FEEDBACK
LINE
SPECIAL DISCHARGE
PORT FTG. W/
FEEDBACK LINE
CONNECTION
DISCHARGE
PORT
SPECIAL DISCHARGE
PORT FTG. W/
FEEDBACK LINE
CONNECTION
END COVER
BOTTOM VIEW
FIGURE 2 - AD-IP ™ DI DROP IN AIR DRYER FOR HOLSET
COMPRESSORS
™
AD-IP DI "DROP IN" AIR DRYER MODEL
In addition to the standard AD-IP
AD-IP ™ DI (Drop In) air dryer is also offered. It is a specialized
version designed especially for air systems that use either
the Holset (Cummins) Type E or QE air compressor. These
Holset compressors utilize an unusual unloading system
that requires that air pressure remain in the discharge line
during the entire unloaded cycle of the compressor. To
accomplish this, Holset compressors rely on air "feedback"
from the supply reservoir as shown in Figure 3B. When an
air dryer is installed the direct "feedback" from the supply
reservoir is interrupted and an alternate source for "feedback"
pressure must be provided. A standard AD-IP
be installed, however a separate "feedback" line with a single
check must be installed as shown in Figure 3C.
The AD-IP ™ DI drop in air dryer model incorporates the
feedback line and single check as an integral part of the
dryer and eliminates the need for these components as shown
in Figures 2 & 3C.
2
CHECK
VALVE
LOWER
MTG. BRKT.
FEEDBACK
(PARTIAL)
LINE
™
air dryer, the Bendix
™
air dryer can
HOLSET COMPRESSOR
HOLSET TYPE E & QE COMPRESSORS - NO AIR DRYER
HOLSET
COMPRESSOR
STANDARD AD-IP
HOLSET TYPE E & QE COMPRESSORS
HOLSET
COMPRESSOR
™
AD-IP DI DROP IN AIR
DRYER W/FEEDBACK
LINE & CHECK VALVE
™
AD-IP
HOLSET TYPE E & QE COMPRESSORS
FIGURE 3 - AD-IP ™
COMPRESSORS

OPERATION

®
GENERAL
™
The AD-IP air dryer alternates between two operational
modes or "cycles" during operation: the Charge Cycle and
the Purge Cycle. The following description of operation is
separated into these "cycles" of operation.

CHARGE CYCLE

When the compressor is loaded (compressing air)
compressed air, along with oil, oil vapor, water and water
vapor flows through the compressor discharge line to the
supply port of the air dryer body.
As air travels through the end cover assembly, its direction
of flow changes several times, reducing the temperature,
causing contaminants to condense and drop to the bottom
or sump of the air dryer end cover.
After exiting the end cover, the air flows into the desiccant
cartridge. Once in the desiccant cartridge air first flows
through an oil separator located between the outer and inner
shells of the cartridge. The separator removes water in liquid
form as well as liquid oil and solid contaminants.
DISCHARGE LINE
FIGURE A
STANDARD AD-IP
DRYER
FEEDBACK LINE
W/CHECK VALVE
FIGURE B
™
AIR DRYER AND
FIGURE C
DI DROP IN AIR DRYER AND
AIR DRYER AND HOLSET TYPE E & QE
(refer to Figure 4)
SUPPLY
RES.
™
AIR
SUPPLY
RES.
SUPPLY
RES.
