PORTABLE GASOLINE GENERATORS
ILLUSTRATED
PARTS LIST
FOR MODEL RGH11000IE

ALTERNATOR ASSEMBLY

This list contains replaceable parts used in
your generator. When ordering parts, follow
the instructions listed under Replacement
Parts on page 17 of this manual.
®
23
25
4
22
3
KEY
NO. DESCRIPTION
1 Stator
2 Rotor
3 Draw Bolt
4 Fan
5 Balancing Disc
6 Lifting Eyes
7 D.E. Bracket
8 N.D.E. Bracket
9 Mounting Bolts
10 Nuts
11 Top Box
12 Screw and Washer
13 Plastic Cap
14 Bearing
15 Borelly Washer
16 Diode
17 Terminal Block
18 Capacitor
19 Tie Wrap
20 Foam Pad
21 Capacitor Bracket
22 Engine Flange
23 Bolts
24 'O' Ring
25 Washer
26 Hex Head Nut
† Alternator Assembly
* Part not available by itself. Must purchase Alternator Assembly.
19
17
21
12
11
2
16
7
PART
NUMBER
*
*
103188-01
103191-01
103192-01
103193-01
103194-01
103195-01
099847-05
270010105
103189-01
099701-01
103198-01
103199-01
103200-01
27003012S
103201-01
099845-02
103204-01
099892-02
103202-01
103190-01
27003155
103203-01
WLE-5
099891-01
102938-01
20
18
20
8
15
24
14
5
1
6
9
QTY.
1
1
1
1
1
2
1
1
4
4
1
6
1
1
1
2
1
1
1
1
1
1
4
1
2
1
1
13
26
10
104960
