gas Supply INSTALLATION Continued CONNECTING TO GAS SUPPLY WARNING: This appliance requires a 1/2" NPT (National Pipe Thread) inlet connection to the pres- sure regulator. WARNING: A qualified service person must con- nect heater to gas supply. Follow all local codes. CAUTION: Never connect propane/LP heater di- rectly to the propane/LP supply. -
Page 9: Checking Gas Connections
INSTALLATION Continued WARNING: Use pipe joint sealant that is resistant to liquid petroleum (LP) gas. We recommend that you install a sediment trap in supply line as shown in Figure 8. Locate sediment trap where it is within reach for cleaning. - Page 10 INSTALLATION Checking Gas Connections (Cont.) Installing Rod and Screen INSTALLATION Continued Pressure Testing Heater Gas Connections Open equipment shutoff valve (see Figure 9, page 9). Open main gas valve located on or near gas meter for natural gas or open propane.LP supply tank valve. Make sure control knob of heater is in the OFF position.
-
Page 11: Operating Heater
INSTALLATION Continued INSTALLING LOG SET Set one-piece log on heater base as shown in Figure 12. Make sure middle section at bottom of log is seated into "U" shaped cutout in center of heater base. Log will fit securely on base. IMPORTANT: Make sure log does not cover any burner ports and does not touch the stove cavity (see Figure 14). -
Page 12: Thermostat Control Operation
OPERATING HEATER Lighting Instructions (Cont.) To Turn Off Gas To Appliance Thermostat Control Operation Manual Lighting Procedure INSPECTING BURNERS OPERATING HEATER Continued Note: You may be running this heater for the first time after hooking up to gas supply. If so, the control knob may need to be pressed in for 30 seconds or more. -
Page 13: For More Information, Visit Www.desatech.com For More Information, Visit Www.desatech.com
INSPECTING BURNERS Continued MAIN BURNER Periodically inspect all burner flame holes with the heater running. All slotted burner flame holes should be open with yellow flame present. All round burner flame holes should be open with a small blue flame present. -
Page 14: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Note: For additional help, visit DESA Heating Products’ Technical Service web site at www.desatech.com. Note: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM When ignitor button is pressed, there is no spark at ODS/pilot When ignitor button is pressed, there is... - Page 15 TROUBLESHOOTING Continued OBSERVED PROBLEM Burner does not light after ODS/pilot is lit Delayed ignition burner Burner backfiring during combustion Slight smoke or odor during initial operation Moisture/condensation noticed on windows Heater produces a whistling noise when burner is lit Dark residue on logs or inside of fireplace White powder residue forming within burner box or on adjacent walls or furniture For more information, visit www.desatech.com...
- Page 16 TROUBLESHOOTING TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.
-
Page 17: Specifications
Contact authorized dealers of this product. If they can’t supply original replacement part(s), either contact your nearest Parts Central (see page 22) or call DESA Heating Products at 1-866-672-6040 for referral information. When calling DESA Heating Products, have ready • model number of your heater •... -
Page 18: Illustrated Parts Breakdown And Parts List
ILLUSTRATED PARTS BREAKDOWN Models 111485-01 and 111485-02 ILLUSTRATED PARTS BREAKDOWN MODELS 111485-01 AND 111485-02 For more information, visit www.desatech.com For more information, visit www.desatech.com 111487-01C... -
Page 19: Parts List
PARTS LIST This list contains replaceable parts used in your stove. For replace- ment parts see Replacement Parts on page 17 of this manual. PART NUMBER 111485-01 104026-01 098249-01 104454-01 098867-10 104425-01 104424-03 099056-19 111124-01 102980-01 101329-22 104472-01 099211-01 102445-01 099387-09 098271-10 104286-01... - Page 20 ILLUSTRATED PARTS BREAKDOWN Models CSB Series, CSPB Series, and CSPI Series ILLUSTRATED PARTS BREAKDOWN STOVE BODY MODELS CSB SERIES, CSPB SERIES, AND CSPI SERIES For more information, visit www.desatech.com For more information, visit www.desatech.com 111487-01C...
- Page 21 PARTS LIST This list contains replaceable parts used in your stove. For replace- ment parts see Replacement Parts on page 17 of this manual. PART NUMBER CSB Series CSPB Series (Black) (Porcelain Black) 111698-07 111698-08 111698-11 111698-12 111531-01CK 111531-01CK 111698-14 111698-15 111698-17 111698-18...
-
Page 22: Parts Centrals
PARTS CENTRALS PARTS CENTRALS These Parts Centrals are privately owned businesses. They have agreed to support our customer’s needs by providing original replacement parts and accessories. Tool & Equipment Company 1348 Dixwell Avenue Hamden, CT 06514-0322 1-800-397-7553 203-248-7553 Parts Department Portable Heater Parts 342 N. -
Page 23: Owner's Registration Form
Address: City: Home Phone: E-Mail: Please answer the following questions to register your product with DESA Heating Products: 1. Where will the product be used? ❍ Living/Family Room ❍ Office/Warehouse If you bought this product yourself, did you plan to purchase this type of product before going into the store? 3. - Page 24 Postage Required 2701 Industrial Drive P.O. Box 90004 Bowling Green, KY 42102-9004 For more information, visit www.desatech.com For more information, visit www.desatech.com 111487-01C TAPE...
- Page 25 NOTES NOTES _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ For more information, visit www.desatech.com For more information, visit www.desatech.com 111487-01C...
-
Page 26: Warranty Information
VENT-FREE PROPANE/LP GAS OR NATURAL GAS LOG HEATERS DESA Heating Products warrants this product to be free from defects in materials and components for two (2) years from the date of first purchase, provided that the product has been properly installed, operated and maintained in accordance with all applicable instructions. To make a claim under this warranty the Bill of Sale or cancelled check must be presented.
Need help?
